Summary of Contents for Quail Digital Q-HCBS
- Page 1 User guide HEALTHCARE HEADSET SYSTEM...
-
Page 2: System Components
System components Healthcare Base Station Healthcare Headset Healthcare Charger (Q-HCBS) (Q-P7HS) 6-Port (Q-RCH) HEALTHCARE HEADSET SYSTEM... -
Page 3: Table Of Contents
Contents Installing the system Positioning the charger Registering and using headsets Product specification Frequently asked questions Troubleshooter... -
Page 4: Installing The System
Installing the system Important note: Your headsets should be fully charged before commissioning the system. Begin the installation process by connecting the charger and placing all headsets on it. The blue LED on the headsets will flash during the charge process. Batteries will arrive partially charged. - Page 5 Healthcare Base Station The Base Station has two LEDs on the front facia. Power illuminated when power is on Status flashes when a headset is in talk mode Base Station features There are 4 connectors on the top of the Base.
-
Page 6: Positioning The Charger
Positioning the charger The Healthcare Headset System comes with one or more charger. Chargers should be located within transmit range (same or annexed room) of the Base so that headsets activate automatically when they’re taken out of the charger. Make sure the charger remains plugged in at all times, day and night - shown by the illuminated red LED. -
Page 7: Registering And Using Headsets
Registering and using headsets Each headset needs to be registered to the system for the first time before use. The system has the capacity for 30 headsets at any one time. New or additional headsets can be added at any time by following the registration process. - Page 8 Multiple systems in the same premises It’s quite normal to use multiple systems in the same premises - and systems won’t interfere with one another. But if you swap headsets between systems, thus taking a headset from system A and registering it to system B, you should clear its registration from system A;...
- Page 9 Audible tones for different headset status and functions: STATUS TONE Registration mode 1 beep every second Out of range 2 beeps every 10 seconds Battery low 3 beeps every 60 seconds Registration complete 1 long beep (3 seconds) Busy tone 3 long beeps Headset not registered 1 beep every 3 seconds...
-
Page 10: Product Specification
Product specifications HEALTHCARE BASE STATION Q-HCBS Operating frequency 1.88-1.90 GHz EMEA, Asia, 1.910-1.930 GHz North America Headset capacity 30 headsets (6 in talk mode at one time Power requirements 100-240v AC voltage sensing Dimensions HxWxD 168 x 128 x 36 mm... - Page 11 HEALTHCARE CHARGER Q-RCH Capacity for headsets 6 port Power indicator Red LED Mounting Shelf / desktop Power requirements 100-240v AC voltage sensing Dimensions HxWxD 110 x 330 x 96 mm Weight 680g HEALTHCARE ACCESSORIES NECKBAND Q-RH7NB HEADBAND Q-RH7HB BATTERY Q-RH7BAT POWER ADAPTER Q-48V HEADSET CHARGER SHELF Q-P7SHELF HYGIENE COVERS...
-
Page 12: Frequently Asked Questions
Frequently asked questions Up to 6 people can use No. Anyone else pressing their talk-button will TalkLock at one time. If 6 hear an engaged tone and cannot enter the people are using call. TalkLock, can anyone else speak on the system? How are the 6 speech As soon as the 6th user engages TalkLock they... - Page 13 Two methods are recommended: 1) connect speakers onto the from Q-HCBS output socket into PC speakers; system? 2) connect from Q-HCBS output socket to PA amplifier of your choice and then into ceiling and wall mounted speakers. Seek advice from your AV specialist.
-
Page 14: Troubleshooter
Troubleshooter F A U L T A C T I O N None of the headsets Always check the headsets are registered. are working Check the Base power LED is illuminated. If not, check the mains power is on. If yes, power supply or Base may be faulty. - Page 16 Quail Digital North America 200 East Randolph Street, Suite 5100, Chicago, IL 60601 sales@quaildigital.com Toll Free 1-888-575-1010 Service 1-888 575 1016 Quail Digital Europe 92 Lots Road, London SW10 0QD sales@quaildigital.com Tel: +44 (0)20 7349 2000 Service +44 (0)8706 087 087...
