- Page 1 Banded Shade Collection Smart Shades Installation Instructions Rev. D 04/24...
-
Page 2: Table Of Contents
CONTENTS Smith & Noble offers the Internal Rechargeable Battery, Rechargeable Battery Wand and Satellite Rechargeable Battery Wand power options on Smart Shades. TOOLS AND FASTENERS NEEDED ..................3 STEP 1: MOUNT THE INSTALLATION BRACKETS ..............4 Mounting Types and Window Terminology ..................4 Mount the Cassette Installation Brackets —... - Page 3 CONTENTS TROUBLESHOOTING ......................18 Removing the Rechargeable Battery Wand from the Mount ............20 Recharging Via the Dual Charging Station ................... 20 Recharging Via the Single Charger ....................21 Reinserting the Rechargeable Battery Wand into the Mount ............22 REMOVING THE SHADE ......................23 Remove the Cassette ........................
-
Page 4: Getting Started
GETTING STARTED Product View Cassette Installation Brackets Cassette Bottom Bar End Cap... - Page 5 GETTING STARTED Product View Profile Installation Brackets Profile Headrail Profile Side Bracket Bottom Endcap...
-
Page 6: Tools And Fasteners Needed
GETTING STARTED Thank you for purchasing Smith & Noble Banded Shades with Smart Shades. With proper installation, operation, and care, your ® new shades will provide years of beauty and performance. Please thoroughly review this instruction booklet before beginning the installation. Tools and Fasteners Needed Flat blade and Phillips screwdrivers ■... -
Page 7: Step 1: Mount The Installation Brackets
INSTALLATION INSTALLATION Installation Overview caution: Keep the “Do Not Remove Until Installation” paper wrap in place, until the shade is completely installed. These instructions will remind you when to remove the wrap. Your order will include installation brackets specific to your shade. The number of installation brackets required varies with shade width, as shown in the tables below. -
Page 8: Mount The Cassette Installation Brackets - Inside Mount
INSTALLATION INSTALLATION Mount the Cassette Installation Brackets — Inside Mount Mark 4" in from each jamb for bracket location. If more than two installation brackets came with your order, space additional bracket(s) evenly between the two end brackets and mark their location. Mount into wood whenever possible. Min. -
Page 9: Install The Back Cover (Optional)
INSTALLATION INSTALLATION Angle the back cover towards the window to hook the top feature of the back ■ Cassette Bracket Back Cover Clip cover with the top tab of the clip. Rotate the back cover towards the room until the bottom feature snaps into ■... -
Page 10: Inside Mount For Profile
INSTALLATION INSTALLATION IMPORTANT: The front edges of the installation brackets must be level and aligned to 4" each other. Drill the screw holes with a " drill bit. ■ ⁄ Use a level to check that the mounting surface is level. Shim the brackets if necessary. ■... -
Page 11: Step 2: Install The Battery Wand (Cassette Only, If Applicable)
INSTALLATION INSTALLATION Use a " drill bit to drill holes for the mounting screws. ⁄ ■ Attach the installation brackets using the screws provided. ■ Important: The front edges of the installation brackets must be level and aligned to each other. ■... -
Page 12: Step 3: Install The Shade
INSTALLATION INSTALLATION Install the Rechargeable Battery Mount into the Battery Wand Clips From the back of the shade headrail, connect the power cable from the motor side into the socket on the rechargeable ■ battery mount. Align the slots in the battery mount with the battery wand clips. ■... -
Page 13: Install Profile
INSTALLATION INSTALLATION Install Profile The groove on the top of the mounting profile fits into the hooks on the installation brackets. Inside or Ceiling Mount Outside Mount Hook Hook Bracket Bracket Mounting Mounting Profile Profile Hold the shade so the bottom bar fabric side faces you. ■... -
Page 14: Satellite Battery Pack
INSTALLATION INSTALLATION Satellite Battery Pack Decide where you want to mount the bracket(s). A satellite battery pack may be mounted in any orientation. ■ Mark the screw holes. ■ Bracket for the Satellite Battery Pack Drill the screw hole using a 3⁄32" drill bit. ■... -
Page 15: Satellite-Mounted Rechargeable Battery Wand
INSTALLATION INSTALLATION Satellite-Mounted Rechargeable Battery Wand Determine the location to mount the rechargeable battery wand. ■ CAUTION: To prevent overheating, do not install the rechargeable battery wand in direct sunlight. The battery mount may be installed in any orientation. ➤ Plan placement of the battery mount so that the cable can be plugged into the power socket. - Page 16 INSTALLATION INSTALLATION Install the Battery Wand into the Battery Mount NOTE: The rechargeable battery wand ships fully charged, so it is ready to install out of the package. Match the direction of the arrow on the underside of the battery wand with the arrow on the battery mount. ■...
-
Page 17: Double Connector Power Cable (If Applicable)
INSTALLATION INSTALLATION Double Connector Power Cable (If Applicable) NOTE: Refer to this section only if you have a double connector power cable. Install the Batteries into the Battery Wand or Satellite Battery Pack Refer to "Replace the batteries in the battery wand." on page 22. ■... -
Page 18: Step 5: Deactivate Ship Mode - Internal Rechargeable Battery Only
INSTALLATION INSTALLATION Step 5: Deactivate Ship Mode - Internal Rechargeable Battery Only All internal rechargeable battery shades arrive out of the packaging in Ship Mode and will not operate. Ship Mode must be deactivated before use. Using a flathead screwdriver, press and release the control button. -
Page 19: Operating The Smart Shades App And Remote
INSTALLATION OPERATION Operating the Smith & Noble® App and Smart Shades Remote Syncing and Programming Your Remote Activate the remote by pulling both plastic tabs from the back battery compartment. ■ Download the Smith & Noble App for your smartphone or tablet at getsmithandnobleapp.com ®... -
Page 20: Further Operation And Programming Information
INSTALLATION OPERATION Further Operation and Programming Information Smith & Noble® App The Smith & Noble App is required to program Smart Shades window coverings, remotes, and gateways. The App is ® compatible with Apple and Android™ smartphones and tablets. For more information regarding setup and operation using ®... -
Page 21: Troubleshooting
INSTALLATION TROUBLESHOOTING Troubleshooting If your shade is not operating correctly: Review the digital support guide for your control device. ■ Refer to the following troubleshooting procedures below for the specific solutions for your shade. ■ If questions remain, please contact Smith & Noble Consumer Support at 888-214-2134. Problem The shade will not fit into the installation brackets. - Page 22 INSTALLATION TROUBLESHOOTING Problem The shade will not set a new bottom limit or the limit will not save. Solution Raise the shade to the fully open position, the shade may touch the ■ hard stop. Lower the shade to the fully lowered position, the shade may stall on bottom hard limit. ■...
-
Page 23: Removing The Rechargeable Battery Wand From The Mount
INSTALLATION TROUBLESHOOTING Problem Rechargeable battery wand needs recharging. Solution There are two methods for charging the rechargeable battery wand — the dual charging station or the single charger. CAUTION: The rechargeable battery wand can only be charged with these Smith & Noble provided charging ®... -
Page 24: Recharging Via The Single Charger
INSTALLATION TROUBLESHOOTING Problem Rechargeable battery wand needs recharging (continued). Solution Recharging Via the Single Charger Remove the rechargeable battery wand from the mount, or insert the single charger cable without removing from the shading. Attach the plug adapter to the charger. ■... -
Page 25: Reinserting The Rechargeable Battery Wand Into The Mount
INSTALLATION TROUBLESHOOTING Problem Rechargeable battery wand needs recharging (continued). Solution Reinserting the Rechargeable Battery Wand into the Mount Match the direction of the arrow on the underside of the battery wand with the arrow on the battery mount. Insert the nose of the battery wand into the cavity of the battery mount. Push the battery wand flush into the mount until the battery snaps into place. -
Page 26: Removing The Shade
INSTALLATION CARE Removing the Shade Remove the Cassette Move the shade to the fully raised position and disconnect the power. ■ While keeping one hand on the cassette at all times, push up on the plastic release tabs of the bracket until you hear it click ■... -
Page 27: Declarations
INSTALLATION SMITH & NOBLE SMART SHADES MOTOR DECLARATIONS ® DECLARATIONS FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 28: Child Safety
INSTALLATION CHILD SAFETY WARNING ADVERTENCIA Window Blind Cord Strangulation Risk Window Blinds with a damaged or loose tension device or retractable cord that fails to fully retract pose a stangulation risk to children. To avoid this potential strangulation risk, consider purchasing cordless products or products with inaccessible cords. -
Page 29: Year Limited Warranty
10-Year Limited Warranty 10-Year Limited Warranty Smith & Noble is proud to extend a 10-year limited warranty on all Smith & Noble Custom Window Covering products. This Kirsch® is proud to extend a 10-year limited warranty on all Kirsch Custom Window Covering products. This is part ®...
