Quail Digital Pro11 Instruction Manual page 3

Step 2 — Charger
•
To set up the 6-port battery charger,
select a clear desk or cabinet top in
the monitoring room close to a power
socket that DOESN'T get switched off or
unplugged at night.
•
Feed the Q-PSU5 power supply through
the back of the charger and thread the
cable around the gates underneath the
charger. Make sure the PSU is plugged
into the charger before connecting to
the power socket.
•
Switch on the power and the LED on
the front of the charger will show GREEN.
Useful information
• If you have multiple ORs and multiple Pro11 systems, you can move headsets
from one room to another by following
new base, it automatically deregisters from the previous base.
• If you hear 2 beeps in your ear, it means you've gone out of range. Move back
towards the base to which it is registered and the headset will reconnect.
• Batteries will last for 16 hours on standby and up to 10 hours in hands-free
mode. Always put headsets back in the charger when not in use.
• Wipe headsets, head/neckbands, charger and hanger thoroughly with
antibacterial dry wipe as infection control guidelines.
• Call your service provider if you have any problems.
(figure 3)
(figure 4)
figure 3
Feed cable
Power supply plug
figure 4
STEP 4. When a headset is registered to a
Underside
of charger
3
