Connectors
The Evaluation Board is furnished with many connectors for easy access to various signals.
Test Port 1 (P17) and Test Port 2 (P5) are 2x10 pin pin-row connectors that are connected to
the FPGA and can be used to monitor various signals, including all the CC2400 signals. The
pin-out of these connectors is compatible with logic analyzer probes from Agilent.
The DTEST1 (P6) and DTEST2 (P7) SMA connectors are also connected to the FPGA and
can be used to output or input signals from/to the CC2400, respectively.
The ATEST1 (P9) and ATEST2 (P8) provide access to analog test signals from the CC2400.
®
The selection of what signals are available at the different connectors is done in SmartRF
Studio.
