- Page 1 GTR502 & GTR503 ARTICULATED ARM OPENERS 24V DC MOTOR FOR RESIDENTIAL USER MANUAL Software Version: PS21068B...
-
Page 2: Table Of Contents
INDEX 1.2 Installation 1.2.1 Standard Installation 1.2.2 Dimension Chart 1.2.3 Components of Installation 1.2.4 Installation of Articulated Arm Opener 1.2.5 Emergency Release 1.2.6 Wi-Fi Device (Sold Seperately) 1.2.7 Photocells (Sold Seperately) 1.2.8 Power Supply Connections 2.1 Wiring Connection 2.1.1 Master Motor is installed at right side 2.1.2 Master Motor is installed at left side 3. -
Page 3: Installation
1.2 Installation 1.2.1 Standard Installation 2x1.5 mm 4x0.5 mm RX - 4x0.5 mm TX - 4x0.5 mm 2x1.5 mm 2x1.5 mm 1. 24V DC blinker with integrated antenna 2. Push Button 3. Photocells 4. 24V DC articulated arm opener 5. TM3 Transmitter 1.2.2 Dimension Chart Please comply with the measures shown on the chart for Inward Opening... -
Page 4: Components Of Installation
Straight arm 1 pce 1.2.3 Components of Installation Curved arm 1 pce U-shaped fixing plate 1 pce Mechanical stopper 2 pcs Front-end fixing bracket 1 pce Screw 4 pcs Nut Ø10 2 pcs Screw 2 pcs Gasket 2 pcs Screw 2 pcs Spring washer 4 pcs... -
Page 5: Emergency Release
5) Closed position adjustment : 5.1 After the full closed position decided, fix the corresponding mechanical stopper at the position. 5.2 After the full closed position decided, make the pointer on limit switch aligned with the pointer on the curved arm. (Red points shown on the figure below indicate the pointers) 6) Opened position adjustment : 6.1 Adjust the gate to full opened position and after the position decided, fixe with corresponding mechanical stopper. -
Page 6: Photocells (Sold Seperately)
1.2.7 Photocells (Sold Seperately) The safety photocells are security devices for control automatic gates. Consist of one transmitter and one receiver based in waterproof covers; it is triggered while breaking the path of the beams. SPECIFICATION: Detection Method Through Beam Sensing Range MAX~15m Input Voltage... -
Page 7: Wiring Connection
2.1 Wiring Connection Figure 2(1) Electric Lock Flashing Light Push Button Key Selector WiFi box 11 10 PhVcc PhVcc - t i LED3 LED4 LED2 LED2 Push button or Key selector LED3 Photocell 1 LED 4 Photocell 2 RF-LEARN LED Display DOWN 24V D/C 24V A/C... -
Page 8: Master Motor Is Installed At Right Side
2.1.1 Master Motor is installed at right side Figure 2(2) Motor1 Power Motor2 Power PhVcc PhVcc SKey DKey Lmt4 Lmt3 Lmt2 Lmt1 Lat- Lat+ Lit- Lit+ Motor with Limit switch Figure 2(3) Limit Switch Limit Switch Motor1 Power Motor2 Power Limit1 Limit2 Limit4... -
Page 9: Master Motor Is Installed At Left Side
2.1.2 Master Motor is installed at left side Figure 2(5) Motor2 Power Motor1 Power PhVcc PhVcc SKey DKey Lmt4 Lmt3 Lmt2 Lmt1 Lat- Lat+ Lit- Lit+ 24 23 16 15 Motor with Limit switch Figure 2(6) Limit Switch Limit Switch Motor2 Power Motor1 Power Limit4... -
Page 10: Get Started
3. Get Started Note: (A) Remote memorizing must be done before system learning. (B) Verifying the GATE CONDITION. 1) Release the gear with the release key and move the gate to the middle so the gate can move in both opening and closing directions;... -
Page 11: Step 2: System Learning
3.2 Step 2: System Learning DOWN Step1: Press and hold SET & DOWN buttons for 3 secs till the LED shows “LEA”. Within 20 secs, press the "open-stop- RF-LEARN close-stop" button on the remote or SET button on the control board. Then the motor runs the system learning procedure automatically. -
Page 12: Gate-Moving Logic
3.3 Gate-moving Logic (A) In gate-opening phase: The gates stop if the transmitter/push button/key selector is activated, and close when the transmitter/push button/key selector is reactivated. (B) In gate-closing phase: The gates stop if the transmitter/push button/key selector is activated, and open when the transmitter/push button/key selector is reactivated. -
Page 13: Parameter
3. 6 Parameter 3.6.1 Parameter Learning Push Push Push DOWN DOWN DOWN Press "SET" for 3 secs to get into the Press "UP" or "DOWN" to change Press "SET" button again to get program setting display from F1 into the sub-setting setting items from F1 to FW. - Page 14 LED Display Definition Parameter Table Description LED1 LED1 LED1 LED2 LED2 LED2 20% of full speed 1. The factory setting is "F73". Deceleration Speed for Opening LED3 LED3 LED3 30% of full speed 40% of full speed (Default) 50% of full speed 20% of full speed 1.
- Page 15 LED Display Definition Parameter Table Description LED Display Definition Parameter Table Description 1. Please see 3.6.3 photocell adjustment for photocell Mode 1 (Default) Safety Device Function Mode logic Mode 2 2. The factory setting is "FE1". Mode 3 Mode 4 Pedestrian Mode Function OFF 1.
-
Page 16: Photocell Logic
LED Display Definition Parameter Table Description P P ar Description D Key Function (PCB Terminal) PB Function: 1. The factory setting is "FT1" 2. Fire Alarm Mode: Open-Stop-Close-Stop (Default) * Terminal Detect NO Open ONLY - normal operation LED Display * Terminal Detect NC Pedestrian Mode - Open the gate and lock all the functions before... -
Page 17: Dimension
Open Only Device (Vehicle detector) Position of Gate When safety devices are activated Type of Safety Device Photocell-CLOSE Opening Device FULLY CLOSED Open No effect FULLY OPENED Reload automatic closing time STOP DURING MOVING Reload automatic closing time Open CLOSING Open Open OPENING... -
Page 18: Maintenance
5. Technical Feature: Model GTR502 & GTR503 Motor 24Vdc motor Gear type Electromechanical worm gear Nominal thrust 2500N Maximum Gate Weight 250 kg per leaf Maximum Gate Length 2.5 meters per leaf Operating Temperature C~+50 Dimension 256 x 187 x 267mm... -
Page 19: Technical Support
NZ: 0800 61 71 81 International: +613 9551 2233 Richmond Wheel & Castor Co. declines all responsibility for any consequences resulting from improper use of the product, or use which is different from the expected and specified in the present documentation. - Page 20 Key Release Silence EZ Instal Low Voltage Durability 24V power supply Solid material apply Manual release device Worm gear application Easy installation for great safety with lasting usage with easy use and give silence operation and user friendly highly protection interface...
