- Page 1 Bed Scale USER MANUAL MS7800 Please keep the instruction manual at hand and follow instruction for use.
-
Page 3: Table Of Contents
CONTENTS I.Explanation of Graphic Symbols on Label/Packaging 4 II. Copyright Notice ............ 6 III. Safety Notes ............7 General Information ........7 B. EMC Guidance and Manufacturer's Declaration ..10 IV. Preparing to use Device ........15 A. Charging Device..........15 B. -
Page 4: I.explanation Of Graphic Symbols On Label/Packaging
I.Explanation of Graphic Symbols on Label/Packaging Meaning Text/Symbol Caution, consult accompanying documents before use Separate collection for waste of electrical and electronic equipment, in accordance with Directive 2002/96/EC. Do not dispose of device with everyday waste Name and address of device manufacturer, and year/country of manufacture Carefully read user manual before installation and usage, and follow instructions for use. - Page 5 Device complies with EC directives (verified models only) M: Conformity label in compliance with Directive 2014/31/EU for non-automatic weighing instruments 20: Year in which conformity verification was performed and the CE label was applied. (ex: 16=2016) 0122: Identifier for metrology Notified Body Device is a Class III scale in compliance with Directive 2014/31/EU (verified models only) Name and address of entity importing device (if...
-
Page 6: Copyright Notice
Charder Electronic Co., Ltd. (hereinafter Charder) Charder is not liable for any damage caused by a failure to adhere to requirements stated in this manual. Charder reserves the right to correct misprints in the manual without prior notice, and modify the exterior of the device for quality purposes without customer consent. -
Page 7: Safety Notes
III. Safety Notes A. General Information Thank you for choosing this Charder Medical device. It is designed to be easy and straightforward to operate, but if you encounter any problems not addressed in this manual, please contact your local Charder service partner. -
Page 8: Intended User Profile
Intended user profile (a) At least 20 years old (b) Minimum knowledge: - To be able to read at a high-school level and understand Arabic numerals (e.g. 1, 2, 3, 4...) - Basic hygiene knowledge - Trained in device's operation - Read the instruction manual (c) Language - Able to read the language of instruction manual and... - Page 9 Charder service partner, using original Charder accessories and spare parts. Charder is not liable for any damages arising from improper maintenance or usage. Dismantlement of the device will void the warranty.
-
Page 10: Emc Guidance And Manufacturer's Declaration
B. EMC Guidance and Manufacturer's Declaration Guidance and manufacturer’s declaration-electromagnetic emissions The product is intended for use in the electromagnetic environment specified below. The customer or the user of the product should assure that it is used in such an environment. Emission test Compliance Electromagnetic... - Page 11 Guidance and manufacturer’s declaration-electromagnetic immunity The product is intended for use in the electromagnetic environment specified below. The customer or the user of the product should assure that it is used in such an environment. Electromagnetic IEC 00601 Compliance Immunity test environment-guidanc test level level...
- Page 12 Guidance and manufacturer’s declaration-electromagnetic immunity The product is intended for use in the electromagnetic environment specified below. The customer or the user of the product should assure that is used in such and environment. IEC 60601 Compliance Electromagnetic Immunity test test level level environment-guidance...
- Page 13 Field strengths from fixed transmitters, such as base stations for radio (cellular/cordless) telephones and land mobile radios, amateur radio, AM and FM radio broadcast and TV broadcast cannot be predicted theoretically with accuracy. To assess the electromagnetic environment due to fixed RF transmitters, an electromagnetic site survey should be considered.
- Page 14 Recommended separation distance between portable and mobile RF communications equipment and the product The product is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The customer or the user of the product can help prevent electromagnetic interference by maintaining a minimum distance between portable and mobile RF communications equipment (transmitters) and the product as recommended below, according to the maximum output power of the communications equipment.
-
Page 15: Preparing To Use Device
IV. Preparing to use Device A. Charging Device Device should be fully charged before first use. Please allow 8 hours for full charge. When low battery indicator on display appears, please charge battery promptly to avoid battery damage. Charging port is located on underside of device. -
Page 16: Standard Procedure
B. Standard Procedure The device should be used in accordance with standard medical moving and handling procedure. It should be used in the same way as a transfer board, with a short period of time reserved in process to allow device to measure subject weight. SAFETY RULES 1. - Page 17 2. Help subject lie upon measurement platform. Conduct measurement (see Chapter V - Using Device).
- Page 18 3. After weight measurement, transfer subject and remove slide sheet.
-
Page 19: Indicator
V. Indicator A. Key Functions Description Power on or power off. When device is on, press and hold for 3 seconds to turn off. Reset the display to 0.0kg / Zero the scale (within ± 2% of full capacity) Determine stable weighing value - used when weight is unstable. -
Page 20: Using Device
VI. Using Device A. Basic Operation Switch on the device using key. The device will automatically perform self-calibration, displaying software version. Once "0.00 kg" appears on indicator, device is ready for measurement. Note: If "0.00 kg" does not display on indicator, press [ZERO] key to zero the device. -
Page 21: Device Setup
Note: Hold function can be activated before or after subject lies upon platform. However, if subject finds it difficult to hold still, we recommend activating Hold after subject is on platform. VII. Device Setup When device is switched on, press and hold key until appears on display. - Page 22 Press [HOLD] to toggle between on/auto. When "on" is selected, the backlight will always be on. When "Auto" is selected, backlight will be activated when there is a change in weight, or buttons are pressed. Press [ZERO] key to confirm selection. To confirm all setting changes, press [HOLD] key when appears on display.
-
Page 23: Troubleshooting
Warranty Program & Return Policy. 1. If Charder is responsible for a fault or defect present upon receipt of the unit, Charder shall either repair the fault, or supply a replacement unit. Should the repairs or replacement delivery fail, statutory provisions shall be valid. - Page 24 ◼ re-calibration may be required to correct weighing accuracy Distributor support required If the following errors occur, we recommend contacting your local Charder distributor for repair or replacement services: 1. Device will not power on Faulty on/off key ◼ Broken or damaged wires causing short circuit or faulty ◼...
-
Page 25: Error Messages
IX. Error Messages Error Message Reason Action Tilt Error Ensure device is as Device is tilted by 3 level as possible degrees or more before use Low battery Plug in charger or warning replace battery Voltage of battery is too low to operate device Overload Reduce weight on... -
Page 26: Product Specifications
X. Product Specifications Model MS7800 250kg x 0.5kg / Capacity 250kg x 0.5kg 550lb x 1lb ±1.5e ±1.5e Accuracy Weight Unit kg / lb Measurement OIML Class III 27.7 x 75.0 mm Screen Dimensions Overall 1805(W) x 700(D) x 30(H) mm Device Weight 11.4 kg... - Page 27 Notes __________________________________________________ __________________________________________________ __________________________________________________ __________________________________________________ __________________________________________________ __________________________________________________ __________________________________________________ __________________________________________________ __________________________________________________ __________________________________________________ __________________________________________________ __________________________________________________ __________________________________________________ __________________________________________________ __________________________________________________ __________________________________________________ __________________________________________________ __________________________________________________ __________________________________________________ __________________________________________________...
-
Page 28: Declaration Of Conformity
XI. Declaration of Conformity This product has been manufactured in accordance with the harmonized European standards, following the provisions of the below stated directives: (EU) 2017/745 Regulation on Medical Devices 2014/31/EU Non-automatic Weighing Instruments Directive (OIML models only) RoHS Directive 2011/65/EU and Delegated Directive (EU) 2015/863 Radio Equipment Directive 2014/53/EU (applicable if wireless module is used)
