Quick Start Guide
MODEL DKSW5484E
SW5484E DEMO KIT - DESCRIPTION
Metrix SW5484E Demo kit will allow
you to demonstrate and test the
features of the SW5484E. When the
kit is properly connected, you will be
able to demonstrate the SW5484E
capabilities. It is assumed that the
owner of this kit also has access to a
Hardy Shaker.
This demo kit can be used for Metric
or English Unit Measurements.
Visit the webpages below for more information on the Metrix SW5484E:
www.metrixvibration.com/products/switches/electronic-vibration-switches/
sw5484e-compact-switch#tab-bordered-documentations
www.metrixvibration.com/resources/videos/sw5484e-switch-video
SW5484E DEMO KIT - DESCRIPTION
Component
SW5484E Demo
Kit Bundle
Purpose
Demonstrate the versatility and functions
of the SW5484E.
Doc. 1966252
| Rev A (December 2024)
s
Metrix P/N
DKSW
5484E
| 1 of 8
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Metrix DKSW5484E
Summary of Contents for Metrix DKSW5484E
- Page 1 Hardy Shaker. This demo kit can be used for Metric or English Unit Measurements. Visit the webpages below for more information on the Metrix SW5484E: www.metrixvibration.com/products/switches/electronic-vibration-switches/ sw5484e-compact-switch#tab-bordered-documentations www.metrixvibration.com/resources/videos/sw5484e-switch-video SW5484E DEMO KIT - DESCRIPTION...
- Page 2 INCLUDED IN KIT Component Purpose Metrix Model Image Demonstrate the SW5484E Demo SW5484E-001 functions of the Kit Bundle (English Units) SW5484E Demonstrate the SW5484E Demo SW5484E-002 functions of the Kit Bundle (Metric Units) SW5484E Demonstrate SW5484E Test accuracy and TB-SW5484E...
- Page 3 INCLUDED IN KIT (Continued) Component Purpose Metrix Model Image 24 Volt Pow- Provide power 96002-048 (Digikey er Supply to SW5484E part # T1253-P6P- (240V/120V AC Test Box to 24 V DC) Case to secure all demo 99540-028 Carrying Case equipment...
-
Page 4: Demo Set Up
NOT INCLUDED IN KIT (Needed for Demonstration) Component Purpose Metrix Model Image Demonstrate Acceleration HI-903/913 Shaker HI-903/913 and Impact on the SW5580 DEMO SET UP 8978-811-0010 Doc. 1966252 | Rev A (December 2024) |4 of 8... - Page 5 SW5484E Demonstration (Alert and Danger Alarms) SW5484E Test Box 100983 Doc. 1966252 | Rev A (December 2024) | 5 of 8...
- Page 6 CONNECTING DEMO HARDWARE 1. Layout the equipment per the illustration on pages 4 and 5. 2. Mount the SW5484E on the HI-903/HI-913 Shaker (hand tighten using counter torque to not stress the shaker mounting structure). 3. Connect the Transducer Cable (8978-811-0010) to the SW5484E that is mounted on the HI-903/HI-913 Shaker.
- Page 7 DEMONSTRATING THE SW5484E CAPABILITIES Given: Download the free SW5484E Configuration software from the website. 1. Move the switch on the front of the SW5484E Test Box to the “Configure” position. 2. Start the SW5484E configuration software. It should automatically connect to the SW5484E mounted on the shaker. Verify that the serial number shown in the software matches the serial number on the connected SW5484E switch.
- Page 8 • Numerous Full Scale Ranges Note: Metrix is continuously improving our products. Please refer to our website to download the latest version of this document. All trademarks used in this document belong to Metrix. © 2024, Metrix Instrument Company, L.P. All rights reserved.
