Bosch Shutter Control in-wall AA Quick Instructions page 4

Product overview
5
1
2
3
4
Item Description
1 Shutter control unit
2 Example of a frame
(not included in the box contents)
3 Example of an adapter
(not included in the box contents)
4 Example of a rocker
(not included in the box contents)
5 System button and status LED
An adapter (3) is essential for the operation of
the shutter control unit (1). At the same time, the
adapter (3) is also used to attach the frame (2)
and the rocker (4). For your design freedom, we
offer multiple adapter variants:
1. The adapter set for in-wall switches.
This set includes a rocker with pre-mounted
adapter and the matching frame.
