Rockwell Automation ASEM 6300B Series Installation Instructions Manual

Installation Instructions
Original Instructions
ASEM 6300B Box PCs and 6300T Thin Clients
Catalog Numbers 6300B-xxA, 6300B-AB0, 6300B-BMB, 6300B-SB0, 6300B-xxF, 6300B-xxN, 6300T-BA, 6300T-BB
The following catalog numbers are ASEM™ 6300B Edge Box PCs intended for use with FactoryTalk® Edge™ Manager:
• 6300B-BMBDNE-3DBAE01FNNBNN-NN1S
• 6300B-BMBDNE-7EDAE01FNNDNN-NN1S
These catalog numbers have a unique Edge Virtualization Engine operating system (EVE-OS) orchestrated from FactoryTalk Edge Manager. If you have sent
the product to be returned or repaired, the device software and data has been erased and the EVE-OS has been reinstalled. For more information on
FactoryTalk Edge Manager, see publication
Topic
Summary of Changes
Compliance
Environment Requirements
Hazardous Locations
Installation Requirements
Mount the Product
Connect the DC Power Wiring
Technical Data
Additional Resources

Summary of Changes

This publication contains the following new or updated information. This list includes substantive updates only and is not intended to reflect all changes.
Topic
Updated Hazardous Locations information
Add 6300B-AB0/SB0/SB0 catalog numbers

Compliance

UL/cUL Mark Compliance
Equipment with the UL/cUL mark complies with the requirements of UL 121201, UL 61010-1, UL 61010-2-201, CSA C22.2 No. 213, CSA C22.2 No 61010-1, and
CSA C22.2 No. 61010-2-201. A copy of the certificate of compliance is available at rok.auto/certifications.
European Union and UK Directive Compliance
This equipment meets the European Union and UK Directive requirements when installed within the European Union, UK, or EEA regions and have the CE or UK marking.
A copy of the declaration of the conformity is available at rok.auto/certifications.
ATTENTION: This equipment is intended to operate in an industrial or control room environment, which uses some form of power isolation from the
public low-voltage mains. Some computer configurations cannot comply with the EN 61000-3-2 Harmonic Emissions standard as specified by the
EMC Directive of the European Union or UK.
All I/O cables must be used only indoors.
• 6300B-BMBDNE-3DBAE01NNNBNN-NN1S
• 6300B-BMBDNE-7EDAE01NNNDNN-NN1S
95055-UM007-EN-P and publication 95055-QS003-EN-P.
