Laser Sight LT70 DCS/Super
Safety, Operation, Maintenance
LS LT70DCS Laser Kit
(LT70DCS & LT70Super)
USED WITH:
LT70 DCS MILLS
LT70 SUPER HYDRAULIC
FOR ALL OTHER LT70 MILLS, SEE
MANUAL 1081
WARNING! Read and understand this
!
manual before using this machine.
& Parts Manual
Safety is our #1 concern!
February 2012
rev. E.00
Form #1786

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LT70 DCS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Wood-mizer LT70 DCS

  • Page 1 Laser Sight LT70 DCS/Super Safety, Operation, Maintenance & Parts Manual LS LT70DCS Laser Kit rev. E.00 (LT70DCS & LT70Super) Safety is our #1 concern! February 2012 Form #1786 USED WITH: LT70 DCS MILLS LT70 SUPER HYDRAULIC FOR ALL OTHER LT70 MILLS, SEE...
  • Page 2 Active Patents assigned to Wood-Mizer, LLC Wood-Mizer, LLC has received patents that protect our inventions which are a result of a dedication to research, innovation, development, and design. Learn more at: woodmizer.com/patents ©2024 Wood-Mizer LLC Printed in the United States of America, all rights reserved. No part of this manual may be reproduced in any form by any...
  • Page 3: Table Of Contents

    Table of Contents Section-Page SECTION 1 LASER INSTALLATION Laser Installation..................1-1 Laser Activation (LT70DCS Only)............1-2 Laser Activation (LT70Super Only) ............1-3 SECTION 2 OPERATION & ALIGNMENT Laser Operation (LT70DCS Only) ............2-1 Laser Operation (LT70Super Only)............2-1 Laser Alignment..................2-2 SECTION 3 REPLACEMENT PARTS Laser Assembly..................
  • Page 4: Section 1 Laser Installation

    Laser Installation Laser Installation SECTION 1 LASER INSTALLATION Before installing the laser option, be aware that the laser beam can not be seen in direct sunlight. The laser option is best for indoor cutting applications. Laser Installation 1. Locate the four square mounting holes on the saw head near the bottom of the drive-side blade housing. 2.
  • Page 5: Laser Activation (Lt70Dcs Only)

    Laser Installation Laser Activation (LT70DCS Only) Laser Activation (LT70DCS Only) The laser option needs to be activated in the control panel after installation. Use the following steps to activate the laser option. 1. Enter the User Configuration screen by pushing the UP button while in Manual Mode. 2.
  • Page 6: Laser Activation (Lt70Super Only)

    Laser Installation Laser Activation (LT70Super Only) FIG. 1-4 Laser Activation (LT70Super Only) The laser option does not need to be activated in the control panel after installation. The laser button is always available on the Main screen as shown below. 1.
  • Page 7: Section 2 Operation & Alignment

    Laser Operation (LT70DCS Only) SECTION 2 OPERATION & ALIGNMENT Laser Operation (LT70DCS Only) When properly installed, the laser option will guide you in making cuts. Press the laser button on the control panel to turn on the laser. The button LED will light up.
  • Page 8: Laser Alignment

    Laser Alignment Laser Alignment 1. Sawmills should be setup on firm, level ground before proceeding with alignment. 2. Shim the feet so the weight of the sawmill is evenly supported. 3. Adjust the two end outriggers on the main frame tube down just enough to lift weight from the trailer tire.
  • Page 9: Section 2 Replacement Parts

    Replacement Parts Laser Assembly SECTION 2 REPLACEMENT PARTS Laser Assembly PART # DESCRIPTION COMMENTS QTY. LS LT70DCS LASER KIT, COMPLETE FOR LT60/70 073701 Laser Assembly, 20 mW 638nm 90 Deg RED Available in assemblies only. Line 073863 Mount Weldment, LT70 Laser F05006-9 Bolt, 5/16-18 x 1”...
  • Page 10 Replacement Parts Laser Assembly PART # DESCRIPTION COMMENTS QTY. 025935 Bag Assembly, LT70 DCS Laser Parts 025671 Clamp, 1/4" Wire 9/32” Mounting Hole F05089-1 Tie Wrap, 1/4” x 6” F05005-15 Bolt, 1/4-20 x 1/2” Hex Head F05011-11 Washer, 1/4” SAE Flat...
