Bill of materials, CC2400EM
Reference Description
C1 Capacitor 0603
C11 Capacitor 0402
C61 Capacitor 0402
C62 Capacitor 0402
C71 Capacitor 0402
C81 Capacitor 0402
C101 Capacitor 0402
C161 Capacitor 0402
C251 Capacitor 0402
C261 Capacitor 0402
C411 Capacitor 0402
C421 Capacitor 0402
C431 Capacitor 0402
C481 Capacitor 0402
L61 Inductor 0402
L62 Inductor 0402
L71 Inductor 0402
L81 Inductor 0402
P1 SMD pinrow socket
P2 SMD pinrow socket
P4 Surface-mount
SMA, straight
R1 Resistor 0402
R451 Resistor 0402
U1 Single-chip
transceiver
X1 Crystal, ceramic
SMD 4x25mm
Note: The crystal X1 mounted on the EM board is a 16.000 MHz crystal, with ±10 ppm initial
tolerance, ± 10 ppm drift over temperature and a temperature range of -10˚ C to +60˚ C. The
crystal is designed for 16 pF load capacitance. In an actual application, the tolerance, drift
and temperature range of the crystal must be considered with application requirements in
mind. Please consult the data sheet and SmartRF
to choose a larger crystal package to save cost. The crystal should have an ESR of 60 Ω or
less.
Bill of materials, CC2400EM
Value
2.2 µF, 10%
100 nF, 10%
0.5 pF, ± 0.25 pF
5.6 pF, ± 0.25 pF
100 nF, 10%
0.5 pF, ± 0.25 pF
10 nF, 10%
68 pF, 5%
100 nF, 10%
100 nF, 10%
68 pF, 5%
27 pF, 5%
27 pF, 5%
68 pF, 5%
7.5 nH, 5%
5.6 nH, 5%
27 nH, 5%
7.5 nH, 5%
2.2 Ω, 5%
43 kΩ, 1%
®
Studio for more information. It is possible
SWRU050
Part
C_2U2_0603_X5R_K_10
C_100N_0402_X5R_J_10
C_0P5_0402_NP0_C_50
C_5P6_0402_NP0_C_50
C_100N_0402_X5R_J_10
C_0P5_0402_NP0_C_50
C_10N_0402_X7R_K_25
C_68P_0402_NP0_J_50
C_100N_0402_X5R_K_10
C_100N_0402_X5R_K_10
C_68P_0402_NP0_J_50
C_27P_0402_NP0_J_50
C_27P_0402_NP0_J_50
C_68P_0402_NP0_J_50
L_7N5_0402_J
L_5N6_0402_J
L_27N_0402_J
L_7N5_0402_J
SMD_SOCKET_2x10 (Samtec
SFM-110-02-S-D-A-K-TR)
SMD_SOCKET_2x10 (Samtec
SFM-110-02-S-D-A-K-TR)
SMA_SMD
R2R2_0402_J
R_43K_0402_F
CC2400
X_16.000/10/10/10/16 (Toyocom
TSX-10A 16M 16pF)
