- Page 1 User Manual 1/2.8” HD Camera, Day&Night, 1920x1080, Infrared, WDR, 2.8-12mm, 12/24V, IP67 MPB-72M2812M0A...
-
Page 3: Safety Precaution
ULTRA CLEAR RESOLUTION CAMERA Safety Precaution To prevent electric shocks and risk of fire hazards, do NOT use other than specific power source. CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. - Page 4 ULTRA CLEAR RESOLUTION CAMERA Safety Precaution NOTICE The image used in this instruction manual are processed to help comprehension and may differ from actual video of the camera. Avoid installing areas where has shock or vibration which results in the problems. Pay attention to safety when laying the connection cable and observe that the cable is not subjected to heavy loads, kinks or damage and no moisture can get in.
-
Page 5: Table Of Contents
ULTRA CLEAR RESOLUTION CAMERA Contents p.03~04 Safety Precaution p.05 Contents p.06 Features p.07 Composition p.07 Dimensions p.08 Part Names p.09~13 Installation Instructions p.14~31 Operating Instructions p.32 Specifications... -
Page 6: Features
ULTRA CLEAR RESOLUTION CAMERA Features Key Features • 4Mega pixel CAMERA, 2560 x 1440(25p) • The best low light performance with SONY’s STARVIS sensor • HD-Analog Transmission Distance over Coax.; 500M • Premium 4MP Multi-format Video output, Digital: EX-SDI 1.0/ 2.0/ 2.1(4MP/2MP/1.3MP), HD-SDI(2MP/1.3MP) HD-Analog: TVI mode, AHD mode (4MP/2MP/1.3MP) SD-Analog: CVBS •... -
Page 7: Composition
ULTRA CLEAR RESOLUTION CAMERA Composition Plastic Anchor: Sunshield 6 x 30mm (4pcs) Mounting Screw: 4 x 30mm (4pcs) Hex Wrench: 3mm (1pc) Cable Tie (2pcs) Camera unit Hinge Pin (1pc) Grommet (2pcs) Operating Mounting Cable fixation plate Wiring Video Sub-out Instruction Template with Fixing screw... -
Page 8: Part Names
ULTRA CLEAR RESOLUTION CAMERA Part Names SUNSHIELD JUNCTION BOX TOP JUNCTION BOX BASE BRACKET BODY CASE DUAL WINDOW Hinge Pin 2x Lock/Unlock Screw 2x Water drain Inside of Opening Cover OSD Control Joy Stick Video Sub-out Connector Video format Switch CAUTION •... -
Page 9: Installation Instructions
ULTRA CLEAR RESOLUTION CAMERA Installation Instructions Install the mount onto a strong structure such as a concrete or steel beam, etc. Use the supplied accessories when installing the mount to a structure, make sure that all the screw parts are metallic. ①... - Page 10 ULTRA CLEAR RESOLUTION CAMERA Installation Instructions ⑥ Hook up the Junction Box Top with the Junction box base by the hinge pin. ⑦ Connects the Power/Video cables from camera as illustrated. Fix the Power/Video cables from camera to junction box base using the supplied screw.
- Page 11 ULTRA CLEAR RESOLUTION CAMERA Installation Instructions ⑨ Set the camera’s orientation and tighten the lock/unlock screw using hex wrench. ⑩ If necessary, open the opening cover and connect the video sub-out cable for OSD menu setting. ⑪ After all the setting, close the opening cover and tighten with the hex wrench.
- Page 12 ULTRA CLEAR RESOLUTION CAMERA Installation Instructions Pan & Tilt adjustments • Unlock the screw on the camera bracket through using the torque wrench supplied • Set the camera’s viewing angle then lock the screw on the bracket. 1) Pan limit: Pan is limited to +/- 90°.
-
Page 13: Sunshield Assembling
ULTRA CLEAR RESOLUTION CAMERA Installation Instructions Sunshield Assembling • After all adjustments, assemble the sunsheild with the camera unit as illustrated. ① Cover the sunsheild to the camera unit. ② Slide foward to straight the camera front case. ③ Push down the front part of sunshield until clicking sound. Make sure the sunshield is fixed with camera. -
Page 14: Operating Instructions
ULTRA CLEAR RESOLUTION CAMERA Operating Instructions Using OSD controller Setup menu can be accessed and controlled by OSD control joystick on the side of camera unit. Five commands are available with the joy stick. The design of OSD could be different according to the Model. OSD Control Joy Stick Video Sub-out... -
Page 15: Osd Menu Table
ULTRA CLEAR RESOLUTION CAMERA Operating Instructions OSD menu Table MENU SUB MENU CONFIGURATION ZOOM SPEED SLOW, MID, FAST ZOOM / FOCUS ZOOM POI ZOOM H/V-POINTER PRESET ZOOM ZONE NUM, ZONE VIEW, H/V POS, ZOOM RATIO, DURATION SMART MOTION ZONE NUM, WINDOW ZONE, MOTION ZOOM OSD, H/V POS, ZOOM RATIO, DURATION, SENSITIVITY... - Page 16 ULTRA CLEAR RESOLUTION CAMERA Operating Instructions DEFOG OFF, ON MODE, LEVEL PICT. ADJUST SHADING OFF, ON SPECIAL MIRROR / FLIP OFF, HV, Hor., Ver. PRIVACY ZONE NUM, ZONE DISP, H/V-POS, H/V- SIZE, MASK COLOR, TRANSPARENCY POLYGON ZONE NUM, ZONE DISP, POS 0-X/Y, POS 1-X/Y, POS 3-X/Y, MASK COLOR, TRANSPARENCY 10% ~ 30%...
-
Page 17: Osd Menu Startup
ULTRA CLEAR RESOLUTION CAMERA Operating Instructions OSD menu Startup Press the ‘OSD menu SET key’ down to access the setup menu mode. • RETURN : Returns to the previous menu. • EXIT : Exits the current menu with SAVE or CANCEL. MENU V0. -
Page 18: Preset Zoom
ULTRA CLEAR RESOLUTION CAMERA Operating Instructions POI ZOOM PRESET ZOOM H-POINTER ZONE NUM V-POINTER ZONE VIEW RETURN H POS V POS ZOOM RATIO OZ X1.1 DURATION 5 SEC RETURN 1-1-3. PRESET ZOOM : Able to zoom in for the preset area •... - Page 19 ULTRA CLEAR RESOLUTION CAMERA Operating Instructions • DURATION : Sets the duration time for zooming by Motion. • SENSITIVITY : Adjusts the detection sensitivity for motion. High value increases the sensitivity to detect the small motion easily. 1-1-5. HOME POSITION : Camera can be configured to return to pre-defined Zoom position automatically after certain period since ZOOM IN/OUT control is accomplished.
- Page 20 ULTRA CLEAR RESOLUTION CAMERA Operating Instructions 1-2-3. LENS INIT : Lens initialization is necessary during the installation or the regular operation to align the position data with the mechanical positions whose lens elements may move and deviate from its calibrated position by the shock or vibration, for example, during the transportation.
-
Page 21: Scene Enhance
ULTRA CLEAR RESOLUTION CAMERA Operating Instructions 2-1-4. MANUAL: Iris level and Shutter speed can be set to fix. • IRIS LEVEL : 0~17 • SHUT SPEED : 1/30(1/25), 1/60(1/50), 1/120(100), 1/250(200), 1/500(400), 1/1000(800), 1/2000(1600), 1/4000(3200), 1/8000(6400), 1/15000(12800), 1/30000(25600) 2-1-5. FLIKERLESS : Reduces the flicker in video when US(60Hz)/EU(50Hz) mode is used in 50Hz/60Hz fluorescent lighting respectively. -
Page 22: Wdr Mode
ULTRA CLEAR RESOLUTION CAMERA Operating Instructions 3-1. WDR (Wide Dynamic Range) WDR is extended the gain range of the video that is mostly useful if camera takes a simultaneous picture of both indoor and outdoor nearby window. It improves contrast of the picture in outdoor scenery as well as indoor. Video outputs image processed from two images by dual shutter (long and short shutter) in a field to provide the best dynamic range. - Page 23 ULTRA CLEAR RESOLUTION CAMERA Operating Instructions 3-2. NORMAL Optimized for the normal indoor and outdoor in the good lighting condition. 3-3. HLC (High Light Compensation) Cuts out the highlight area with mask and excludes it from compensation. 3-3-1. LEVEL (0~20): Sets the HLC level.
-
Page 24: Day & Night
ULTRA CLEAR RESOLUTION CAMERA Operating Instructions 4. 3D-NR (Digital Noise Reduction) DNR function improves picture quality by filtering out signal noise which is generated under the low light conditions. Sets off, low, middle or high level. 3DNR(3-dimensional noise reduction) which reduces the noise by the multi frames. It is effective at low light. -
Page 25: Agc Thres
ULTRA CLEAR RESOLUTION CAMERA Operating Instructions 5-1-2. ANTI-SAT. (Available only with the SMART IR is ON) Sets the anti saturation level 0~20. Setting high level avoids the saturation strongly but the corners will be darker accordingly. 5-1-3. DELAY D→N DELAY is time in second while camera maintains its status before Day to Night switches. -
Page 26: Pict. Adjust
ULTRA CLEAR RESOLUTION CAMERA Operating Instructions 5-2-5. DELAY D→N DELAY is time in second while camera maintains its status before Day to Night switches. DELAY can avoid the unwanted/frivolous switching by a short term lights such as light from the passing car. Sets delay term low, middle or high. - Page 27 ULTRA CLEAR RESOLUTION CAMERA Operating Instructions 6-1-1. AUTO : Optimized for Indoor installation and more easily compensates AWB for low color temperature such as incandescent lights. 6-1-2. AUTOext : Optimized for outdoor sunlight applications and more easily compensates AWB for high color temperature such as sunlight. 6-1-3.
- Page 28 ULTRA CLEAR RESOLUTION CAMERA Operating Instructions 7. SPECIAL 7. SPECIAL MIRROR/FLIP PRIVACY CAM TITLE RETURN 7-1. MIRROR/FLIP Reverses the video left and right and/or up and down by MIRROR/FLIP. When the video is reversed by Ver. or HV, then the joystick directions are reversed accordingly.
- Page 29 ULTRA CLEAR RESOLUTION CAMERA Operating Instructions POLYGON ZONE NUM ZONE NUM ZONE DISP POS0-X ZONE DISP POS0-Y H-POS POS1-X V-POS POS1-Y H-SIZE POS2-X V-SIZE POS2-Y MASK COLOR POS3-X llllllllllllllllllllll POS3-Y TRANSPARENCY MASK COLOR llllllllllllllllllllll RETURN TRANSPARENCY RETURN 7-2-2. POLYGON • ZONE NUM : Selects mask zone number from 0 to 3 to be adjusted. •...
- Page 30 ULTRA CLEAR RESOLUTION CAMERA Operating Instructions 7-4. CAM TITLE Camera title(name) can be set and edited with alphanumeric characters. Select the camera title position ‘LEFT DOWN’ or ‘RIGHT UP’ on the video. Then ◀,▶ moves the cursor and ▲,▼ choose a character to select it. The selected characters are added and displayed on the input line.
-
Page 31: Analog Mode
ULTRA CLEAR RESOLUTION CAMERA Operating Instructions 8-4. ANALOG MODE Selects HD-ANALOG modes TVI MODE, AHD MODE or CVI MODE. If set to TVI MODE, it can be selected PELCO-C or HIK-C in UTC TYPE. 8-5. LANGUAGE 6 languages are available for OSD menu. English, Korean, Japanese, Chinese(S), Chinese, German. -
Page 32: Specifications
ULTRA CLEAR RESOLUTION CAMERA Specifications ITEM MCB-64A0003M0A Imaging Sensor 1/2.9” Sony 6.64Mega pixel STARVIS CMOS Sensor Effective Pixels 2560(H) x 1440(V) x 25p Scan Frequency 25Hz(V), 18.75Khz(H) / Progressive Video Format 2560x1440p @25/30fps, 1920x1080p @25/30fps, 1280x720p @50/60fps NTSC/PAL (16:9) Video Output Digital: EX-SDI 1.0/ 2.0/ 2.1, HD-SDI HD-Analog: TVI mode, AHD mode SD-Analog: CVBS... - Page 33 Videor E. Hartig GmbH Exclusive distribution through special- ised trade channels only. Videor E. Hartig GmbH Carl-Zeiss-Straße 8 63322 Rödermark/Germany Tel. +49 (0) 6074 / 888-0 Technical changes reserved Fax +49 (0) 6074 / 888-100 www.videor.com...
