  • Page 1 DR-17E & DR-22E LED-Backlit Display User Manual...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Safety Information FCC Declaimers ............................4 WEEE ............................... 5 EMC Information ............................6 Precautions Notice ............................... 10 Cautions When Setting Up ........................11 Cautions When Using ..........................12 Cleaning and Maintenance ........................12 Notice for the LCD Display ........................13 Chapter 1: Product Description 1.1 Package Contents ..........................
  • Page 3 Chapter 6: Appendix 6.1 Warning Messages ..........................48 6.2 Troubleshooting ..........................49 6.3 Transporting the LCD Display ......................50 Chapter 7: Specifications 7.1 Display Specifications ........................51 7.2 Display Dimensions ..........................52 7.2.1 DR-17E Dimensions ........................52 7.2.2 DR-22E Dimensions ........................52...

  • Page 4: Safety Information

    SAFETY INFORMATION FCC Class B Radio Frequency Interference Statement WARNING: (FOR FCC CERTIFIED MODELS) NOTE: This equipment has been tested and found to compl with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 5: Weee

    SAFETY INFORMATION WEEE Information for users applicable in European Union countries. The symbol on the product or its packaging signifies that this product has to be disposed separately from ordinary household wastes at its end of life. Please kindly be aware that this is your responsibility to dispose electronic equipment at recycling centers so as to help conserve natural resources.

  • Page 6: Emc Information

    Guidance and manufacturer’s declaration – electromagnetic emissions The DR-17E and DR-22E is intended for use in the electromagnetic environment specified below. The customer or the user of the DR-17E and DR-22E should assure that it is used in such an environment. Not Life-supporting Medical Equipment.
  • Page 7 Guidance and manufacturer’s declaration – electromagnetic immunity The DR-17E and DR-22E is intended for use in the electromagnetic environment specified below. The customer or the user of The DR-17E and DR-22E should assure that it is used in such an environment. Not Life-supporting Medical Equipment.
  • Page 8 If the measured field strength in the location in which the DR-17E and DR-22E is used exceeds the applicable RF compliance level above, the DR-17E and DR-22E should be observed to verify normal operation. If abnormal performance is observed, additional...
  • Page 9 Recommended separation distances between portable and mobile RF communications equipment and the DR-17E and DR-22E The DR-17E and DR-22E is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The customer or the user of the DR-17E and DR-22E can help prevent...

  • Page 10: Precautions

    PRECAUTIONS CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN Symbols used in this manual This icon indicates the existence ISO 7010-M002: Follow instructions of a potential hazard that could for use result in personal injury or damage to the product. This icon indicates important This icon indicates complies with the operating and servicing...

  • Page 11: Cautions When Setting Up

    PRECAUTIONS Cautions When Setting Up Do not place the LCD display near heat sources, such as a heater, exhaust vent, or in direct sunlight. Do not cover or block the ventilation holes in the housing. Place the LCD display on a stable area. Do not place the LCD display where it may subject to vibration or shock.

  • Page 12: Cautions When Using

    This may result in scratching the surface of the glass. AG Neovo for consultations and solutions to help ensure a most Do not attempt to service the LCD display yourself, refer to qualified service personnel.

  • Page 13: Notice For The Lcd Display

    This is acceptable and is not considered a failure. The intended use of the DR-17E, DR-22E is to serve as a LCD monitor for integration with the hospital system.It is designed for general purpose for adults using at hospital environment,continuous operation. For displaying and viewing of images for reference.
  • Page 14 PRECAUTIONS Notice for the LCD Display Use a power cord that matches the voltage of the power outlet, which has been approved and complies with the safety standard of your particular country. The single device output analog signals through ADC element (Analog DigitalConvert) conversion to become a digital signal and the video signal is via Video Decorder conversion.

  • Page 15: Chapter 1: Product Description

    Note: Must use only the supplied power adapter: DR-17E & DR-22E ♦ ADAPTER TECH Quick Start Guide Model no.: ATM065-P240 DR-17E & DR-22E LED-Backlit Display Rating: 24V/ 2.7A DR-17E/DR-22E_Quick Guide_V010 www.agneovo.com ♦ ADAPTER TECH Model no.: ATM065T-P240 Rating: 24V/ 2.7A...

  • Page 16: Wall Mounting Installation Preparation

    ♦ Use only the 75 x 75 mm and base stand from the 100 x 100 mm wall mount kit LCD display. recommended by AG Neovo. Detach the base ♦ Secure the LCD display on a stand. solid wall strong enough to bear its weight.

  • Page 17: Lcd Display Overview

    PRODUCT DESCRIPTION 1.3 LCD Display Overview 1.3.1 Front View and Keypad Buttons Display screen UP: Hot Key: Screen Freeze The LCD display screen is protected by • During OSD menu selection, press to select NeoV Optical Glass. an option or adjust the settings. DOWN: Hot Key: Picture Mode AUTO: Hotkey: For VGA input signal source, press to perform auto adjustment.

  • Page 18: Rear View

    PRODUCT DESCRIPTION 1.3.2 Rear View DR-17E S-VIDEO CVBS-1 CVBS-2 AUDIO AUDIO DC IN HDMI ANALOG AUDIO IN RS-232 DR-22E S-VIDEO CVBS-1 CVBS-2 AUDIO AUDIO DC IN HDMI ANALOG AUDIO IN RS-232...
  • Page 19 PRODUCT DESCRIPTION DC power input COMPOSITE Video input/output connectors (2) Use to connect the power adapter. Use to connect composite cables for CVBS DVI connector input/output signal. Use to connect a PC using DVI cable COMPOSITE Audio input connectors for digital input signal. Use to connect RCA cables for CVBS / HDMI connector S-Video audio signal.

  • Page 20: Chapter 2: Making Connections

    CHAPTER 2: MAKING CONNECTIONS 2.1 Connecting the Power Connect the power cord to the power adapter. Connect the power adapter to the DC power input at the rear of the LCD display. Connect the power cord plug to a power outlet or a power supply. DC IN Caution: ♦...

  • Page 21: Connecting Input Source Signals

    MAKING CONNECTIONS 2.2 Connecting Input Source Signals 2.2.1 Connecting a Computer Using DVI Cables Connect one end of a DVI (DVI-D) cable to the DVI connector of the LCD display and the other end to the DVI connector of the computer. Using VGA Cables Connect one end of a VGA cable to the ANALOG (VGA) connector of the LCD display and the other end to the VGA connector of the computer.

  • Page 22: Using Audio Cables

    MAKING CONNECTIONS Using Audio Cables Connect one end of an audio cable to the audio port of the LCD display and the other end to the audio out port of the computer. AUDIO IN Using RS-232 Cables Connect one end of an RS-232 cable to the RS-232 connector of the LCD display and the other end to the RS-232 connector of the computer.

  • Page 23: Connecting A Video Device

    MAKING CONNECTIONS 2.2.2 Connecting a Camera or Video Device Using S-Video Cables Connect one end of an S-Video S-VIDEO cable to the S-VIDEO connector of the LCD display and the other end to the S-VIDEO connector of your device. For audio input, connect an RCA cable to the audio in connector of the LCD display and the audio out connector of your device.
  • Page 24 MAKING CONNECTIONS Using HDMI Cables Connect one end of an HDMI cable to the HDMI connector of the LCD display and the other end to the HDMI connector of your device. HDMI Using DisplayPort Cables Connect one end of a DisplayPort cable to the DP (DisplayPort) connector of the LCD display and the other end to the DisplayPort connector of your device.

  • Page 25: Connecting A Stereo Amplifier

    MAKING CONNECTIONS 2.3 Connecting a Stereo Amplifier To amplify the sound output, connect a stereo amplifier to the LCD display. Connect an RCA cable to the audio out connector of the LCD display and to the audio in connector of a stereo amplifier.

  • Page 26: Chapter 3: Using The Lcd Display

    CHAPTER 3: USING THE LCD DISPLAY 3.1 Turning on the Power Note: ♦ The LCD display still consumes POWER button power as long as the power LED indicator cord is connected to the power outlet. Disconnect the power Connect the power cord to the power adapter. Then cord to completely cut off connect the power adapter to the DC power input at the power.

  • Page 27: Adjusting The Volume / Illuminator Function Hot Key

    USING THE LCD DISPLAY 3.3 Adjusting the Volume / Illuminator Function Hot Key VOLUME buttons Touch the buttons to call out the volume bar. Touch the button to increase volume or the button to decrease volume. 3.3.1 Muting the Audio Touch the and the buttons simultaneously to mute or unmute the audio.

  • Page 28: Using Freeze Function

    USING THE LCD DISPLAY 3.5 Using FREEZE Function The FREEZE function allows you to freeze the screen image but still continues real-time playback until the image is unfreeze. Touch the button to activate screen freeze, the screen freeze message is displayed on the screen. Note: ♦...

  • Page 29: Chapter 4: On Screen Display Menu

    CHAPTER 4: ON SCREEN DISPLAY MENU 4.1 Using the OSD Menu Operation Display the main menu screen. Touch N T S C 6 0 H z B R I G H T N E S S B R I G H T N E S S C O N T R A S T C O L O U R T E M P .
  • Page 30 ON SCREEN DISPLAY MENU Operation Select the submenu item. Touch the buttons. 6 0 H z B R I G H T N E S S T N E S S C O N T R A S T T E M P . B A C K L I G H T S E T T I N G B L A C K L E V E L...

  • Page 31: Osd Menu Tree

    ON SCREEN DISPLAY MENU 4.2 OSD Menu Tree N T S C 6 0 H z B R I G H T N E S S B R I G H T N E S S C O N T R A S T C O L O U R T E M P .
  • Page 32 ON SCREEN DISPLAY MENU Main Menu Submenu Remarks 4. ASPECT RATIO • ASPECT RATIO Refer to page 40 • H. ZOOM • V. ZOOM • OVERSCAN 5. ANTI-BURN-IN • ENABLE Refer to page 41 • INTERVAL (HOURS) • MODE 6. OSD SETTING •...
  • Page 33 ON SCREEN DISPLAY MENU Main Menu Submenu Remarks 12. INFORMATION Displays settings information such as Input, Resolution, Horizontal and Vertical Frequency, Timing mode, and Firmware version.

  • Page 34: Chapter 5: Adjusting The Lcd Display

    CHAPTER 5: ADJUSTING THE LCD DISPLAY 5.1 BRIGHTNESS 1. Touch to call out the OSD window. N T S C 6 0 H z B R I G H T N E S S B R I G H T N E S S 2.
  • Page 35 ADJUSTING THE LCD DISPLAY Original Setting High Setting Low Setting BRIGHTNESS CONTRAST BLACK LEVEL...

  • Page 36: Colour Temp

    ADJUSTING THE LCD DISPLAY 5.2 COLOUR TEMP. 1. Touch to call out the OSD window. N T S C 6 0 H z C O L O U R S E T T I N G N E U T R A L B R I G H T N E S S 2.

  • Page 37: Image Setting

    ADJUSTING THE LCD DISPLAY 5.3 IMAGE SETTING 1. Touch to call out the OSD window. N T S C 6 0 H z S H A R P N E S S B R I G H T N E S S 2.
  • Page 38 ADJUSTING THE LCD DISPLAY Item Function Operation Range Adjusts black and white levels for video. FULL Touch the button to Note: This menu option is only LIMIT select the setting. available if the input source is HDMI or DP. Signal source from PC - PC signal at a full range (Grayscale 0-255) state: COLOUR RANGE Monitor OSD colour range: Full Monitor OSD colour range: Limit...
  • Page 39 ADJUSTING THE LCD DISPLAY Item Function Operation Range H. POSITION Moves the screen image to the left (Horizontal Position) or right. V. POSITION Moves the screen image up or down. (Vertical Position) Adjusts the phase timing to Touch the button to synchronise with the video signal.

  • Page 40: Aspect Ratio

    ADJUSTING THE LCD DISPLAY 5.4 ASPECT RATIO 1. Touch to call out the OSD window. N T S C 6 0 H z A S P E C T R A T I O F U L L B R I G H T N E S S 2.

  • Page 41: Anti-Burn-In

    ADJUSTING THE LCD DISPLAY 5.5 ANTI-BURN-IN 1. Touch to call out the OSD window. N T S C 6 0 H z E N A B L E O F F B R I G H T N E S S 2.

  • Page 42: Osd Setting

    ADJUSTING THE LCD DISPLAY 5.6 OSD SETTING 1. Touch to call out the OSD window. N T S C 6 0 H z T R A N S P A R E N C Y B R I G H T N E S S 2.

  • Page 43: Audio Setting

    ADJUSTING THE LCD DISPLAY 5.7 AUDIO SETTING 1. Touch to call out the OSD window. N T S C 6 0 H z V O L U M E B R I G H T N E S S 2. Select AUDIO SETTING menu, then A U D I O C O L O U R T E M P .

  • Page 44: System

    ADJUSTING THE LCD DISPLAY 5.8 SYSTEM 1. Touch to call out the OSD window. N T S C 6 0 H z P O W E R S A V I N G O F F B R I G H T N E S S 2.
  • Page 45 Note: This menu option is only available if the input source is HDMI or DP. Enables or disables the logo feature. If the setting is set to ON, the AG Neovo logo is LOGO briefly displayed after the display is powered Turns the LED indicator on or off while using the LCD monitor.

  • Page 46: Eco Smart

    ADJUSTING THE LCD DISPLAY 5.9 ECO SMART With the built-in EcoSmart sensor, users can enable the Eco Smart feature to automatically adjust the LCD screen brightness according to the ambient light. This feature comforts the eyes and helps optimise energy efficiency.

  • Page 47: Input Select

    ADJUSTING THE LCD DISPLAY 5.10 INPUT SELECT 1. Touch to call out the OSD window. N T S C 6 0 H z V G A P R E S S B R I G H T N E S S 2.

  • Page 48: Chapter 6: Appendix

    CHAPTER 6: APPENDIX 6.1 Warning Messages Warning Messages Cause Solution The resolution or the refresh rate of • Change the resolution or the the graphics card of the computer refresh rate of the graphics I N P U T S I G N A L O U T O F R A N G E is set too high.

  • Page 49: Troubleshooting

    APPENDIX 6.2 Troubleshooting Problem Possible Cause and Solution No picture. • Check if the LCD display is turned ON. • Check if the power adapter is properly connected to the LCD display. • LED indicator is OFF. • Check if the power cord is plugged into the power outlet. •...

  • Page 50: Transporting The Lcd Display

    APPENDIX 6.3 Transporting the LCD Display To transport the LCD display for repair or shipment, place the display in its original packaging carton. Put all the accessories in the box (if necessary). Place the two foam cushions on each side of the LCD display for protection. Place the LCD display down in the box.

  • Page 51: Chapter 7: Specifications

    CHAPTER 7: SPECIFICATIONS 7.1 Display Specifications DR-17E DR-22E Panel Panel Size 17.0” 21.5” Max. Resolution SXGA 1280 x 1024 FHD 1920 x 1080 Pixel Pitch 0.2640 mm 0.2480 mm Brightness 250cd/m Contrast Ratio 1000:1 3,000 : 1 Viewing Angle (H/V) 170°/160°...

  • Page 52: Display Dimensions

    172mm 240mm 7.2.2 DR-22E Dimensions 282.4mm 53.5mm 32.6mm 100mm 513.2mm 368.5mm 324.3mm 100mm 75mm 75mm 155mm 227.4mm AG Neovo Company Address: 5F-1, No. 3-1, Park Street, Nangang District, Taipei, 11503, Taiwan. Copyright © 2017 AG Neovo. All rights reserved. DR-17E/DR-22E_UM_V010...
