Wood-Mizer
®
Wireless Option
rev. B1.00
Operator's Manual
Safety is our #1 concern! Read and understand all
!
safety information and instructions before operating,
setting up or maintaining this machine.
Form #120

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LT70 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Wood-mizer LT70 Series

Summary of Contents for Wood-mizer LT70 Series

  • Page 1 Wood-Mizer ® Wireless Option rev. B1.00 Operator’s Manual Safety is our #1 concern! Read and understand all safety information and instructions before operating, setting up or maintaining this machine. Form #120...

  • Page 2: Table Of Contents

    Table of Contents Section-Page SECTION 1 OPERATION Safety......................... 1-1 Wireless control panel ....................1-2 Operation ........................1-4 SECTION 2 DIAGNOSTICS AND MAINTENANCE Diagnostics - Receiver....................2-2 Maintenance ......................2-3 Daily Maintenance Procedures Three-Month Maintenance Procedures SECTION 3 SPECIFICATIONS SECTION 4 PARTS LIST How To Use The Parts List ..................

  • Page 3: Operation

    WARNING! Failure to follow the safety precautions may result in radio equipment failure or serious personal injury. CAUTION! Wood-Mizer will not bear responsibility for any unapproved changes or modifications made to the equipment. Installation CAUTION! If maintenance is required, the radio must be disconnected from power.

  • Page 4: Wireless Control Panel

    Operation Wireless control panel Maintenance / Welding CAUTION! DISCONNECT THE RADIO RECEIVER BEFORE WELDING on the machine the receiver is connected to. Failure to disconnect will result in destruction of the radio receiver. Wireless control panel The LT70 sawmills can be equipped with the saw head remote control system (with a wireless control panel).
  • Page 5 Operation Wireless control panel Patrz rysunek 1-2. Wireless control panel functions LT70AC Blade Guide In/Out Blade Drive Motor Saw Head Up/Down START/STOP Diagnostic socket Feed Rate Dial Emergency Stop Debarker In/Out Debarker On/Off Starting Key (Air-Key) Saw Head Forward/Reverse Transmitter Activation Button Panel Working Status Indicator...
  • Page 6 Operation Operation Operation Set up the sawmill as instructed in your sawmill operator’s manual. Install the charged battery. Transmitter electronic system constantly controls battery voltage. When it falls below the appropriate value, the LED indicator light will turn red or an acoustic signal will be heard after which the system will automatically turn off.
  • Page 7 Operation Operation To turn on the wireless control panel on any DC (with diesel engine) sawmill: Make sure that all switches and joysticks are in the neutral or OFF position. The feed  rate dial should be set to the minimum value. Check that the switch located on the electric box is in the ON position;...
  • Page 8 Operation Operation SW-10 Operator’s Manual); Position the saw head at a height of the first cut;  If necessary, turn the debarker on;  Set the Blade Drive On/Off Switch in the upper position;  Push the left joystick forward and hold it in this position. The blade drive will be turned on within ...
  • Page 9 Operation Operation To turn on the wireless control panel on any AC (with electric blade motor) sawmill: Make sure that all switches and joysticks are in the neutral or OFF position. The feed  rate dial should be set to the minimum value. Check that the switch located on the electric box is in the ON position;...
  • Page 10 Operation Operation Position the saw head at a height of the first cut;  If necessary, turn the debarker on;  Start the blade motor by pressing the START button on the left side of the control panel;  Push the left joystick forward and hold it in this position. ...
  • Page 11 Operation Operation Operation doc021820...

  • Page 12: Diagnostics And Maintenance

    Diagnostics and Maintenance SECTION 2 DIAGNOSTICS AND MAINTENANCE CAUTION! DISCONNECT POWER SUPPLY FROM THE SAWMILL BEFORE SERVICING! Always disconnect the remote system before doing any maintenance to prevent accidental start-up of the machine. Before starting to perform any diagnostic operation, do as follows: Bring the transmitting unit close to the receiving unit to avoid any radio interference and ...

  • Page 13: Diagnostics - Receiver

    Diagnostics and Maintenance Diagnostics - Receiver Diagnostics - Receiver Signal lights are located on the side wall of the receiver. Operation Control light Control light Control light Control light Yellow Green Orange Operation Signal Error Normal Receiver is turning on Blinks every 0.5 sec.

  • Page 14: Maintenance

    Replace the transmitter panel if necessary. Check that the plates on the receiver are intact and readable.  If any transmitter/receiver fault occurs, contact your Wood-Mizer Representative. All repairs of the equipment should be done by authorized persons only. doc021820...

  • Page 15: Specifications

    Specifications SECTION 3 SPECIFICATIONS Transmitter Frequency 434MHz Weight < 2kg Power of transmitted signal <10mW Range about 100m Operating temperature range C - +70 (-18 F - +160 Operating humidity range 0-97% IP65 Approvals CE, TUV, ISO 9001 Antenna Internal Operating time on fully 14-20 hours charged battery...

  • Page 16: Parts List

    +48-63-2626000. From the continental U.S., call our toll-free Parts hotline at 1-800-448-7881. Have your customer number, vehicle identification number, and part numbers ready when you call. From other international locations, contact the Wood-Mizer distributor in your area for parts. doc021820 Parts List...

  • Page 17: Wireless Control Kit, Dc Sawmills

    Parts List Wireless Control Kit, DC Sawmills Wireless Control Kit, DC Sawmills REF. DESCRIPTION ( Indicates Parts Available In Assemblies Only) PART # WIRELESS CONTROL SYSTEM, HETRONIC LT70 DC SAWMILLS 533785 TRANSMITTER, DC HETRONIC NOVE-L/K RX18 533771 RECEIVER, HETRONIC RX18 PROP-HL 533772 BATTERY, HETRONIC 533773...

  • Page 18: Wireless Receiver Housing, Dc Sawmills

    Parts List Wireless Receiver Housing, DC Sawmills Wireless Receiver Housing, DC Sawmills REF. DESCRIPTION ( Indicates Parts Available In Assemblies Only) PART # HOUSING, DC WIRELESS RECEIVER 532248 BOX WELDMENT 530943-1 GASKET, CORK 532355 PLATE, FRONT 530945 PLATE, MOUNTING 532351-1 WASHER, 5.3 FLAT ZINC F81052-1 BOLT, #10-24X1/2 SELF-TAPPING...

  • Page 19: Wireless Receiver Housing, Ac Sawmills

    Parts List Wireless Receiver Housing, AC Sawmills Wireless Receiver Housing, AC Sawmills REF. DESCRIPTION ( Indicates Parts Available In Assemblies Only) PART # HOUSING, AC WIRELESS RECEIVER 534501 BOX WELDMENT 534496-1 GASKET, CORK 534502 PLATE, FRONT 534500-1 WASHER, 5.3 FLAT ZINC F81052-1 BOLT, #10-24X1/2 SELF-TAPPING F05015-7...
