Structural Concepts Fusion GP441RR User Manual page 6

Installation: Case Removal From Skid
Remove Lower Front Panel From Case:
• To prevent damage to the case, remove the lower front
panel from the case before removing it from the pallet.
• The lower front is held in place by magnets only. No
screw removal is required.
• Place the lower front panel in a secure location while
removing the case from the pallet.
Remove Lower Rear Panel From Case:
• Remove the lower rear panel from the case before
removing it from the pallet.
• The lower rear is held in place by magnets only. No screw
removal is required.
• Place the lower rear panel in a secure location while
removing the case from the pallet.
Disconnect Case From Pallet:
• Remove screws from shipping brackets. Remove and
discard shipping brackets from the pallet.
• Raise the leveler all the way up to engage the casters.
Fusion® User Manual Fusion® User Manual Oasis® B(L)24 User Manual
Lower Front Panel
Lower Rear Panel
Shipping Bracket
