QUICK START GUIDE
PSOC
Control C3M5 Complete
System Motor Control Kit
KIT_PSC3M5_MC1
Kit contents
1. KIT_PSC3M5_CC2 motor control card
2. Drive adapter card
3. KITMOTORDC250W24VTOBO1 power board
www.infineon.com/KIT_PSC3M5_MC1
4. USB-A to USB-C cable
5. Nanotec DB42S03 or DB42M03 24V BLDC motor
6. 24 V/1 A AC-DC adapter
7. Quick start guide (this document)
-

Advertisement

loading
Need help?

Need help?

Do you have a question about the PSOC C3M5 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Infineon PSOC C3M5

  • Page 1 Kit contents 1. KIT_PSC3M5_CC2 motor control card 4. USB-A to USB-C cable 2. Drive adapter card 5. Nanotec DB42S03 or DB42M03 24V BLDC motor 3. KITMOTORDC250W24VTOBO1 power board 6. 24 V/1 A AC-DC adapter 7. Quick start guide (this document) www.infineon.com/KIT_PSC3M5_MC1...
  • Page 2 Complete setup with motor and adapter Standalone operation 1. The MCU is pre-programmed with the out-of-box (OOB) firmware configured to run the included motor in sensorless field-oriented control (FOC) three-shunt mode. 2. Ensure that the input voltage selection jumper (X20) is set to position 2-3 (V5V). 3.
  • Page 3 GUI-based operation Install ModusToolbox™ Setup for Windows from the www.infineon.com/mtb page by clicking on Download. Install ModusToolbox™ Industrial MCU Pack from Additional Packages. This installs the ModusToolbox™ Motor Suite GUI. 3. Ensure that all the micro switches of SW3 are on the right side for proper operation.
  • Page 4 Visit the kit website and ModusToolbox webpage for more information on code examples supported for this kit and the kit documentation. All rights reserved. © 2024 Published by Infineon Technologies AG Document number: 002-40124 Rev. *C 81726 Munich, Germany Infineon Technologies AG...
