Introduction
The CC2400 single-chip RF transceiver provides a highly integrated, flexible low-cost solution
for applications using the worldwide unlicensed 2.4 GHz frequency band. The CC2400DK
development kit is a powerful and flexible tool specifically designed to make it easy for the
user to evaluate the RF performance of the CC2400 and to minimize the time spent on
evaluation.
The Development Kit includes two Evaluation Boards and two Evaluation Modules. The
Evaluation Modules contain the CC2400 chip and required external components.
The Evaluation Board serves as a motherboard for the Evaluation Modules. The Evaluation
Board provides a USB port, a serial port, buttons, LEDs, voltage regulator, configuration
jumpers and connectors to make it easy to interface the CC2400 with the SmartRF
software and various test equipment.
This User Manual describes how to use the Development Kit. SmartRF
documented in its own user manual.
®
Your SmartRF
CC2400DK Development Kit should contain the following items:
Item
Evaluation Board (CC2400EB)
Evaluation Module (CC2400EM)
Quick Start instructions
Antenna, 50Ω quarter-wave monopole, SMA male connector
SMA to BNC adapters
USB cable
CC2400 sample kit
Kit contents
Number of articles
2
2
1
2
4
2
1
SWRU050
®
Studio
®
Studio is
Page 3 of 35
