- Page 1 Venture Mobile Active Battery-Powered Speaker User Manual The information included in this user manual is subject to change at any time and without notification: Version: 1.0 Date & Author Initials: 05-12-2022 YDL Revision Date & Author Initials: –...
- Page 2 Thanks for purchasing the Devine Venture Mobile active speaker. Before unpacking the box, we recommend reading this user manual thoroughly to ensure that you are familiar with all of the features and functions that the Venture Mobile has to offer. When unpacking the box, please make sure that all of the components and accessories listed below have been included.
-
Page 3: Safety Instructions
Safety Instructions WARNING! Keep this device away from moisture, water and rain to prevent any danger of electric shocks! Every person involved with the installation, operation and maintenance of this device must: - Be qualified. - Be skilled. - Have read the instructions included in this user manual. - Be sure that neither the device nor the included accessories are damaged. - Page 4 - In case of emergency, ensure that the device can always be quickly switched off or unplugged. Always make sure that one of these power points is within reach during use: - the IEC C13 power input of the device, found on the rear panel - the CEE 7/7 hybrid plug of the included power cable –...
- Page 5 Using the Battery and Maintaining its Lifespan The Devine Venture Mobile speaker features a pre-installed lithium-ion battery. This battery is able to power the speaker without the need to plug it into a power socket. After unpacking the speaker, it is recommended to fully charge the battery before switching the speaker on for the first time.
- Page 6 and trade names are the property of their respective owners. The information included in this user manual is subject to change at any time and without notification: Version: 1.0 Date & Author Initials: 05-12-2022 YDL Revision Date & Author Initials: –...
- Page 7 Overview...
-
Page 8: Warning Before Use
The Devine Venture Mobile is a powerful speaker complete with a built-in amplifier and a range of options for playing back music or amplifying microphones (not included). This section of the manual includes information about all the functions that this speaker has to offer and the optional accessories it can be combined with. -
Page 9: Adjusting The Sound
When Hi-Z mode is activated, an electric guitar or electro-acoustic guitar can be plugged in and amplified by the Devine Venture Mobile speaker. To use the normal line-level input mode once more, simply set the Hi-Z switch back to the Off position. - Page 10 Bluetooth connection. Two Devine Venture Mobile speakers can be linked via Bluetooth to complete a stereo pair without the need for any connecting cables. By pushing the BT PAIR button on both speakers, they will detect one another to automatically form a wireless stereo pair.
-
Page 11: Troubleshooting
Troubleshooting If you happen to encounter any problems while using your speaker, we recommend checking this troubleshooting section to see if a solution can be found. If none of the suggested solutions included below solve your particular problem, please contact your local retailer for further advice. This troubleshooting section includes all of the most common issues and is not a complete list of every possible fault or defect and their subsequent solution. - Page 12 Problem Possible Cause Solution Badly distorted or crackling sound Connected equipment is sending a Check if any connected equipment distorted signal is sending a distorted signal and reduce the volume where necessary. Volume level is too high Turn the volume down slightly. Treble and/or bass controls are too Turn the treble and bass controls high...
-
Page 13: Specifications
– Fuse: 110 V: T4AL 250V, 230 V: T2AL 250V Technical Details: – Connection voltage: 110-240 V AC, 50/60 Hz – Fuse: T2A250V – Amplifier power: 100 + 100 W RMS (200 + 200 W max.) Feature Venture Mobile Woofer 10” woofer Tweeter 1” constant directivity Frequency Range 65 Hz –... - Page 14 EU Declaration of Conformity Devine pro audio and studio products Verrijn Stuartweg 18 4462 GE Goes The Netherlands This declaration of conformity is issued under the full responsibility of the manufacturer. Product code: Product name: Devine Venture Mobile Active 10 inch loudspeaker with Bluetooth (2.4 GHz) The objects of the declaration described above are in accordance with the relevant harmonisation laws of the European Union.
- Page 15 UK Declaration of Conformity Devine pro audio and studio products Verrijn Stuartweg 18 4462 GE Goes The Netherlands This declaration of conformity is issued under the full responsibility of the manufacturer. Product code: Product name: Devine Venture Mobile Active 10 inch loudspeaker with Bluetooth (2.4 GHz) The objects of the declaration described above are in conformity with the relevant statutory requirements of the United Kingdom: Radio Equipment Regulations 2017.
