Kia RIO 2016 Manual

Interior Overview

Interior Overview

  1. Door lock/unlock button* [4]
  2. Central door lock switch* [4]
  3. Power window switches* [4]
  4. Power window lock button* [4]
  5. Outside rearview mirror control switch [4]
  6. Outside rearview mirror folding switch [4]
  7. Bonnet release lever [4]
  1. Fuel filler lid open lever [4]
  2. Tailgate lid release lever (4 door) [4]
  3. Steering wheel [4]
  4. Steering wheel tilt control [4]
  5. Instrument panel illumination control* [4]
  6. Headlight levelling control* [4]
  1. ESC OFF button* [5]
  2. Rear parking assist system ON/OFF button* [5]
  3. Heated steering wheel switch* [4]
  4. Idle Stop and Go (ISG) OFF button* [5]
  5. Interior fuse box [7]
  6. Brake pedal [5]
  7. Accelerator pedal

* if equipped
[#] Number in brackets indicates chapter in Owner's Manual
The illustrations in this guide may vary from the actual vehicle.

Instrument Panel Overview / Engine Compartment

Instrument Panel Overview

  1. Instrument cluster [4]
  2. Horn [4]
  3. Driver's front air bag* [3]
  4. Light/Turn signal control lever [4]
  5. Wiper and washer control lever [4]
  6. Ignition switch* or ENGINE START/STOP button* [5]
  1. Hazard warning light [4/6]
  2. Audio system [4]
  3. Climate control system* [4]
  4. Gear lever* [5]
  5. Audio remote control buttons* [4]
  6. Passenger's front air bag* [3]
  1. Glove box [4]
  2. Parking brake [5]
  3. Power outlet* [4]
  4. Cigarette lighter* [4]
  5. Front seat warmer* [3]
  6. Central door lock button* [4]

Engine Compartment

  1. Engine coolant reservoir [7]
  2. Radiator cap [7]
  3. Brake/clutch* fluid reservoir [7]
  4. Air cleaner [7]
  5. Engine oil dipstick [7]
  6. Engine oil filler cap [7]
  7. Windscreen washer fluid reservoir [7]
  8. Engine room fuse box [7]
  9. Positive battery terminal [7]
  10. Negative battery terminal [7]
  11. Fuel filter [7]

Door Locks / Tailgate / Bonnet / Fuel Filler Lid

Operating door locks from outside the vehicle [4]

Operating door locks from inside the vehicle with central door lock switch [4]

Emergency door locking [4]

Child-protector rear door lock [4]

Opening the tailgate [4]

Closing the tailgate [4]

Opening the bonnet [4]
Pull the release lever to unlatch the bonnet.

  1. Lift the bonnet slightly.
  2. Push the secondary latch inside and open the bonnet.


Release the support rod and insert it into the position shown.

Opening the fuel filler [4]
Pull up the fuel-filler lid release lever.

  1. Fully open the lid.
  2. Turn cap counterclockwise to open.

Closing the fuel filler

  1. Turn cap clockwise until it "clicks" to ensure it is securely closed.
  2. Close the lid and press the edge until it is securely locked.

Windows / Wipers and Washers

Windows / Wipers and Washers
Windows [4]

  1. Driver's door power window switch
  2. Front passenger's door power window switch
  3. Rear door (right) power window switch*
  4. Rear door (left) power window switch*
  5. Window opening and closing
  6. Automatic power window up*/down*
  7. Power window lock switch*

Notice
In cold and wet climates, power windows may not work properly due to freezing conditions.

  1. Wiper speed control (front)
    2 High wiper speed
    1 Low wiper speed
    --- Intermittent wipe
    O OFF
    Single wipe
  2. Intermittent control wipe time adjustment
  3. Wash with brief wipes (front)


Rear* [4]

  1. Rear wiper/washer control
    High wiper speed
    --- Low wiper speed
    O OFF
  2. Wash with brief wipes (rear)

Seat / Air Bag / Child Restraint System

Seat / Air Bag / Child Restraint System
Seat [3]

Driver's Seat

  1. Forward and backward
  2. Seatback angle
  3. Seat cushion height*
  4. Seat warmer*
  5. Headrest

Front passenger seat

  1. Forward and backward
  2. Seatback angle
  3. Seat warmer*
  4. Walk-in seat (3 door)
  5. Headrest

Rear seat

  1. Headrest*
  2. Seatback folding*

Passenger's front air bag ON/ OFF switch [3]

Rearward-facing child restraint system [3]

Installing a child restraint system by lap/shoulder belt [3]

Securing with "ISOFIX" system and "Tether Anchorage" system [3]

Position of the lower anchors for child restraints

Securing with "Tether Anchor" system [3]

Climate Control System

Manual climate control system* [4]
Manual climate control system

  1. Fan speed control
  2. Mode selection
  3. Temperature control
  1. Air conditioning*
  2. Rear window defroster
  3. Air intake control

Automatic climate control system* [4]
Automatic climate control system

  1. Temperature control
  2. AUTO (automatic control)
  3. A/C display
  4. Fan speed control
  1. Blower OFF
  2. Front windscreen defroster
  3. Rear window defroster
  1. Mode selection
  2. Air conditioning
  3. Air intake control

Lighting Control / Steering Wheel / Cruise Control System

Lighting control [4]

  1. OFF
  2. Position light
  3. Headlight
  4. Auto light*

Tilt steering* [4]
Steering wheel angle adjustment:

  1. Pull down lock release lever
  2. Adjust the steering wheel to the desired angle
  3. Height adjustment*

Lock steering wheel by pulling up lock release lever.

Heated steering wheel* [4]
When the ignition switch is in the ON position, pressing the heated steering wheel button warms the steering wheel. The indicator on the button will illuminate. To turn the steering wheel off, press the button once again. The indicator on the button will turn off.

  1. Cruise control system* [5] ON-OFF button (CRUISE/ ) to activate cruise control system
  2. Set cruise control speed by moving the lever down to SET -.
  3. To increase cruise control set speed.
  4. To decrease cruise control set speed.
  5. Cancel cruise control set speed by pressing the Cancel button.
  6. Resume cruising speed by moving the lever up to RES +.

Towing / Spare Tyre / Tyre Mobility Kit

Towing [6]
When towing your vehicle in an emergency without wheel dollies:

  1. Set the ignition switch in the ACC position.
  2. Place the transaxle shift lever in N (Neutral).
  3. Release the parking brake.

Emergency towing
If towing is necessary, we recommend you to have it done by an authorised Kia dealer or a commercial tow truck service.

Removable towing hook

  1. Open the tailgate and remove the towing hook from the tool case.
  2. Remove the hole cover pressing the lower part of the cover on the bumper.
  3. Install the towing hook by turning it clockwise until it is fully secured.
  4. Remove the towing hook and install the cover after use.

Spare Tyre, Jack and tools* [6]
The shown tools are stored in the luggage compartment.
Pull up the luggage box cover to access the equipment.

  1. Jack handle
  2. Jack
  3. Wheel lug nut wrench

Tyre Mobility Kit* [6]
Please read the instructions before using the Tyre Mobility Kit.

  1. Compressor
  2. Sealant bottle

With the Tyre Mobility Kit it is possible to stay mobile even after experiencing a tyre puncture.
Once the punctured tyre is properly sealed, cautiously drive (up to max. 200 km (120 miles)) at a max. speed of 80 km/h (50 mph) to the nearest vehicle or tyre service point, in order to have the tyre repaired or replaced.

Engine Oil / Washer Fluid / Additional Info

Checking the engine oil level [7]
Warm up the engine to operating temperature and switch off. On level ground pull the dipstick out and wipe clean before re inserting it fully. Pull the dipstick out again and check the level. The level should be between F and L.

Refilling engine oil [7]
Only refill with the specified engine oil [8], using a funnel to avoid spillage on engine components.

Checking the washer fluid level [7]
Check the fluid level and add fluid if necessary.

Additional Information*
Idle Stop & Go (ISG)
When enabled, ISG automatically stops the car's engine to reduce fuel consumption and emissions. The ISG function may not work if the car's battery charge status, ambient temperature and/or engine temperature is too low. Air conditioning/heater control settings may also affect ISG function.

Starting your vehicle with the parking brake applied:

  • For Manual Transaxle vehicles: Make sure the transaxle is in Neutral and the clutch pedal is fully depressed before starting the vehicle.
  • For Automatic Transaxle vehicles: Make sure the transaxle is in the P (Park) position and the brake pedal fully depressed before starting the vehicle. ISG function.

Bluetooth ®
Many of our cars have Bluetooth ® connectivity to enable the driver to safely enjoy the convenience of the mobile phone. For Bluetooth ® compatibility please visit the owners section on our website.
For full details and instructions on any item contained in this quick reference guide, please read the owner's manual.

Hill-Start Assist Control (HAC)
This is designed to assist with hill starts by preventing the car rolling backwards when driving off. The system maintains the braking pressure in certain circumstances for 2 seconds enabling to pull away when you are ready.

Parking brake (handbrake)
When engaging the parking brake, apply the footbrake first and keep it depressed. Then ensure the parking brake is properly applied according to the type. Hand type: pull the parking brake lever up as far as possible. Foot type: depress the parking brake pedal down as far as possible. Electric (EPB) type: pull up the EPB switch and make sure the warning light comes on.
We strongly recommend to leave the car in first or reverse gear or in the 'P' (Park) position on automatics when leaving the car.

The Kia Service App – now available for free on iPhone/iPad and Android
With the Kia Service, you have (almost) all Kia dealers in Europe within reach*. Looking for a showroom or just a service, the app displays all dealers around your current location on the map. With one click you can call a dealer, visit their website or get directions to the showroom. Great for travel at home or abroad.
(*) In selected markets only

The Kia Service App
