- Page 1 ARTICULATED ARM OPENERS 24V DC MOTOR FOR RESIDENTIAL USER MANUAL GTR502 & GTR503 ARTICULATED ARM OPENERS 24V DC MOTOR FOR RESIDENTIAL USER MANUAL GTR502 & GTR503 ARTICULATED ARM OPENERS 24V DC MOTOR FOR RESIDENTIAL USER MANUAL...
- Page 2 1.1 WARNING: This user manual is only for qualified technicians who is specialized in installations and automations. All installations, electrical connections, adjustments, and testing must be performed only after reading and understanding of all instructions carefully. Before carrying out any installation or maintenance operation, disconnect the electrical power supply by turning off the magneto thermic switch connected upstream and apply the hazard area notice required by applicable regulations.
-
Page 3: Table Of Contents
CONTENTS 1.2 Installation 1.2.1 Standard Installation 1.2.2 Dimension Chart 1.2.3 Components of Installation 1.2.4 Installation of Articulated Arm Opener 1.2.5 Emergency Release 2.1 Wiring Connection 2.1.1 Master Motor is installed at right side 2.1.2 Master Motor is installed at left side 3. -
Page 4: Installation
1.2 Installation 1.2.1 Standard Installation 2x1.5 mm 4x0.5 mm RX - 4x0.5 mm TX - 4x0.5 mm 2x1.5 mm 2x1.5 mm 1. 24V DC blinker with integrated antenna 2. Push Button 3. Photocells 4. 24V DC articulated arm opener 5. TM3 Transmitter 1.2.2 Dimension Chart Please comply with the measures shown on the chart for Inward Opening... -
Page 5: Components Of Installation
Straight arm 1 pce 1.2.3 Components of Installation Curved arm 1 pce U-shaped fixing plate 1 pce Mechanical stopper 2 pcs Front-end fixing bracket 1 pce Screw 4 pcs Nut Ø10 2 pcs Screw 2 pcs Gasket 2 pcs Screw 2 pcs Spring washer 4 pcs... -
Page 6: Emergency Release
5) Closed position adjustment: 5.1 After the full closed position decided, fix the corresponding mechanical stopper at the position. 5.2 After the full closed position decided, make the pointer on limit switch aligned with the pointer on the curved arm. (Red points shown on the figure below indicate the pointers) 6) Opened position adjustment: 6.1 Adjust the gate to full opened position and after the position decided, fixe with corresponding mechanical stopper. -
Page 7: Wiring Connection
2.1 Wiring Connection Figure 2(1) Flashing Light Electric Lock Push Button Key Selector NO NC COM WiFi box 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10 PhVcc Ph2 GND PhVcc Ph1 GND SKey DKey GND Lmt4 Lmt3 GND Lmt2 Lmt1 GND S2 M2- M2+ M1- M1+ Lat- Lat+ Lit- Lit+... -
Page 8: Master Motor Is Installed At Right Side
2.1.1 Master Motor is installed at right side Figure 2(2) Motor1 Power Motor2 Power PhVcc Ph2 GND PhVcc Ph1 GND SKey DKey GND Lmt4 Lmt3 GND Lmt2 Lmt1 GND M1- M1+ Lat- Lat+ Lit- Lit+ 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 Motor with Limit switch Figure 2(3) -
Page 9: Master Motor Is Installed At Left Side
2.1.2 Master Motor is installed at left side Figure 2(5) Motor2 Power Motor1 Power PhVcc Ph2 GND PhVcc Ph1 GND SKey DKey GND Lmt4 Lmt3 GND Lmt2 Lmt1 GND M1- M1+ Lat- Lat+ Lit- Lit+ 26 25 24 23 22 21 20 19 18 17 16 15 14 13... -
Page 10: Get Started
3. Get Started Note: (A) Remote memorizing must be done before system learning. (B) Verifying the GATE CONDITION. 1) Release the gear with the release key and move the gate to the middle so the gate can move in both opening and closing directions;... -
Page 11: Step 2: System Learning
Step 2: System Learning Note – Before performing system learning, check your system parameters. 3.2 Step 2: System Learning DOWN “F1” should be set to single or double (factory default is double) Step 2: System Learning Note – Before performing system learning, check your system parameters. RF-LEARN Step1: Note –... -
Page 12: Gate-Moving Logic
3.3 Gate-moving Logic (A) In gate-opening phase: The gates stop if the transmitter/push button/key selector is activated, and close when the transmitter/push button/key selector is reactivated. (B) In gate-closing phase: The gates stop if the transmitter/push button/key selector is activated, and open when the transmitter/push button/key selector is reactivated. -
Page 13: Parameter
3. 6 Parameter 3.6.1 Parameter Learning Push Push Push DOWN DOWN DOWN Press "SET" for 3 secs to get into the Press "SET" button again to get Press "UP" or "DOWN" to change program setting display from F1 into the sub-setting setting items from F1 to FW. - Page 14 LED Display Definition Parameter Table Description 20% of full speed 1. The factory setting is "F73". Deceleration Speed for Opening 30% of full speed 40% of full speed (Default) 50% of full speed 20% of full speed 1. The factory setting is "F83". Deceleration Speed for Closing 30% of full speed 40% of full speed (Default)
- Page 15 LED Display Definition Parameter Table Description 1. Please see 3.6.3 photocell adjustment for photocell Mode 1 (Default) Safety Device Function Mode logic Mode 2 2. The factory setting is "FE1". Mode 3 Mode 4 Pedestrian Mode Function OFF 1. The factory setting is "FF1". 2.
-
Page 16: Photocell Logic
LED Display Definition Parameter Table Description PB Function D Key Function (PCB Terminal) 1. The factory setting " FT1" 2. Fire Alarm Mode: Open-Stop-Close-Stop (Default) * Terminal Detect NO Open ONLY - normal operation * Terminal Detect NC Pedestrian Mode - Open the gate and lock all the functions before Close ONLY returning to NO... -
Page 17: Dimension
Open Only Device (Vehicle detector) Position of Gate When safety devices are activated Type of Safety Device Photocell-CLOSE Opening Device FULLY CLOSED Open No effect FULLY OPENED Reload automatic closing time STOP DURING MOVING Reload automatic closing time Open CLOSING Open Open OPENING... -
Page 18: Technical Feature
5. Technical Feature: Model GTR502 & GTR503 Motor 24Vdc motor Gear type Electromechanical worm gear Nominal thrust 2500N Maximum Gate Weight 250 kg per leaf Maximum Gate Length 2.5 meters per leaf Operating Temperature C~+50 Dimension 256 x 187 x 267mm... -
Page 19: Technical Support
NZ: 0800 61 71 81 International: +613 9551 2233 Richmond Wheel & Castor Co. declines all responsibility for any consequences resulting from improper use of the product or use which is different from the expected and specified in the present documentation. - Page 20 Key Release Silence EZ Instal Low Voltage Durability 24V power supply Solid material apply Manual release device Worm gear application Easy installation for great safety with lasting usage with easy use and give silence operation and user friendly highly protection interface ARTICULATED ARM OPENERS USER MANUAL...
