Kia Soul 2015 Manual

Interior Overview

Interior Overview

  1. Inside door handle [4]
  2. Power window switches [4]
  3. Power window lock switch* [4]
  4. Central door lock switch* [4]
  5. Outside rearview mirror control switch [4]
  6. Outside rearview mirror folding button* [4]
  7. Fuel filler lid open lever [4]
  1. Headlight leveling control* [4]
  2. LDWS ON/OFF button* [5]
  3. Active Eco button Idle Stop and Go (ISG) OFF button* [5]
  4. Heated steering wheel ON/ OFF button* [4]
  5. ESC OFF button [5]
  6. Instrument panel illumination control [4]
  1. Advanced Lighting Speaker* [4]
  2. Steering wheel [3]
  3. Tilt and telescopic steering column control lever [4]
  4. Interior Fuse box [7]
  5. Bonnet release lever [4]
  6. Seat [3]
  7. Gear lever [5]

* if equipped
[#] Number in brackets indicates chapter in Owner's Manual
The illustrations in this guide may vary from the actual vehicle.

Instrument Panel Overview / Engine Compartment

Instrument Panel Overview

  1. Audio remote control buttons* [4]
  2. Driver's front air bag [3]
  3. Horn [4]
  4. Cruise control/Speed limiter buttons* [5]
  5. Instrument cluster [4]
  6. Light/Turn signal control lever [4]
  1. Wiper and washer control lever [4]
  2. ENGINE START/STOP button* [5]
  3. Audio/Sat Nav system* [4]
  4. Hazard warning light [6]
  5. Climate control system [4]
  6. Front seat warmer* [4]
  1. Power outlet/ Cigarette lighter* [4]
  2. Center console storage box [4]
  3. Glove box [4]
  4. Passenger's front air bag [3]
  5. Parking brake lever [5]

Engine Compartment

  1. Engine coolant reservoir [7]
  2. Engine oil filler cap [7]
  3. Windscreen washer fluid reservoir [7]
  4. Engine oil dipstick [7]
  5. Radiator cap [7]
  6. Brake/clutch* fluid reservoir [7]
  7. Fuel filter* [7]
  8. Positive battery terminal [7]
  9. Negative battery terminal [7]
  10. Engine room fuse box [7]
  11. Air cleaner [7]

Door Locks / Tailgate / Bonnet / Fuel Filler Lid

Operating door locks manually [4]

Central door lock/unlock switch [4]

  1. lock doors
  2. unlock doors

Child-protector rear door lock [4]

Opening the tailgate [4]

Closing the tailgate [4]

Emergency tailgate release [4]

Opening the bonnet [4]
Pull the release lever to unlatch the bonnet.

  1. Lift the bonnet slightly.
  2. Push the secondary latch inside and open the bonnet.

Closing the bonnet

  1. Ensure that all filler caps in the engine compartment are correctly installed and gloves, rags or any other combustible material was removed before closing the bonnet.
  2. Lower the bonnet halfway and push down to securely lock in place.

Opening the fuel filler [4]
Pull up the fuel filler lid release lever.

  1. Fully open the lid.
  2. Turn cap counterclockwise to open.

Closing the fuel filler

  1. Turn cap clockwise until it "clicks" to ensure it is securely closed.
  2. Close the lid and press the edge until it is securely locked.

Windows / Wipers and Washers

Windows / Wipers and Washers

  1. Driver's door power window switch
  2. Front passenger's door power window switch
  3. Rear door (right) power window switch*
  4. Rear door (left) power window switch*
  5. Window opening and closing
  6. Automatic power window up*/down*
  7. Power window lock switch*

NOTICE
In cold and wet climates, power windows may not work properly due to freezing conditions. Windows [4]

  1. Wiper speed control (front)
    2 High wiper speed
    1 Low wiper speed
    --- Intermittent wipe
    O OFF
    Single wipe
  2. Intermittent control wipe time adjustment
  3. Wash with brief wipes (front)


Rear* [4]

  1. Rear wiper/washer control
    Continuous wipe
    --- Intermittent wipe*
    O OFF
  2. Wash with brief wipes (rear)

Seat / Air Bag / Child Restraint System

Seat [3]
Seat / Air Bag / Child Restraint System

Front seat

  1. Forward and backward
  2. Seatback angle
  3. Seat cushion height (Driver's seat)
  4. Lumbar support (Driver's seat)*
  5. Headrest

Rear seat

  1. Seat back folding
  2. Headrest

Passenger's front air bag ON/ OFF switch* [3]

Rearward-facing child restraint system [3]

Installing a child restraint system by lap/shoulder belt [3]

Securing with "ISOFIX" system and "Tether Anchorage" system* [3]

  1. ISOFIX Anchor Position Indicator
  2. ISOFIX Anchor

Securing with "Tether Anchor" system* [3]

Climate Control System

Manual climate control system* [4]
Manual climate control system

  1. Fan speed control
  2. Air intake control
  3. Mode selection
  1. Rear window defroster
  2. Temperature control
  3. Air conditioning*

Automatic climate control system* [4]
Automatic climate control system

  1. Temperature control knob
  2. Front windscreen defroster button
  3. Rear windscreen defroster button
  1. Air intake control button
  2. Air conditioning button
  3. Fan speed control switch
  1. AUTO (automatic control) button
  2. OFF button
  3. Mode selection button
  4. Climate control information screen selection button

Lighting Control / Steering Wheel / Cruise Control System

Lighting control [4]

  1. OFF
  2. Position light
  3. Headlight
  4. Auto light*

Tilt & telescopic steering* [4]
Steering wheel adjustment:

  1. Pull down lock release lever.
  2. Adjust the steering wheel to the desired angle.
  3. Adjust the steering wheel to desired height.
  4. Lock the steering wheel by pulling up lock release lever

FLEX STEER System* [4]
The Flex Steer System controls steering effort depending on the driver's preference or driving conditions. You can choose between 3 different steering modes by pressing the steering mode button.

Cruise control system* [5]

  1. Cruise indicator
  2. Cruise set indicator.

Activate cruise control system by pressing the shown button.

Set cruise control speed by pressing the SET - button

To increase/decrease cruise control set speed.

Cancel cruise control set speed by pressing the CANCEL button.

Resume cruising speed by pressing the button RES +.

Towing / Spare Tyre / Tyre Mobility Kit

Towing [6]
When towing the vehicle in an emergency without wheel dollies:

  1. Set the ignition switch in the ACC position.
  2. Place the transaxle shift lever in N (Neutral).
  3. Release the parking brake.

Emergency towing
If towing is necessary, it is recommended to have it done by an authorised Kia dealer or a commercial tow truck service.

Removable towing hook

  1. Open the tailgate and remove the towing hook from the tool case. The tool case is located under the luggage box.
  2. Remove the hole cover by pressing the lower part of the cover on the bumper.
  3. Install the towing hook by turning it clockwise until it is fully secured.
  4. Remove the towing hook and install the cover after use.

Spare Tyre, Jack and tools* [6]
Pull up the luggage box cover to access the equipment.

  1. Jack handle
  2. Jack
  3. Wheel lug nut wrench

Tyre Mobility Kit* [6]
Please read the instructions before using the Tyre Mobility Kit.

  1. Compressor
  2. Sealant bottle

With the Tyre Mobility Kit it is possible to stay mobile even after experiencing a tyre puncture. Once the punctured tyre is properly sealed, cautiously drive (up to max. 200 km (120 miles)) at a max. speed of 80 km/h (50 mph) to the nearest vehicle or tyre service point, in order to have the tyre repaired or replaced.

Engine Oil / Washer Fluid / Additional Information

Checking the engine oil level [7]
Warm up the engine to operating temperature and switch off. On level ground pull the dipstick out and wipe clean before re inserting it fully. Pull the dipstick out again and check the level. The level should be between F and L.

Refilling engine oil [7]
Only refill with the specified engine oil [8], using a funnel to avoid spillage on engine components.

Checking the washer fluid level [7]
Check the fluid level and add fluid if necessary.

Additional Information*

Idle Stop & Go (ISG)
When enabled, ISG automatically stops the car's engine to reduce fuel consumption and emissions. The ISG function may not work if the car's battery charge status, ambient temperature and/or engine temperature is too low. Air conditioning/heater control settings may also affect ISG function.

Starting your vehicle with the parking brake applied:

  • For Manual Transaxle vehicles: Make sure the transaxle is in Neutral and the clutch pedal is fully depressed before starting the vehicle.
  • For Automatic Transaxle vehicles: Make sure the transaxle is in the P (Park) position and the brake pedal fully depressed before starting the vehicle.

Hill-Start Assist Control (HAC)
This is designed to assist with hill starts by preventing the car rolling backwards when driving off. The system maintains the braking pressure in certain circumstances for 2 seconds enabling to pull away when you are ready.

Parking brake (Handbrake)
When engaging the parking brake, apply the footbrake first and keep it depressed. Then ensure the parking brake is properly applied according to the type. Hand type: pull the parking brake lever up as far as possible. Foot type: depress the parking brake pedal down as far as possible. Electric (EPB) type: pull up the EPB switch and make sure the warning light comes on.
We strongly recommend to leave the car in first or reverse gear or in the 'P' (Park) position on automatics when leaving the car.

Bluetooth ®
Many of our cars have Bluetooth ® connectivity to enable the driver to safely enjoy the convenience of their mobile phone. For Bluetooth ® compatibility please visit the owners section on our website. www.kia.co.uk

The Kia Service App – now available for free on iPhone/iPad and Android
With the Kia Service App, you have (almost) all Kia dealers in Europe within reach*. Looking for a showroom or just a service, the app displays all dealers around your current location on the map. With one click you can call a dealer, visit their website or get directions to the showroom. (*) In selected markets only
