SPECIFICATIONS
Model
Rated voltage
No-load speed
Cutting length
Tooth space
Cutting capacity
Blade thickness
Collapsing height
Angle modulation
Weight (tool only)
*20V Max battery, maximum initial battery
voltage (measured without a workload) is 20V.
The nominal voltage is 18V.
ASSEMBLY
1.
Unpack all parts and lay them on a flat,
stable surface:
2.
Remove all packing materials and shipping
devices, if applicable.
3.
The scope of delivery varies depending on
the country and purchased variant.
Model of HTPX2-M-EU
•
Pole Hedge Trimmer x1
•
Blade Cover x1
•
Shouler Strap x1
•
Instruction Manual x1
4.
If you find that parts are missing or show
damage do not use the product but
contact your dealer. Using an incomplete
or damaged product represents a hazard
to people and property.
5.
Ensure that you have all the accessories
and tools needed for assembly and
operation. This also includes suitable
personal protective equipment.
EN - 8
HTPX2-M-EU
18 V (20 V Max*)
2 300 spm
450 mm
28 mm
20 mm
1.5 mm
1.85 - 2.35 m
-60°/-30°/ 0
/30°/60°/90°
3.2 kg
WARNING!
Wear protective gloves for this
assembly work and always lay the
product on a flat and stable surface
while assembling.
Follow the assembly instructions
step-by-step and use the pictures
provided as a visual guide to easily
assemble the product! Do not insert
the battery pack before the power
tool is completely assembled or
adjusted!
CONNECTING THE POLE
AND THE TRIMMER HEAD
WARNING!
To avoid serious personal injury and damage
to the unit, shut the unit off before removing or
installing an attachment.
1. Align the telescopic pole with the trimmer
head.
Locking Sleeve
Telescopic Ploe
2. Insert the telescopic pole to the locking
base until the lock holes click into place.
The grooves must be aligned with the arrow
positions near the locking base.
3. Slide the locking sleeve to the locking base
and rotate clockwise till fully tighten.
Locking Base
Lock Holes
Fig. 1
SENIX.COM.AU
