A T
BOUT THE IGER
LED
1~24
(PoE Mode)
Combination Ports
25-26
(Link/Activity)
1-6
S III 10/100
TACK
Table 1-1
Condition
On Green
Flashing Green
Flashing Amber
On Amber
Alternate
Green/Amber
Off
On/Flashing
Amber
On/Flashing
Green
Off
Port Status LEDs
Status
Powered device is connected, but not
drawing power.
Powered device is receiving power.
Port has detected a power overload or
short circuit and shut down the port's
power.
The power budget for the switch has
been exceeded and the port's power
shut down.
Port power has been turned off by the
administrator.
No powered device is connected to the
port.
Port has established a valid
10/100 Mbps network connection.
Flashing indicates activity.
Port has established a valid 1000 Mbps
network connection. Flashing indicates
activity.
There is no valid link on the port.
