Bosch Shutter Control in-wall AA Quick Instructions page 6

The status LED (5) shows the status of the shutter
control unit using flashing codes.
Status LED flashing
sequence
Flashes orange
Flashes green
Flashes red
Flashes red 6x
(long)
Notes regarding installation
The standards and directives applicable in
your country must be observed during plan-
ning, set-up, operation and maintenance.
A 230 volt alternating current power supply
is required for this product (the switch must
have a phase and neutral conductor).
The product is only intended for fixed
installation in in-wall switch boxes with a
minimum depth of 50 mm and a screw dis-
tance of 60 mm (in accordance with DIN
49073-1) in indoor areas.
Device status
Tuning mode
(is active) or device
is communicating with
the controller
Tuning mode
(successful) or
process confirmed
Tuning mode
(not successful) or
process failed or max.
wireless duration/hour
reached (duty cycle
limit)
The device is defective
Recommended action
Please wait
If this is the first tuning attempt, please try
again. Otherwise reset the device to the factory
settings and contact the service department if
necessary.
If the wireless duration is exceeded, wait
60 minutes.
Please contact support.
When connecting the device terminals,
ensure that permitted wires and wire cross
sections are used.
The consumers connected to the relay out-
puts must have sufficient insulation.
Observe the technical data, in particular
the maximum permissible switching power
of the relay and the type of consumers to be
connected, before connecting a consumer.
All load information relates to ohmic loads.
The device should only be loaded to the
specified power limit.
