Breeza Video/Film Camera Dolly Slider (DL-BRZA-01)
A s s e m b l y M a n u a l
What's In The Box
Please inspect the contents of your shipped package to ensure you have received everything that is listed
below.
Heavy Duty Sled
75mm Bowl Adapter
Anti-Tilt Safety
Brake
Breeza Dolly
2 x End Spacers
Low-Profile Middle Support
Spacer Washer
100mm Bowl
Flat Mount Plate
Spacer
for Mitchell Mounting
Adapter
All rights reserved.
No part of this document may be reproduced, stored in a retrieval system, or transmitted by any form or by any means,
electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permitted by the applicable copyright
statutes or in writing by the Publisher.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for PROAIM Breeza
Summary of Contents for PROAIM Breeza
- Page 1 Breeza Video/Film Camera Dolly Slider (DL-BRZA-01) A s s e m b l y M a n u a l What’s In The Box Please inspect the contents of your shipped package to ensure you have received everything that is listed below.
-
Page 2: Table Of Contents
2 x T- Type Allen Keys (Sizes: 4mm & 5mm) Bag Packing INDEX Sr. No Particulars Page No. End Spacers Assembly Breeza Dolly Mounting Anti-Tilt Safety Brake Assembly Mount Fluid Head on the Bowl Adapter Flat Mount Plate Mounting Spacer Washer Mounting 8ft Track Setup... -
Page 3: End Spacers Assembly
Breeza Video/Film Camera Dolly Slider Setup End Spacers Assembly • Loosen the knobs of the clamp and then slide up the clamp to easily fit the track. • Insert a 4ft track into the clamp. • Once the track is properly fitted into the clamp, tightly secure it with the knob, as shown in the image. -
Page 4: Breeza Dolly Mounting
Breeza Dolly Mounting • Now place the breeza dolly onto the 4ft track. • The handles part of the dolly platform should be inside of the track as shown. Make sure all wheels are aligned correctly on the track and dolly runs smoothly. -
Page 5: Mount Fluid Head On The Bowl Adapter
• After mounting the fluid head mount a camera (Not Included) on it. NOTE: Breeza Dolly Slider is sturdy enough to take a massive payload. And the end-clamps mount tripods and light stand in seconds. -
Page 6: Flat Mount Plate Mounting
Flat Mount Plate Mounting • To mount the flat plate, first remove the 100mm bowl adapter from the dolly platform. • For this, use an Allen key, loosen all the screws and then take out the 100mm bowl adapter. • Mount the flat plate on the dolly platform. -
Page 7: 8Ft Track Setup
• Then attach the Spacer Washer from bottom side and rotate the castle nut to lock the spacer washer. • Then tighten the knob to secure it. • The Spacer washer is properly attached. • Then lock the height riser by lever. •... -
Page 8: Center Support Spacer Mounting
• The 8ft track is now mounted on the center support spacer. • Now place the breeza dolly onto the 8ft track. • The handles part of the dolly platform should be inside of the track as shown. NOTE: Make sure all wheels are aligned correctly on the track and dolly runs smoothly. -
Page 9: Underslung Camera Setup
Underslung Camera Setup • To mount the camera underslung, attach the bowl adapter aligning the bottom threads, then insert the screws and properly tighten using an Allen key. • Then attach the fluid head to the bowl adapter, as shown in the image. •... - Page 10 YOUR PROAIM BREEZA VIDEO/FILM CAMERA DOLLY SLIDER WITH TRACK ENDS ALL DRESSED UP AND READY TO GO! (SHOWN WITH OPTIONAL ACCESSORIES) Warranty: We offer one year warranty for our products from date of purchase. Within this period of time, we will repair it without charge for labor or parts. Warranty doesn’t cover transportation costs nor does it cover a product subjected to misuse or accidental damage.
