Instruction Manual
Thank you for purchasing the HAKKO FR-410 Desoldering Tool.
Please read this manual before operating the HAKKO FR-410.
Keep this manual readily accessible for reference.
1.
Desoldering Tool
(HAKKO FR-4101)
●
●
Table of Contents
................................................. 1
...................................................... 3
.......................................................... 4
........................................ 7
..................................................... 8
...................... 1
................. 2
...........................11
Advertisement
Related Manuals for Hakko Electronics FR-4101
Summary of Contents for Hakko Electronics FR-4101
-
Page 1: Table Of Contents
Desoldering Tool (HAKKO FR-4101) Instruction Manual ● Thank you for purchasing the HAKKO FR-410 Desoldering Tool. Please read this manual before operating the HAKKO FR-410. Keep this manual readily accessible for reference. ● Table of Contents PACKING LIST AND PART NAMES ...... 1 2. SPECIFICATIONS ..........1 3. WARNINGS, CAUTIONS AND NOTES ....2 4. INITIAL SETUP ............3 5. OPERATION ............4 6. -
Page 2: Packing List And Part Names
1. PACKING LIST AND PART NAMES Please check to make sure that all items listed below are included in the package. HAKKO FR-410 Desoldering station HAKKO FH-410 Handpiece holder HAKKO FR-4101 Desoldering Handpiece Tool box with N61-05 (ø1.0mm [0.04 in]) nozzle Instruction Manual Power cord Nozzle (N61 series) Filter pipe... -
Page 3: Warnings, Cautions And Notes
3. WARNINGS, CAUTIONS AND NOTES Warnings, cautions and notes are placed at critical points in this manual to direct the operator’s attention to significant items. They are defined as follows: WARNING：Failure to comply with a WARNING may result in serious injury or death. CAUTION ：Failure to comply with a CAUTION may result in injury to the operator, or damage to the items involved. NOTE：A NOTE indicates a procedure or point that is important to the process being described. WARNING When power is ON, the nozzle will be hot. To avoid injury or damage to personnel and items in the work area, observe the following: Do not touch the nozzle or the metal parts near the nozzle. -
Page 4: Initial Setup
4. INITIAL SETUP A. Handpiece holder Loosen the adjusting screws to change the angle of the handpiece receptacle as you like, then tighten the screws. CAUTION Increasing the angle of the handpiece receptacle will cause an increase in the handpiece temperature. ●... -
Page 5: Operation
Connect the plug to the receptacle, aligning the tab on the plug with the opening on the receptacle. 3. Set the HAKKO FR-4101 in the handpiece holder. 4. Connect the hose from the HAKKO FR-4101 to the vacuum outlet cap on the HAKKO Connect the hose. - Page 6 A. Desoldering Nozzle CAUTION If the pump does not operate, immediately clean the nozzle & heating element and replace the filter Board if necessary. Solder Lead 1. Place the nozzle over the lead wire of the part to be desoldered and begin heating. Be careful to heat the lead wire and the solder, not the land.
- Page 7 3. Make your SELECTION by moving the cursor UP or DOWN 4. Press the <ENT> button to by pressing the corresponding finalize your selection. buttons. PRESET1 350℃ PRESET1 350℃ PRESET2 400℃ PRESET2 400℃ PRESET3 450℃ PRESET3 450℃ <↑> <↓> <ENT> <↑>...
-
Page 8: Parameter Setting
3. Make your SELECTION by moving the cursor UP or DOWN 4. Press the <ENT> button to by pressing the corresponding finalize your selection. buttons. Set Temp Set Temp Offset Temp Offset Temp Vacuum Check Vacuum Check <↑> <↓> <ENT> <↑>... -
Page 9: Maintenance
※Operation procedure for parameter setting Use <↑>, <↓>, and <ENT> to set parameters as you do in the operation settings. When you are finished, press the <ENT> button in the parameter setting screen to return to the normal display. 7. MAINTENANCE Properly maintained, the HAKKO FR-410 desoldering tool should provide years of good service. -
Page 10: Nozzle Maintenance
Nozzle Maintenance CAUTION The desoldering tool may be extremely hot. During maintenance, please work carefully. 1. Inspect and clean the nozzle ● Turn the power switch ON and let the nozzle Cleaning with the nozzle cleaning pin heat up. The cleaning pin passes completely through the CAUTION hole. -
Page 11: Replace The Filters
2. Disassemble the heating element. Remove the element cover assembly and the nozzle with the provided wrench. CAUTION The element cover assembly is held to The heating element is the nozzle changing very hot during operation. tool by pressing this part from both sides. Heating (The nozzle is not Element cover Element held to the nozzle changing tool. Be careful when removing them.） Nozzle 3. -
Page 12: Trouble Shooting Guide
8. TROUBLE SHOOTING GUIDE WARNING Before checking the inside of the HAKKO FR-410 or replacing parts, be sure to disconnect the power plug. Failure to do so may result in electric shock. ● Display does not turn CHECK Is the power supply cable or connection plug disconnected? ACTION : Connect it tightly.
