- Page 1 DW2702 LCD Monitor User Manual www.agneovo.com...
-
Page 2: Table Of Contents
Contents TABLE OF CONTENTS SAFETY INFORMATION Federal Communications Commission (FCC) Notice (U.S. Only) ..............1 WEEE ................................1 Turkey RoHS ..............................2 Ukraine RoHS .............................. 2 PRECAUTIONS Notice ................................3 Cautions When Setting Up ........................... 3 Cautions When Using ........................... 4 Cleaning and Maintenance ........................... -
Page 3: Safety Information
SAFETY INFORMATION Federal Communications Commission (FCC) Notice (U.S. Only) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 4: Turkey Rohs
SAFETY INFORMATION Turkey RoHS Ukraine RoHS... -
Page 5: Precautions
Precautions PRECAUTIONS PRECAUTIONS CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN Symbols used in this manual This icon indicates the existence of a potential hazard that could result in personal injury or damage to the product. This icon indicates important operating and servicing information. Notice •... -
Page 6: Cautions When Using
PRECAUTIONS Cautions When Using Use only the power cord supplied with the LCD monitor. The power outlet should be installed near the LCD monitor and be easily accessible. If an extension cord is used with the LCD monitor, ensure that the total current consumption plugged into the power outlet does not exceed the ampere rating. -
Page 7: Cleaning And Maintenance
PRECAUTIONS Cleaning and Maintenance Opening or removing the covers may expose you to dangerous voltage or other risks. Notice for the LCD Monitor In order to maintain the stable luminous performance, it is recommended to use low brightness setting. Due to the lifespan of the lamp, it is normal that the brightness quality of the LCD monitor may decrease with time. -
Page 8: Chapter 1: Product Description
Chapter 1: Product Description CHAPTER 1: PRODUCT DESCRIPTION 1.1 Package Contents When unpacking, check if the following items are included in the package. If any of them is missing or damaged, contact your dealer. LCD Monitor Quick Start Guide Power Cord Power Adapter RJ45 USB-A... -
Page 9: Installation
PRODUCT DESCRIPTION 1.2 Installation 1.2.1 Installing the Stand 1. Take out the stand and base, and lock the stand with the hand screw that comes with the base. 2. Insert the assembled base into the corresponding bayonet of the rear shell, and gently align the tail end perpendicular to the surface of the rear shell, so that the lock of the bracket can be buckled on the quick release button of the rear shell. -
Page 10: Wall Mounting
Note: Take measures to prevent the LCD monitor from falling down and lessen possible injury and damage to the monitor in case of earthquakes or other disasters. • Use the 100 x 100 mm wall mount kit recommended by AG Neovo. All AG Neovo wall mount kits comply with VESA standard. -
Page 11: Overview
PRODUCT DESCRIPTION 1.3 Overview 1.3.1 Front View 1.3.2 Control Panel Button Description Button Press to (Menu/Enter) sub-menus. Button Press to move up in the menu. Button Press to move down in the menu. Button Backs to the previous menu. Power button: Power on/off the monitor. LED indicator light Press to turn the power on or off. -
Page 12: Rear View
PRODUCT DESCRIPTION 1.3.3 Rear View RJ45 USB-A USB-A HDMI Type-C AUDIO OUT RJ45 Connect network devices. USB-A Connect USB-A signals input. USB-A Connect USB-A signals input. HDMI Connect HDMI signals input. Connect DisplayPort signals input. Type-C Connect Type-C signals input. AUDIO OUT Connect audio signals output (3.5 mm Stereo Audio Jack). -
Page 13: Chapter 2: Making Connections
Chapter 2: Making Connections CHAPTER 2: MAKING CONNECTIONS 2.1 Making Connections RJ45 USB-A USB-A HDMI Type-C AUDIO OUT USB TYPE-C Hub Multiport Dongle with RJ45 Ethernet and USB-A 2.0 x 2 RJ45 USB-A USB-A HDMI Type-C AUDIO OUT Ethernet... - Page 14 MAKING CONNECTIONS • When charging connected device via USB Type-C Connector, check if the device is equipped with a USB Type-C Connector that supports charging function via USB PD (Power Delivery). • The connected device can be charged via USB Type-C connector even when the monitor is in standby mode.
-
Page 15: Chapter 3: On Screen Display Menu
Chapter 3: On Screen Display Menu CHAPTER 3: ON SCREEN DISPLAY MENU 3.1 OSD Menu Tree Main Menu Submenu Third menu Description Standard Mode Off/On Movie Mode Off/On Eye Care Mode Off/On Picture Mode Select a predefined picture setting. Off/On Mac View Mode E-Book Mode Off/On... - Page 16 ON SCREEN DISPLAY MENU Main Menu Submenu Third menu Description Input Signal Auto/HDMI/DP/Type-C Set the default input signal. Enable the Quick Boot feature to Quick Boot Off/On speed up the monitor wake-up time when a signal is detected. Enabling the DDC/CI feature allows Off/On DDC/CI you to adjust the monitor's brightness,...
-
Page 17: Chapter 4: Appendix
CHAPTER 4: APPENDIX 4.1 Warning Messages When any of these warning messages appear, check the following items. Warning Message Cause Solution The LCD monitor cannot detect the Check if the input source is input source signal. turned ON. Check if the signal cable is No Signal properly connected. -
Page 18: Troubleshooting
APPENDIX 4.2 Troubleshooting Problems Possible Cause and Solution • Check if the power is on. The power indicator light is not on • Check if the power cord is connected. • Check if the function of plug-and-play of the device is compatible with Impossible plug-and-play •... -
Page 19: Chapter 5: Specifications
Chapter 7: Specifications CHAPTER 5: SPECIFICATIONS DW2702 LED-Backlit TFT LCD Panel (IPS Technology) Panel Size 27” sRGB 122% , NTSC 105% , Colour Gamut DCI-P3 96% , Adobe RGB 103% Max. Resolution WQHD 2560 x 1440 Pixel Pitch 0.233 mm... - Page 20 CHAPTER 5: SPECIFICATIONS Company Address: 5F-1, No. 3-1, Park Street, Nangang District, Taipei, 11503, Taiwan. Copyright © 2024 AG Neovo. All rights reserved. DW2702 Eprel registration number: 2080502 DW2702_UM_V010...
