Kia Rio 2022 Manual

Interior Overview

1. Inside door handle [4]
2. Inner fuse panel [8]
3. Power window switches [4]
4. Power window lock button [4]
5. Outside rearview mirror control switch [4]
6. Outside rearview mirror folding switch [4]
7. Hood release lever [4]
8. Fuel filler door release lever [4]
9. Steering wheel [4]

10. Steering wheel tilt lever [4]
11. Headlight leveling device [4]
12. Instrument panel illumination control button [4]
13. Idle Stop and Go system OFF button [6]
14. ESC OFF button [6]
15. TPMS SET button [7]
16. Brake pedal [6]
17. Accelerator pedal [6]

*: if equipped
The actual feature may differ from the illustration.
[#] Number in parentheses indicates chapter in Owner's Manual.

Instrument Panel / Engine Compartment Overview

Instrument Panel

1. Instrument cluster [4]
2. Horn [4]
3. Driver's front air bag [3]
4. Light control [4]
5. Wiper/Washer [4]
6. Ignition switch or ENGINE START/STOP button [6]
7. a ard warning flasher switch [7]
8. Infotainment system [5]
9. Central door lock switch [4]
10. Manual climate control system [4] Automatic climate control system [4]
11. USB port [5]
12. Manual transmission [6] Intelligent manual transmission [6] Automatic transmission [6] Dual clutch transmission [6]
13. Parking brake lever [6]
14. Passenger's front air bag [3]
15. Power outlet [4]
16. Glove box [4]
17. Steering wheel audio control [5]
18. Cigarette lighter [4]
19. Seat warmer [4]
20. Heated steering wheel switch [4]
21. Parking safety button [4]
22. DRIVE MODE button [6]
23. USB charger [4]

The actual instrument panel and engine compartment in the vehicle may differ from the illustration.

Door Locks / Bonnet / Tailgate

Door locks [4]
Operating door locks from outside the vehicle

Operating door locks from inside the vehicle

Closing the bonnet

1. Before closing the bonnet, check the following:
   • ll filler caps in the engine compartment must be correctly installed.
   • Gloves, rags or any other combustible material must be removed from the engine compartment.
2. Return the support rod to its clip to prevent it from rattling.
3. Lower the bonnet until it is about 30 cm above the closed position and let it drop.
4. Check that the bonnet has engaged properly. If the bonnet can be raised slightly, open it again and close it with a little more force.

Tailgate [4]
Opening the tailgate manually

Closing the tailgate
To close the tailgate, lower and push down the tailgate firmly. Make sure that the tailgate is securely latched.

Emergency tailgate safety release

1. Input the mechanical key into the hole.
2. Push the mechanical key to the right (1).
3. Push up the tailgate.

Windows / Windshield Wipers and Washers

Windows [4]

1. Driver's door power window switch
2. Front passenger's door power window switch
3. Rear door (left) power window switch*
4. Rear door (right) power window switch*
5. Window opening and closing
6. Automatic power window up*/down* (Driver's window)
7. Power window lock switch*

*In cold and wet climates, power windows may not work properly due to freezing conditions.

Wipers and Washers [4]

1. Wiper speed control (front)
   1. 2 / HI – High wiper speed
   2. 1 / LO – Low wiper speed
   3. -- / INT – Intermittent wipe AUTO* – Automatic control wipe
   4. O / OFF – Off
   5. / MIST / 1x – Single wipe
2. Intermittent control wipe time adjustment
3. Wash with brief wipes (front)*
4. Rear wiper/washer control*

6. 2 / HI – Normal wiper operation
7. 1 / LO / ON – Intermittent wipe
8. O / OFF – Wiper is not in operation

5. Wash with brief wipes (rear)

Reverse Parking Distance Warning (PDW)

The reverse parking distance warning assists the driver during backward movement of the vehicle by chiming if any object is sensed within a distance of 120 cm (48 in.) behind the vehicle.

1. Ultrasonic sensor

Types of warning sound	Indicator*
When an object is 60~120 cm (24~48 in.) from the rear bumper: Buzzer beeps intermittently.
When an object is 30~60 cm (12~24 in.) from the rear bumper: Buzzer beeps more frequently.
When an object is within 30 cm (12 in.) of the rear bumper: Buzzer sounds continuously.

Seat / Headrest / Seat Warmer

Driver's seat

1. Forward and backward
2. Seatback angle
3. Seat cushion height*
4. Headrest

Front passenger's seat

1. Forward and backward
2. Seatback angle
3. Seat cushion height*
4. Headrest

Rear seat

5. Headrest
6. Seatback folding

Adjusting the height up and down (front)

• To raise the headrest, pull it up to the desired position (1).
• To lower it, push and hold the release button (2) and lower the headrest to the desired position (3).

• To raise the headrest, pull it up to the desired position (1).
• To lower it, push and hold the release button (2) and lower the headrest to the desired position (3).
• When the seat warmer operation is not needed, keep the switches in "OFF".
• Each time you press the switch, the temperature setting of the front seat will change as follows:


Air Bag / Child Restraint System

1. Driver's front air bag*
2. Passenger's front air bag*
3. Side air bag*
4. Curtain air bag*
5. Front passenger's air bag ON/OFF switch*

Installing a child restraint system with a lap/shoulder belt [3].

Securing a child restraint system seat with "top-tether anchorage" system*. Refer to Owner's Manual [3].

Securing child restraint system with "ISOFIX" anchorage system. Refer to Owner's Manual [3].

Position of the ISOFIX anchors for child restraints.

Automatic Climate Control System*

Manual Climate Control System* [4]

1. Fan speed control knob
2. Mode selection knob
3. Temperature control knob
4. Air conditioning button*
5. Rear window defroster button
6. Air intake control button

Automatic Climate Control System* [4]

1. Temperature control knob
2. AUTO (automatic control) button
3. Climate control display
4. Fan speed control knob
5. OFF button
6. Front windscreen defroster button
7. Rear window defroster button
8. Mode selection button
9. Air conditioning button*
10. Air intake control button

Lighting Control / Tilt & Telescopic Steering / Cruise Control System*

Lighting control [4]

1. Off position
2. Auto light position
3. Parking light position
4. Headlight position

Auto light position
When the light switch is in the AUTO light position, the taillights and headlights will be turned ON or OFF automatically depending on the amount of light outside the vehicle.

1. Sensor

Tilt & telescopic steering* [4]
Pull down the lock release lever (1) and adjust the steering wheel to the desired angle (2) and height (3). Pull up the lock-release lever to lock the steering wheel in place. Be sure to adjust the steering wheel to the desired position before driving.

Cruise control operation* [6]

1. CRUISE indicator ( /CRUISE)
2. Set speed The cruise control system allows you to drive at speeds above 30 km/h (20 mph) without depressing the accelerator pedal.

To set cruise control speed:

• Accelerate to the desired speed, which must be more than 30 km/h (20 mph).
• Press the Driving Assist button at the desired speed. The set speed and Cruise ( /CRUISE) indicator will illuminate on the cluster.
• Release the accelerator pedal. Vehicle speed will maintain the set speed even when the accelerator pedal is not depressed.

To increase cruise control speed:
Follow either of these procedures:

• Push the RES+ switch up and release it immediately. The cruising speed will increase by 1 km/h (1 mph) each time the switch is operated in this manner.
• Push the RES+ switch up and hold it whilst monitoring the set speed on the cluster. The cruising speed will increase to the nearest multiple of ten (multiple of five in mph) at first, and then increase by 10 km/h (5 mph) each time the switch is operated in this manner. Release the switch when the desired speed is shown and the vehicle will accelerate to that speed.

To turn off cruise control
Press the Driving Assist button to turn cruise control off. The Cruise ( /CRUISE) indicator will go off.

Warning and Indicator Lights

Symbol	Color	Name of the Symbol
	Red	Air bag warning light*
	Red	Seat belt warning light
	Red	Parking brake brake fluid warning light
	Yellow	Anti-lock brake system (ABS) warning light*
	Yellow/Red	Electronic brake force distribution (EBD) system warning light*
	Red	Electronic power steering (EPS) warning light
	Yellow	Malfunction indicator lamp (MIL)
	Red	Charging system warning light
	Red	Engine oil pressure warning light
	Yellow	Engine oil level warning light*
	Yellow	Low fuel level warning light
	Yellow	Low tire pressure warning light*
	Yellow	Forward collision avoidance assist (FCA) warning light*
	Yellow	Master warning light*
	Yellow	Exhaust system (GPF) warning light (Gasoline engine)*
	Red	Door ajar warning light*
	Yellow	Tailgate open warning light*
	Yellow	asher fluid warning light
	Yellow	Electronic stability control (ESC) indicator light*
	Yellow	Electronic stability control (ESC) OFF indicator light*
	Yellow/Green	Auto stop indicator*
	Yellow	Immobilizer indicator light
	Green	Turn signal indicator light
	Green	Low beam indicator light*
	Blue	High beam indicator light
	Green	Light ON indicator light
	Green	Front fog indicator light*
	Yellow	Rear fog indicator light*
	Green	Cruise indicator light*
	Green	Cruise SET indicator light*
	Green/Yellow/ White	LKA (lane keeping assist) system indicator*
	Green	High beam assist indicator*
	Yellow	LED headlamp warning light
	White	Icy road warning light
	Yellow	SPORT mode indicator light
	Green	ECO mode indicator light

Please refer to the Owner's Manual Chapter 4 for further information on Warning and Indicators Lights.

Towing / Changing Tyres

When towing your vehicle in an emergency without wheel dollies:

1. Set the ignition switch in the ACC position.
2. Place the transmission shift lever in N (Neutral).
3. Release the parking brake.

When being towed by a commercial tow truck and wheel dollies are not used, the front of the vehicle should always be lifted, not the rear.

1. Wheel dolly

Emergency towing [7]
If towing is necessary, we recommend you to have it done by an authorized Kia dealer or a commercial tow truck service.

Changing tyres [7]

1. Park on a level surface and apply the parking brake firmly.
2. Shift the shift lever into R (Reverse) with manual transmission or P (Park) with automatic transmission.
3. Activate the hazard warning flasher.
4. Remove the wheel lug nut wrench, jack, jack handle, and spare tire from the vehicle.

5. Block both the front and rear of wheel that is diagonally opposite the jack position.
6. Loosen the wheel lug nuts counterclockwise one turn each, but do not remove any nut until the tyre has been raised off the ground.
7. Place the jack at the front (1) or rear (2) jacking position closest to the tire you are changing.

8. Insert the jack handle into the jack and turn it clockwise, raising the vehicle until the tyre just clears the ground. This measurement is approximately 30 mm (1.2 in).
9. Loosen the wheel nuts and remove them with your fingers.
10. To reinstall the wheel, hold it on the studs, put the wheel nuts on the studs and tighten them finger tight. Jiggle the tyre to be sure it is completely seated, then tighten the nuts as much as possible with your fingers again.
11. Lower the vehicle to the ground by turning the wheel nut wrench counterclockwise.

In Case of Remote Key Failure

• Replace the fuse with a new one. If it is not possible, you can start the engine by pressing the engine start/stop button for 10 seconds while it is in the ACC position.
• The engine can start without depressing the brake pedal. But for your safety always depress the brake pedal before starting the engine.

Mechanical key [4]

• To remove the mechanical key, press and hold the release button (1) and remove the mechanical key (2).
• To reinstall the mechanical key, put the key into the hole and push it until a click sound is heard.

Opening the fuel filler door [4]

1. Stop the engine.
2. To open the fuel filler door, pull up the fuel filler door opener.

3. Pull the fuel filler door (1) out to fully open.
4. To remove the cap, turn the fuel tank cap (2) counterclockwise.
5. Refuel as needed.

Closing the fuel filler door

1. To install the cap, turn it clockwise until it "clicks". This indicates that the cap is securely tightened.
2. Close the fuel filler door and push it lightly and make sure that it is securely closed.

Checking the engine oil level [8]

1. Be sure the vehicle is on level ground.
2. Start the engine and allow it to reach normal operating temperature.
3. Turn the engine off and wait for a few minutes (about 10 minutes) for the oil to return to the oil pan.
4. Pull the dipstick out, wipe it clean, and re-insert it fully.

5. Pull the dipstick out again and check the level. The level should be between F (Full) and L (Low). Do not overfill.

• Use a funnel to help prevent oil from being spilled on engine components.
• Use only the specified engine oil. [9]

Checking the washer fluid level [8]

• Check the fluid level and add fluid if necessary.
• Plain water may be used if washer fluid is not available. However, use washer solvent with antifreeze characteristics in cold climates to prevent freezing.

Kia Service App
The Kia Service App – now available for free on iPhone/iPad and Android With the Kia Service App, you have (almost) all Kia dealers in Europe within reach*. Looking for a showroom or just a service, the app displays all dealers around your current location on the map. With one click you can call a dealer, visit their website or get directions to the showroom.
(*) In selected markets only
