Shutter control unit
quick instructions
Product description
The Bosch Smart Home shutter control unit
replaces existing traditional switches which
have a wired connection to the shutters.
Description of the symbols
Safety instructions
▶ The device is not a toy! Do not allow children
to play with it. Never leave the packaging
material lying around unattended. Plastic film
and small parts may pose a danger to chil-
dren.
▶ A remote control or automated control sys-
tem carries a risk that shutters/blinds are
lowered out of the operator's sight and direct
sphere of influence. This unsupervised low-
ering of shutters/blinds can result in personal
injury (including crushing injuries) or prop-
erty damage. Therefore, you must ensure to
Warning!
Note about hazards
Note:
Additional important information
Note about the installation video
Advertisement
Related Manuals for Bosch Shutter Control in-wall AA
Summary of Contents for Bosch Shutter Control in-wall AA
- Page 1 Shutter control unit quick instructions Product description The Bosch Smart Home shutter control unit replaces existing traditional switches which have a wired connection to the shutters. Description of the symbols Warning! Note about hazards Note: Additional important information Note about the installation video Safety instructions ▶...
- Page 2 the greatest extent possible that no people or objects are in the travel path of the shut- ter/blind being controlled. Only use the shut- ter control unit in combination with shut- ters/blinds which are equipped with obstacle detection or for which at least a comparable level of protection with regard to crushing inju- ries is ensured by means of other design fea- tures.
- Page 3 ▶ The device is only intended for private use. You can also use the explanatory videos and additional information on our website as an additional aid for mounting, install- ing, starting up and restoring the factory settings on your Bosch Smart Home shut- ter control unit: www.bosch-smarthome.com/rom/ shutter-control...
- Page 4 Product overview Item Description Shutter control unit Example of a frame (not included in the box contents) Example of an adapter (not included in the box contents) Example of a rocker (not included in the box contents) System button and status LED An adapter (3) is essential for the operation of the shutter control unit (1).
- Page 5 Then use the adapter overview on our website and observe the necessary preparations for mounting where applicable. Information about the adapter set and the adapter sets for brand manufacturers can be found at www.bosch-smarthome.com/rom/ shutter-control-adapter...
- Page 6 The status LED (5) shows the status of the shutter control unit using flashing codes. Status LED flashing Device status Recommended action sequence Flashes orange Tuning mode Please wait (is active) or device is communicating with the controller Flashes green Tuning mode (successful) or process confirmed...
- Page 7 Overloading may result in destruction of the device, fire or an electric shock. The power circuit to which the device and the load are connected must be secured with a circuit breaker in accordance with EN 60898-1 (trigger characteristics B or C, max.
- Page 8 Installation Before you start: Be sure to shut off the power circuit breaker! Remove the existing shutter switch. Connect the shutter control unit in accordance with the con- nection diagram below: Terminal Description External conductor “Down” motor “Up” motor Neutral conductor Attach the shutter control unit to the wall box using the screws included.
- Page 9 Start-up Ensure that you have a Bosch Smart Home con- troller and the Bosch Smart Home app and have successfully configured both. Now start the Bosch Smart Home app and select “Add new device”. Follow the instructions in the app.
- Page 10 When resetting to factory settings, the set- tings and information are only lost from the device and not from the Bosch Smart Home controller. Maintenance and cleaning The device does not require maintenance. Leave any repairs to a specialist.
- Page 11 Simplified declaration of conformity Robert Bosch Smart Home GmbH hereby declare that the radio equipment type Bosch Smart Home Shutter Control in-wall AA corresponds with the directive 2014/53/EU. The complete text of the EU declaration of conformity is available via the following web address: https://eu-doc.bosch.com...
- Page 12 Technical data Device type Shutter Control designation in-wall AA Protection class IP20 Ambient temperature +5 °C - +35 °C Housing dimensions 71 × 71 × 37 mm (W × H × D) Weight 58 g Radio frequency 868.3 MHz / 869.525 MHz Duty cycle <...
- Page 13 Open source software This Bosch Smart Home product uses open- source software. License information for the components used can be found in the attached documents. Service information Robert Bosch Smart Home GmbH Schockenriedstraße 17 70565 Stuttgart-Vaihingen Germany service@bosch-smarthome.com @ www.bosch-smarthome.com/service...
