Kia Stonic 2022 Manual

Interior Overview

1. Inside door handle [4]
2. Inner fuse panel [7]
3. Power window switches [4]
4. Power window lock button [4]
5. Outside rear view mirror control switch [4]
6. Outside rear view mirror folding switch [4]
7. Bonnet release lever [4]
8. Fuel filler door release lever [4]
9. Steering wheel [4]
10. Steering wheel tilt lever [4]
11. Headlight leveling device [4]
12. Instrument panel illumination control button [4]
13. Idle Stop and Go system OFF button [5]
14. ESC OFF button [5]
15. TPMS SET button [6]
16. Brake pedal [5]
17. Accelerator pedal [5]

* if equipped

[#] Number in brackets indicates chapter in Owner's Manual.

The illustrations in this guide may vary from the actual vehicle.

Instrument Panel Overview

1. Instrument cluster [4]
2. Horn [4]
3. Driver's front air bag [3]
4. Light control [4]
5. Wiper/Washer [4]
6. Ignition switch [5] ENGINE START/STOP button [5]
7. Hazard warning flasher switch [6]
8. Infotainment System
9. Central door lock switch [4]
10. Manual climate control system [4] Automatic climate control system [4]
11. USB port [4]
12. Manual transmission [5] Intelligent manual transmission [5] Automatic transmission [5] Dual clutch transmission [5]
13. Parking brake lever [5]
14. Passenger's front air bag [3]
15. Power outlet [4]
16. Glove box [4]
17. Steering wheel audio control
18. Cigarette lighter [4]
19. Seat warmer [4]
20. Heated steering wheel switch [4]
21. Parking safety button [4]
22. DRIVE MODE button [5]
23. USB charger [4]

Instrument Cluster / Engine Compartment

Instrument cluster [4]

1. Tachometer
2. Speedometer
3. Engine coolant temperature gauge
4. Fuel gauge
5. Warning and indicator lights
6. LCD display

Engine compartment (Smartstream G1.0 T-GDi/Smartstream G1.0 T-GDi 48V HEV) [2]

1. Engine coolant reservoir [7]
2. Engine oil filler cap [7]
3. Brake/clutch fluid reservoir [7]
4. Air cleaner [7]
5. Fuse box [7]
6. Negative battery terminal [7]
7. Positive battery terminal [7]
8. Engine oil dipstick [7]
9. Radiator cap [7]
10. Windscreen washer fluid reservoir [7]

Climate Control System

Manual climate control system* [4]

Automatic climate control system* [4]

1. Temperature control
2. AUTO (automatic control)
3. Climate control display
4. Fan speed control
5. OFF
6. Front windscreen defroster
7. Rear window defroster
8. Mode selection
9. Air conditioning (if equipped)
10. Air intake control

Door Locks / Tailgate / Bonnet / Fuel Filler Door

Operating door locks manually [4]

Turn the key to the right to lock and to the left to unlock.

Central door lock switch [4]

Child-protector rear door lock [4]

Opening the tailgate [4]

Closing the tailgate [4]

Emergency tailgate safety release [4]

1. Push the mechanical key to the right

Opening the bonnet [4]

Pull the release lever to unlatch the bonnet.

1. Push the secondary latch inside of the bonnet
2. Lift the bonnet

Closing the bonnet

• Before closing the bonnet, check if all filler caps are correctly installed and any other combustible material must be removed from the engine compartment.
• Lower the bonnet until it is about 30 cm above the closed position and let it drop to securely lock in place.

Opening the fuel filler door [4]

Pull up the fuel filler door opener.

1. Fully open the door
2. Turn cap counterclockwise to open

Closing the fuel filler door

• Turn the cap clockwise until it "clicks" to ensure it is securely closed.
• Close the door and push it lightly and make sure that it is securely closed.

Windows / Wipers and Washers / Lighting Control / Fog Lights

Lighting control [4]

1. OFF position
2. Auto light position
3. Parking light position
4. Headlight position

Front fog lights*

The fog lights will turn on when the fog light switch (1) is turned on after the park light is turned on.
To turn the front fog lights off, turn the front fog light switch to the on position again.

Rear fog lights*

To turn the rear fog lights on, turn the rear fog light switch (1) to the on position when the headlight is turned on. To turn the rear fog lights off, turn the rear fog light switch to the on position again.

Seat / Air Bag / Child Restraint System

Front seat

1. Forward and backward
2. Seatback angle
3. Seat cushion height*
4. Headrest

Rear seat

5. Headrest
6. Seatback folding

Seats [3]

Passenger's front air bag ON/ OFF switch* [3]

Rearward-facing child restraint system [3]

Installing a child restraint system with a lap/shoulder belt [3]

Securing with "ISOFIX" system and "Top-tether Anchorage" system* [3]

1. ISOFIX Anchor Position Indicator
2. ISOFIX Anchor

Securing with "Top-tether Anchorage" system* [3]

Steering Wheel / Cruise Control System

Tilt & telescopic steering [4]

Steering wheel adjustment:

1. Pull down the lock release lever
2. Angle adjustment
3. Height adjustment*

Lock the steering wheel by pulling up the lock release lever.

Heated steering wheel* [4]

When the ignition switch is in the ON position, press the button to heat the steering wheel. The indicator on the button will illuminate. To turn off the heating function, press the button once again.

Cruise control (CC)* [5]

1. CRUISE indicator (/CRUISE)
2. Set speed

To set speed, press the Driving Assist button (/MODE) at desired speed.

To increase speed, push the RES+ switch up.

To decrease speed, push the SET - switch down.

Depress the brake pedal to temporarily pause cruise control or press the Driving Assist button (/MODE) to turn this function off. The cruise (/CRUISE) indicator will go off.

Resume cruising speed by pushing the RES+ switch up or SET- switch down.

Towing / Spare Tyre, Jack And Tools / Tyre Mobility Kit

Towing [6]
When towing the vehicle in an emergency without wheel dollies, tow with the front wheels off the ground and:

1. Set the ignition switch in the ACC position.
2. Place the transaxle shift lever in N (Neutral).
3. Release the parking brake.

• Do not tow the vehicle backwards with the front wheels on the ground as this may cause damage to the vehicle.
• Do not tow with sling-type equipment. Use wheel lift or flatbed equipment.

1. Wheel dollies

Jack and tools* [6]

The shown tools are stored in the luggage compartment. Pull up the luggage box cover to reach this equipment.

1. Jack handle
2. Jack
3. Wheel lug nut wrench

Tyre Mobility Kit* [6]

Please read the instructions before using the Tyre Mobility Kit.

1. Compressor
2. Sealant bottle

With the Tyre Mobility Kit you stay mobile even after experiencing a tyre puncture. After you ensure that the tyre is properly sealed you can drive cautiously on the tyre (up to 200 km (120 miles)) at a max. speed of 80 km/h (50 mph) in order to reach a vehicle or tyre dealer to have the tyre replaced.

Engine Oil / Washer Fluid

Checking the engine oil level [7]

1. Be sure the vehicle is on level ground.
2. Start the engine and allow it to reach normal operating temperature.
3. Turn the engine off and wait for a few minutes (about 10 minutes) for the oil to return to the oil pan.
4. Pull the dipstick out, wipe it clean, and re-insert it fully.

Refilling engine oil [7]

5. Pull the dipstick out again and check the level. The level should be between F (Full) and L (Low). Do not overfill.

• Use a funnel to help prevent oil from being spilled on engine components.
• Use only the specified engine oil. (Refer to "Recommended lubricants and capacities")

Checking the washer fluid level [7]

Check the fluid level and add fluid if necessary.

Additional Info*

Idle Stop & Go (ISG)
When enabled, ISG automatically stops the car's engine to reduce fuel consumption and emissions. The ISG function may not work if the car's battery charge status, ambient temperature and/or engine temperature is too low. Air conditioning/heater control settings may also affect ISG function.

Parking brake (handbrake)
When engaging the parking brake, apply the footbrake first and keep it depressed. Then apply the parking brake.

We strongly recommend to leave the car in first or reverse gear or in the 'P' (Park) position on automatics when leaving the car.

(*) In selected markets only
