ASEM 6300B-EW1 and 6300P-
EW1 Entry Level Industrial
Computers
Catalog Numbers 6300B-EW1, 6300P-EW1
User Manual
Original Instructions

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Allen-Bradley ASEM 6300B-EW1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Rockwell Automation Allen-Bradley ASEM 6300B-EW1

  • Page 1 ASEM 6300B-EW1 and 6300P- EW1 Entry Level Industrial Computers Catalog Numbers 6300B-EW1, 6300P-EW1 User Manual Original Instructions...
  • Page 2: Important User Information

    If this equipment is used in a manner not specified by the manufacturer, the protection provided by the equipment may be impaired. In no event will Rockwell Automation, Inc. be responsible or liable for indirect or consequential damages resulting from the use or application of this equipment.
  • Page 3: Table Of Contents

    Site requirements ........... . . 29 Rockwell Automation Publication 6300-UM003A-EN-P - October 2024...
  • Page 4 Create/Verify a FAT32-formatted USB Drive ....... 61 Rockwell Automation Publication 6300-UM003A-EN-P - October 2024...
  • Page 5 Disposal ..............88 Rockwell Automation Publication 6300-UM003A-EN-P - October 2024...
  • Page 6 Table of Contents Notes: Rockwell Automation Publication 6300-UM003A-EN-P - October 2024...
  • Page 7: Preface

    6300B wall mount Box PC low profile with no add-on slots and no expansion slot (SL) 6300B-EW1xB 6300B wall mount Box PC standard profile with add-on slots and no expansion slot (S0) 6300B-EW1xC 6300B wall mount Box PC standard profile with add-on slots and one expansion slot (S1) Rockwell Automation Publication 6300-UM003A-EN-P - October 2024...
  • Page 8: Panel Pc Catalog Number Explanation

    APP Software Optix License Branding Cod. Description Cod. Description Cod. Description Cod. Description Cod. Description Cod. Description Windows 10 IoT Enterprise LTSC 2021 on M.2 SSD Brandless on 2.5 in. SSD on CFast Rockwell Automation Publication 6300-UM003A-EN-P - October 2024...
  • Page 9: Box Pc Catalog Number Explanation

    Windows 10 IoT Enterprise LTSC 2021 on M.2 SSD 2x Serial Ports 1x RVL on 2.5 in. SSD 2x USB 1x DisplayPort on CFast APP Software Optix License Branding Cod. Description Cod. Description Cod. Description Brandless Rockwell Automation Publication 6300-UM003A-EN-P - October 2024...
  • Page 10: Acronyms

    6300 Industrial Computer Specifications Technical Data, publication Provides technical specifications. TD001 Industrial Automation Wiring and Grounding Guidelines, publication 1770-4.1 Provides general guidelines for installing a Rockwell Automation industrial system. Product Certifications website, https://rok.auto/certifications Provides declarations of conformity, certificates, and other certification details. Ethernet Reference Manual, ENET-RM002 Describes basic Ethernet concepts, infrastructure components, and infrastructure features.
  • Page 11: Overview

    Resolution up to Full HD. • Aluminium (AF), aluminium True Flat (AT) and stainless steel True Flat (SR) front panels with resistive touchscreen. • Aluminium and True Flat glass front panels with capacitive back-projected multitouch touchscreen (GL). Rockwell Automation Publication 6300-UM003A-EN-P - October 2024...
  • Page 12: Bezels

    Low Profile Stainless steel IP69K bezel with single touch resistive touchscreen (SR). • Standard Profile Aluminum bezel with USB port and single touch resistive touchscreen (AF). • Low Profile Aluminum True Flat bezel with USB port and single touch resistive touchscreen (AT). Rockwell Automation Publication 6300-UM003A-EN-P - October 2024...
  • Page 13 6300P-EW1xxxD - Stainless steel IP69K bezel with single touch resistive touchscreen (SR) Sizes available * 12.1 in. W 15.6 in. W 18.5 in. W 21.5 in. W 24.0 in. W * not available on S1 version Rockwell Automation Publication 6300-UM003A-EN-P - October 2024...
  • Page 14: Touchscreen (Af)

    Frame: EN AW-5754, H22 EN 485-1. Figure 4 - Construction detail Description Aluminum Frame 5 wires resistive touchscreen Glass Seal IMPORTANT The 12.1 W in. display is not available for systems with S1 configuration Rockwell Automation Publication 6300-UM003A-EN-P - October 2024...
  • Page 15: Touchscreen (At)

    Frame: Aluminum alloy 5754. Figure 7 - Construction detail. Description Tempered glass P-CAP capacitive multitouch touchscreen Aluminum frame Seal IMPORTANT The 12.1 W in. display is not available for systems with S1 configuration Rockwell Automation Publication 6300-UM003A-EN-P - October 2024...
  • Page 16 (Kimoto Elastodur ED AG10) 5 wires resistive touchscreen Tempered true flat glass Stainless steel frame Seal IMPORTANT The 12.1 W in. display is not available for systems with S1 configuration Rockwell Automation Publication 6300-UM003A-EN-P - October 2024...
  • Page 17 USB port: protected by an anti-flame silicone rubber cover. The silicone rubber is soft enough, to guarantee an IP65 degree of protection, when completely closed. Figure 13 - Construction detail. Description Aluminium frame 5 wires resistive touchscreen Glass Seal Rockwell Automation Publication 6300-UM003A-EN-P - October 2024...
  • Page 18 USB port: protected by an anti-flame silicone rubber cover. The silicone rubber is soft enough, to guarantee an IP65 degree of protection, when completely closed. Figure 16 - Construction detail Description Top polyester film 5 wires resistive touchscreen Glass Aluminum frame Seal Rockwell Automation Publication 6300-UM003A-EN-P - October 2024...
  • Page 19: Slim, Slot 0, Slot 1 Depth

    S1 (slot one) version has add-on slots and one expansion slot. Slot 1 - 6300P-EW1*****C Slot 1 - 6300B-EW1*C Description Add-On position A Add-On position B Expansion Slot NOTE: the 12.1 W in. display is not available for systems S1 (slot one) Rockwell Automation Publication 6300-UM003A-EN-P - October 2024...
  • Page 20: Back View

    On the side part of all the systems there are CFast / Battery slot and all around the aeration holes and the recess for the fixing clips. Side view Description CFast / Battery Slot Aeration holes Recess for fixing clips Rockwell Automation Publication 6300-UM003A-EN-P - October 2024...
  • Page 21: Add-On Positon A / B Expansion Slot

    1x RVL (RJ45) 1x Gigabit Ethernet (RJ45) + 1x USB 2.0 (Type-A) 1x DisplayPort Expansion Slot (C): • 1x PCI half-length, on riser card or • 1x PCIe x4 half-length, on riser card Rockwell Automation Publication 6300-UM003A-EN-P - October 2024...
  • Page 22: Technical Data

    (max 1) 1 x DisplayPort++ V1.4a Expansion Slots S1 version only 1x PCI half-length or 1x PCIe x4 half-length, on riser card (max 5W) Novram (optional) 512 Kb MRAM module for retentive variables Rockwell Automation Publication 6300-UM003A-EN-P - October 2024...
  • Page 23: Approximate Dimensions

    5 : 4 55.8 [2.19] [17.91] [13.97] [0.81] [0.23] [17.12] [13.18] 76.8 [3.02] 28.4 [1.11] 490.0 388.0 22.8 470.0 368.0 19.0 6300P-EW119G 5 : 4 55.8 [2.19] [19.29] [15.27] [0.89] [0.23] [18.50] [14.48] 76.8 [3.02] Rockwell Automation Publication 6300-UM003A-EN-P - October 2024...
  • Page 24 Table 9 - System Configuration (Catalog Builder reference) Reference Configuration Slim (no Add-On slots and no Expansion slot) Slot 0 (yes Add-On slots and no expansion slot) Slot 1 (yes Add-On slots and yes expansion slot) Rockwell Automation Publication 6300-UM003A-EN-P - October 2024...
  • Page 25: Box Pcs Dimensions

    80:80/70:70 89:89/89:89 88:88/88:88 88:88/88:88 85:85/85:85 L:R/U:L (typ.) Contrast ratio 700:1 1000:1 1000:1 2500:1 800:1 Response Time (Rise/Fall) ms Backlight LED life time min. (h) 50000 50000 50000 50000 50000 Aspect Ratio 16:10 16:9 Rockwell Automation Publication 6300-UM003A-EN-P - October 2024...
  • Page 26 85:85/85:85 89:89/89:89 89:89/89:89 L:R/U:L (typ.) Contrast ratio 1000:1 1000:1 1500:1 5000:1 5000:1 Response Time (Rise/Fall) ms Backlight LED life time min. (h) 50000 50000 70000 50000 50000 Aspect Ratio 16:9 16:9 16:9 16:9 Rockwell Automation Publication 6300-UM003A-EN-P - October 2024...
  • Page 27: Installation

    All Panel PCsare shipped with a gasketed bezel to meet specified NEMA, UL Type, and IEC IP ratings only when mounted in a panel or enclosure with an equivalent rating Rockwell Automation Publication 6300-UM003A-EN-P - October 2024...
  • Page 28: Ul/Cul Mark Compliance

    Consider a user-supplied fan, heat exchanger, or air conditioner for heat generated by other devices in the enclosure. • For installation in control cabinets and, in particular, in closed containers, make sure the ambient temperature complies with the requirements. Rockwell Automation Publication 6300-UM003A-EN-P - October 2024...
  • Page 29: Working On The Control Cabinet

    X direction ≥ 50 mm (1.96 in.) • Y direction ≥ 100 mm (3.93 in.) • Z direction ≥ 50 mm (1.96 in.) Panel Installation min. clearance Installation max. tilt ° ° ° Rockwell Automation Publication 6300-UM003A-EN-P - October 2024...
  • Page 30: Panel Pc Installation

    Adjustable torque driver with 1.5 mm hex key bit. • Safety glasses. • Mounting clips (supplied); for the needed quantity, see Figure 3 on page 17 Supplied tools Sequence No. Dscription Clip Hexagonal key Rockwell Automation Publication 6300-UM003A-EN-P - October 2024...
  • Page 31: Mount (Panel Pc Only)

    From the front of the panel insert the computer into the cutout (A) and rotate it (B) until it adheres completely to the panel (C). • Slide the mounting clips into the holes on all four sides of the computer and repeat the following procedure for all the clips. Rockwell Automation Publication 6300-UM003A-EN-P - October 2024...
  • Page 32: Box Pc Installation

    Figure 17 - Mounting clips tighten and torque sequence by display size ATTENTION: tighten the mounting clips to the specified torque to provide a proper seal and to help prevent product damage. Rockwell Automation assumes no responsibility for water or chemical damage to the computer or other equipment within the enclosure because of improper installation.
  • Page 33: Installation

    M4x20 stainless steel screws to the nuts as in the picture above. • Align the bottom two screws. • Slide your Box PC downward until all four M4x20 stainless steel screws are at the top of each bracket slot. Rockwell Automation Publication 6300-UM003A-EN-P - October 2024...
  • Page 34: Grounding And Bonding

    Insert the stripped end (2) of the grounding wire (1) into the open end of the Eyelet terminal (3) and crimp it securely to the wire. • Install the ground wire to the ground screw in the following sequence. Rockwell Automation Publication 6300-UM003A-EN-P - October 2024...
  • Page 35: Dc Power Supply Guidelines

    - Iin= 2.4A max. @24V (nominal voltage). - Iin= 3.3A max. @18V (min. voltage). - Iin= 1.8A max. @32V (max. voltage). Inrush current Symbol Definition 6300P-EW1 6300B-EW1 Peak current Pulse width time 2 ms 2 ms Rockwell Automation Publication 6300-UM003A-EN-P - October 2024...
  • Page 36: Power Consumption

    All DC powered computer models require a safety extra low voltage (SELV) power supply. The power supply is internally protected against reverse polarity. To minimize ground loop currents and noise, Allen-Bradley recommends that DC powered computer models use only one grounded connection. Rockwell Automation Publication 6300-UM003A-EN-P - October 2024...
  • Page 37: Required Tools

    Slide the connector half with the attached tie onto the end of the DC terminal block [step (B)]. • Tighten the tie and remove the excess part [step (C)]. • Install the white labels (9) supplied with the terminal block cover kit [steps (D) (E)]. Rockwell Automation Publication 6300-UM003A-EN-P - October 2024...
  • Page 38: Install The Factory-Supplied Metal Retention Plates To Connect Ethernet Cables

    Insert the zip tie around the LAN cable and the beveled edge of the plate, Tighten the tie (2) and remove the excess part(1) [step (C)]. • Tighten the tie (2) and remove the excess part [step (D)] Rockwell Automation Publication 6300-UM003A-EN-P - October 2024...
  • Page 39: Operation

    All the systems in SL version, catalog numbers 6300P-EW1*****A and 6300B-EW1*A, when turned on can have an hot surface. BURN HAZARD: Hot surface. When the system is turned on the surface can be hot. Be careful before handling the system for maintenance. Rockwell Automation Publication 6300-UM003A-EN-P - October 2024...
  • Page 40: Touch Screen Precautions

    The picture below shows 6300B-EW1*C (6300P-EW1xxxxxC is the Panel PC version), that is the full option. Rear Panel areas Description Power supply area Connectors area Buttons /LEDs area Add-On positon A Add-On position B Expansion Slot Rockwell Automation Publication 6300-UM003A-EN-P - October 2024...
  • Page 41: Power Supply Area

    The ATX mode push button command, according to the operating system settings, allows the system the following operations: - soft off; - suspend; - restart; Function ATX+ ATX- + (24V) - (0V) The following picture shows a simplified representation of the electrical circuit: Rockwell Automation Publication 6300-UM003A-EN-P - October 2024...
  • Page 42 To Change what happens when you press the power button (refer also to the OS instructions): • Right click the Start button picture of the desktop. • Select Power Options. • The following window will appear. Rockwell Automation Publication 6300-UM003A-EN-P - October 2024...
  • Page 43: Ps / Sys Off Configuration

    0.5A. Function SYS OFF ( System OFF input) PS (Power Status output 0.5A limited) +24V (+ input voltage fused) - (0V) The following picture shows a simplified representation of the electrical circuit: Rockwell Automation Publication 6300-UM003A-EN-P - October 2024...
  • Page 44: How To Use Correctly The Ps And Sus Off Signals In A Typical Plc Application

    • Event 5: - The PLC provides power to the computer. - The bootstrapping doesn’t start because the SYS OFF is high. • Event 6: - The PLC drives SYS OFF to GND. Rockwell Automation Publication 6300-UM003A-EN-P - October 2024...
  • Page 45: Connectors Area

    Green flashing Access to a mass storage device (SSD or CFast) is happening through a SATA channel. LED Mass Storage No access to a mass storage device (SSD or CFast) is happening and O.S. is running. Rockwell Automation Publication 6300-UM003A-EN-P - October 2024...
  • Page 46 IMPORTANT: Use this button only if there are no better options, like keyboard or mouse commands, or if the Reset Button resumed DC power does not restart the computer. System reset can cause data loss and possible corruption to the operating system. Rockwell Automation Publication 6300-UM003A-EN-P - October 2024...
  • Page 47: Power On Modalities

    [SYSTEM OFF] The system turns ON selected ** Cable with external connection to electric bulb and switch [SYSTEM OFF] The system turns ON if the contact is selected open. +24 VDC 0 VDC Rockwell Automation Publication 6300-UM003A-EN-P - October 2024...
  • Page 48: Dip Switch

    Buttons /LEDs on page 45 for details of these LED status indicators. Restart A keyboard and mouse must be connected to perform the following steps. Use either of the following methods to restart your panel PC. Rockwell Automation Publication 6300-UM003A-EN-P - October 2024...
  • Page 49: System Reset

    A keyboard and mouse must be connected to perform the following steps. • Method 1: From the Start menu, click or select Shut Down. • Method 2: Press Ctrl+Alt+Delete, then click or select Shut Down. Rockwell Automation Publication 6300-UM003A-EN-P - October 2024...
  • Page 50 Chapter 3 Operation Notes: Rockwell Automation Publication 6300-UM003A-EN-P - October 2024...
  • Page 51: Configuration Of System Settings

    Manual Start on page 48 Restart on page 48. The POST initiates. 2. Press ‘F2’ to access the setup utility from the POST. To temporarily change the boot order, press F10 to directly access the Boot menu. Rockwell Automation Publication 6300-UM003A-EN-P - October 2024...
  • Page 52: In-Band Error Correction Code (Ibecc)

    • Step 3: Create a Bootable USB drive. Step 1 — Download the Accessory Files You must be registered with the Rockwell Automation PCDC website and accept the User Agreement before you can download files. 1. Navigate to rok.auto/pcdc. Rockwell Automation Publication 6300-UM003A-EN-P - October 2024...
  • Page 53 1. Click the result within the result area (4), then click the Downloads button (5). 2. Click Select Files (6). . IMPORTANT Do not change the file name of the downloaded batch (EXE) file. 3. The Available Downloads popup window appears. Rockwell Automation Publication 6300-UM003A-EN-P - October 2024...
  • Page 54 Configuration of System Settings 4. Select and download the accessory files SYSTEM_IMAGE_EW1- and Backup and Restore. 5. Click on the Downloads Icon (7), the Download Cart (8) will appear 6. Click on Download Now to confirm. Rockwell Automation Publication 6300-UM003A-EN-P - October 2024...
  • Page 55 1. Click the result within the result area (4), then click the Downloads button (5). 2. Click Select Files (6). . IMPORTANT Do not change the file name of the downloaded batch (EXE) file. 3. The Available Downloads popup window appears. Rockwell Automation Publication 6300-UM003A-EN-P - October 2024...
  • Page 56 Configuration of System Settings 4. Select and download the accessory files SYSTEM_IMAGE_EW1- and Backup and Restore. 5. Click on the Downloads Icon (7), the Download Cart (8) will appear 6. Click on Download Now to confirm. Rockwell Automation Publication 6300-UM003A-EN-P - October 2024...
  • Page 57 • installation of a bootable USB utility (such as Rufus). IMPORTANT The steps and graphics below are specific to the Rufus USB utility. 1. Connect the first USB drive (2GB minimum) to your computer. Rockwell Automation Publication 6300-UM003A-EN-P - October 2024...
  • Page 58 8. Click the OK button within the Warning dialogue box. 9. Use the Status portion of the dialog box to monitor the boot progress. 10. Click the Close button once the boot process is complete. Rockwell Automation Publication 6300-UM003A-EN-P - October 2024...
  • Page 59: Back Up The Os Image

    9. Press the Enter key. A confirmation screen appears. 10. Confirm that the targeted drive is correct. 11. Press the ‘Y’ key, then press the Enter key. The following script appears after the back- up process has completed. Rockwell Automation Publication 6300-UM003A-EN-P - October 2024...
  • Page 60: Restore The Os Image

    7. In the directory, type ‘RestoreImageUEFI.bat NameFile.wim’ where NameFile is the name of the file that you wish to restore. EXAMPLE Correct character structure example of a wim file: D:\RestoreImageUEFI.bat System_Image- PanelPC_6300_windows_10_2020_LTSC.wim Rockwell Automation Publication 6300-UM003A-EN-P - October 2024...
  • Page 61: Update The Uefi Bios

    2. In File Explorer, right-click on the USB drive icon then select Properties. 3. In Properties, verify that the file system type is FAT32. 4. Click the Cancel button to close the Properties popup window. Rockwell Automation Publication 6300-UM003A-EN-P - October 2024...
  • Page 62: Download The Updated Uefi Files

    9. Click the OK button. Download the Updated UEFI files You must be registered with the Rockwell Automation PCDC website and accept a User Agreement before you can download the files. To download the updated UEFI files, perform the following steps.
  • Page 63 6. Click Select Files (6) under Downloads. An Available Downloads popup window appears. IMPORTANT Do not change the file name of the downloaded batch (EXE) file. 7. The Available Downloads popup window appears. Rockwell Automation Publication 6300-UM003A-EN-P - October 2024...
  • Page 64 Configuration of System Settings 8. Select and download the BIOS files: - UEFI-EFI-Shell-Files-EW1 - UEFI_8922107A0x 9. Click on Downloads icon, the Download Cart (8) will appear. 10. Click on Download now (9) to confirm. Rockwell Automation Publication 6300-UM003A-EN-P - October 2024...
  • Page 65 17. Click Select Files (6) under Downloads. An Available Downloads popup window appears. IMPORTANT Do not change the file name of the downloaded batch (EXE) file. 18. The Available Downloads popup window appears. Rockwell Automation Publication 6300-UM003A-EN-P - October 2024...
  • Page 66 Configuration of System Settings 19. Select and download the BIOS files: - UEFI-EFI-Shell-Files-EW1 - UEFI_8922107A0x 20. Click on Downloads icon, the Download Cart (8) will appear. 21. Click on Download now (9) to confirm. Rockwell Automation Publication 6300-UM003A-EN-P - October 2024...
  • Page 67: Update Uefi Files

    3. During POST, press the F2 key to access the SETUP utility. 4. Use the right (6) arrow to toggle over to the ‘Advanced’ menu. 5. Use the down (2) arrow to toggle down to ‘PCH-FW Configuration’, then press the Enter key. Rockwell Automation Publication 6300-UM003A-EN-P - October 2024...
  • Page 68 To verify you moved to the USB drive, use the command ‘dir’ to confirm that the downloaded files are there. 16. To update the UEFI, type “AfuEfix64.efi "NAME_OF_THE_BIN_FILE.bin" /x /me /p /b /n”. Rockwell Automation Publication 6300-UM003A-EN-P - October 2024...
  • Page 69: Restore Uefi Factory Defaults Through A Dip Switch

    Shut Down on page 2. Remove the cover from your computer. See Cover Screw Locations on page 3. Locate the DIP switch bank SW3. 4. Move switch 3 of bank to the ON (factory reset) position. Rockwell Automation Publication 6300-UM003A-EN-P - October 2024...
  • Page 70 12. During the POST, press the F2 key to enter the UEFI SETUP utility. 13. Toggle over to the Save and Exit menu. 14. Toggle down or press the F9 key to select ‘Optimized Defaults’. 15. Press F10 to save and exit the SETUP utility. Rockwell Automation Publication 6300-UM003A-EN-P - October 2024...
  • Page 71: Change Settings In Bios Uefi Firmware

    OS (such as Linux), or real-time environment (such as Codesys). - these are considered an untrusted source where you may receive a secure boot violation. • using additional hardware with boot ROM (such as graphic cards or RAID controllers). Rockwell Automation Publication 6300-UM003A-EN-P - October 2024...
  • Page 72 Ctrl+Alt+Delete on an attached keyboard and select ‘Restart.’ 2. Press the ‘F2’ key. An initial setup screen appears. 3. Navigate over to the ‘Security’ menu. 4. Select “Secure Boot” and press Enter. 5. Select “Disabled”. Rockwell Automation Publication 6300-UM003A-EN-P - October 2024...
  • Page 73: Enable Thinmanager

    4. Select ‘ThinManager’ as ‘Boot Option #1’ for the boot option priority. 5. Navigate over to the ‘Save and Exit’ menu. 6. Select ‘OK’, then press the ‘F10’ key to save and exit the BIOS. Rockwell Automation Publication 6300-UM003A-EN-P - October 2024...
  • Page 74 Chapter 5 Change Settings in BIOS UEFI Firmware Notes: Rockwell Automation Publication 6300-UM003A-EN-P - October 2024...
  • Page 75: Maintenance And Service

    Transport your PC and replacement parts in static-safe containers, such as conductive tubes, bags, or boxes. • Keep electrostatic-sensitive parts in their containers until they arrive at the designated static-free work area. • Cover the designated work area with approved static-dissipating material: Rockwell Automation Publication 6300-UM003A-EN-P - October 2024...
  • Page 76: Burn Hazard

    2. Use a clean sponge or a soft cloth dampened with water to wipe the surfaces of your panel PC. 3. Dry the display with a chamois or moist, cellulose sponge to avoid water spots. Rockwell Automation Publication 6300-UM003A-EN-P - October 2024...
  • Page 77: Cfast / Battery Slot

    Unscrew the CFast / Battery Slot fixing screw (1). • Remove the cover (2). Now you have access to the CFast slot (2) and the Battery Slot (1). CFast /Battery Slot position Description Battery tray Slot CFast Slot Rockwell Automation Publication 6300-UM003A-EN-P - October 2024...
  • Page 78: Battery Removal / Installation

    Put inside the tray a new Lithium CR2032 3V battery with the positive polarity facing UP. • Insert the tray with the new battery in the battery slot (1) and push all the way (2). Rockwell Automation Publication 6300-UM003A-EN-P - October 2024...
  • Page 79: Cfast Removal / Installation

    Insert (push) the CFast card into the slot (1). • Push it all the way and release (2). • The CFast is correctly installed (3). Removal • Push and release the inserted CFast card (1). • CFast is now released (2). Rockwell Automation Publication 6300-UM003A-EN-P - October 2024...
  • Page 80: Remove/Reinstall The Cover

    1. Follow the steps for Prepare for Maintenance and Service on page 2. Depending of the model, use the appropriate screwdriver to remove the screws from the back cover of your PC. 3. Remove the cover. Rockwell Automation Publication 6300-UM003A-EN-P - October 2024...
  • Page 81: Reinstall The Cover

    Prepare for Maintenance and Service on page • Perform all the steps in Remove/Reinstall the Cover on page Required Tools • Philips screwdriver. Installation • To remove the bracket (1) slightly unscrew the screw (2) and pull left. Rockwell Automation Publication 6300-UM003A-EN-P - October 2024...
  • Page 82 Screw the screw (2) and pull right to fix the retainer. • Press the retainer lever (7) to the installed card. • Screw the knob retainer screw (5) to fix the retainer lever. Rockwell Automation Publication 6300-UM003A-EN-P - October 2024...
  • Page 83: Front Usb 2.0

    With your finger, pull the cover at the shown position. • Then, press the cover up/down edges, which assumes the required IP66 degree of protection. • Verify that all edges perfectly adhere the hole. Rockwell Automation Publication 6300-UM003A-EN-P - October 2024...
  • Page 84 Chapter 6 Maintenance and Service Notes: Rockwell Automation Publication 6300-UM003A-EN-P - October 2024...
  • Page 85: Troubleshooting

    Test the outlet by plugging in a properly functioning device. Replace the suspected faulty cable or power cord. Have the monitor serviced. Out of Range Check the maximum resolution and the frequency on the video port of your panel PC. Rockwell Automation Publication 6300-UM003A-EN-P - October 2024...
  • Page 86 The video mode could be out of range. Change to the recommended resolution; Picture is not clear symptom. Screen jitter or noisy video Check for proper video cable installation. Replace the suspected faulty cable. Reroute the cables or replace suspected faulty cables. Rockwell Automation Publication 6300-UM003A-EN-P - October 2024...
  • Page 87: System Default Options

    (4) place it in its original packing material. Rockwell Automation is not responsible for damage when it is shipped or transported while installed in a machine, panel, or rack and if it is not placed in its original packing material.
  • Page 88: Disposal

    When a storage drive is part of your disposal, permanently erase any data on it or destroy the drive before disposing of it. Rockwell Automation Publication 6300-UM003A-EN-P - October 2024...
  • Page 89 ASEM 6300B-EW1 and 6300P-EW1 Entry Level Industrial Computers User Manual Rockwell Automation Publication 6300-UM003A-EN-P - October 2024...
  • Page 90: Rockwell Automation Support

    At the end of life, this equipment should be collected separately from any unsorted municipal waste. Rockwell Automation maintains current product environmental compliance information on its website at rok.auto/pec. Allen-Bradley, ASEM, expanding human possibility, FactoryTalk, Rockwell Automation, and ThinManager are trademarks of Rockwell Automation, Inc. Aptio is a trademark of AMI (American Megatrends Inc.).
