Digital View DVS-1600
High Integration Interface Controller
A l l t r a d e m a r k s , b r a n d n a m e s , a n d b r a n d s a p p e a r i n g h e r e i n a r e t h e p r o p e r t y o f t h e i r r e s p e c t i v e o w n e r s .
• C r i t i c a l a n d e x p e d i t e d s e r v i c e s
• I n s t o c k / R e a d y - t o - s h i p
Artisan Scientific Corporation dba Artisan Technology Group is not an affiliate, representative, or authorized distributor for any manufacturer listed herein.
In Stock
Used and in Excellent Condition
Open Web Page
https://www.artisantg.com/50791-1
• We b u y y o u r e x c e s s , u n d e r u t i l i z e d , a n d i d l e e q u i p me n t
• F u l l - s e r v i c e , i n d e p e n d e n t r e p a i r c e n t e r

Advertisement

loading
Need help?

Need help?

Do you have a question about the DVS-1600 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Digital View DVS-1600

  • Page 1 Digital View DVS-1600 High Integration Interface Controller In Stock Used and in Excellent Condition Open Web Page https://www.artisantg.com/50791-1 A l l t r a d e m a r k s , b r a n d n a m e s , a n d b r a n d s a p p e a r i n g h e r e i n a r e t h e p r o p e r t y o f t h e i r r e s p e c t i v e o w n e r s .
  • Page 2 25. Appendix II – RS-232 control protocols 29. Appendix III – Mapping definition 31. Appendix IV – Auto Color Gain 32. Appendix V – DV remote control unit work for DVS-1600 33. Warranty, Caution & Limitation of Liability, Trademarks 34. Contact details It is essential that these instructions are read and understood before connecting or powering up this controller.
  • Page 3 Introduction Designed for LCD monitor and other flat panel display applications, the DVS-1600 controller provides easy to use interface controller for: TFT (active matrix) LCDs with LVDS / TTL single pixel interface of 1680x1050, 1600x1200, 1400x1050, 1440x900, 1366x768, 1280x1024, 1280x800, 1280x768, 1024x768, 1024x600, 800x600, 800x480, 640x480, 480x640 resolution...
  • Page 4 14. Analog VGA input / Composite 1 / S-Video 1 input 15. DVI-D input 16. Power input (12VDC / 24VDC) Digital View offers a range of accessories such as listed above, to make up complete display solution. - Support on V1.10.00 or up firmware revision. © Digital View Ltd 2010 www.digitalview.com...
  • Page 5 - AV cables: Standard Composite or S-video cables can be used. Reasonable quality cable should be used to avoid image quality degradation. 15. DVI-D input cable : Plug the DVI cable to the connector P2 on the controller board. © Digital View Ltd 2010 www.digitalview.com Page 4 of 34...
  • Page 6 • Refer to graphics modes table in specifications section for supported modes. • Non-interlaced & interlaced video input is acceptable. IMPORTANT: Please read the Application Notes section for more information. © Digital View Ltd 2010 www.digitalview.com Page 5 of 34...
  • Page 7 Once the system has been connected and switched on there are a number of functions available to adjust the display image as summarized in the following sections. The settings chosen will be saved for each mode independently. © Digital View Ltd 2010 www.digitalview.com...
  • Page 8 Select input source to Composite 2 (No function now) Auto Source Seek ON – Auto source select always enable OFF – Disable auto source select function Video system selection* 4 © Digital View Ltd 2010 www.digitalview.com Page 7 of 34...
  • Page 9 Adjust Gamma settings (0.4 / 0.6 / 1.0 / 1.6 / 2.2) Gamma adjustment4 Select Gamma to 0.4 Select Gamma to 0.6 Select Gamma to 1.0 Select Gamma to 1.6 Select Gamma to 2.2 © Digital View Ltd 2010 www.digitalview.com Page 8 of 34...
  • Page 10 [Firmware version : V1.10.00 or up] * - Function in Video mode only # - Function in ARGB mode only Items marked 4 have sub menus. Exit the OSD menu to save the setting chosen © Digital View Ltd 2010 www.digitalview.com Page 9 of 34...
  • Page 11 (Mating type : Molex 43645-0200 compatible) (Matching power cable : P/N 426013800-3) S-video in Mini din 4-way Composite video in BNC connector - Support in V1.10.00 firmware or up revision. © Digital View Ltd 2010 www.digitalview.com Page 10 of 34...
  • Page 12 Input voltage via Panel Voltage Jumper on board 3.3V 3V3 closed 1-3 & 2-4 12VDC 5V closed 1-3 & 2-4 OPEN 5-7 & 6-8 CAUTION: Incorrect setting can damage panel & controller © Digital View Ltd 2010 www.digitalview.com Page 11 of 34...
  • Page 13 CNB1 pin 2 will output 24VDC if input 24VDC via PP2. JA3 & JA6 location on board : (Please pay attention to the jumper settings on JA3 & JA6 which are red in color) © Digital View Ltd 2010 www.digitalview.com Page 12 of 34...
  • Page 14 1024x600 Sharp LS037V7DW03 (Tested) 480x640 For additonal and recent added panels, see DVS-1600 panel support table at http://www.digitalview.com/controllers/csg.php Support in V1.06.00 or up firmware version or up only. Support in V1.10.00 or up firmware version or up only. Support in V1.15.00 or up firmware version or up only.
  • Page 15 A and B. Reserved Selection of TTL / LVDS panel ON : LVDS connection OFF : TTL The most current list can be found the controller solution generator at http://www.digitalview.com/controllers/csg.php © Digital View Ltd 2010 www.digitalview.com Page 14 of 34...
  • Page 16 No connection No connection Data bit G0 Data bit G1 Data bit G2 Data bit G3 Data bit G4 Data bit G5 Data bit G6 Data bit G7 Ground Ground © Digital View Ltd 2010 www.digitalview.com Page 15 of 34...
  • Page 17 S-Video : Chroma in S-Video : Luma in Ground Ground Composite video 1 in LED1 – Controller status LED connector: 3-pin header DESCRIPTION Green LED pin (anode) LED pin common (cathode) © Digital View Ltd 2010 www.digitalview.com Page 16 of 34...
  • Page 18 No connection PP2 – Alternate 12VDC power supply DESCRIPTION +12VDC 5A max / +24VDC 5A max Ground PP5 - Power supply DESCRIPTION +12VDC 5A max / +24VDC 5A max Ground © Digital View Ltd 2010 www.digitalview.com Page 17 of 34...
  • Page 19 Any of the holes shown above can be used for mounting the PCB, they are 3.2mm in diameter. CAUTION: Ensure adequate insulation is provided for all areas of the PCB with special attention to high voltage parts such as the inverter. © Digital View Ltd 2010 www.digitalview.com Page 18 of 34...
  • Page 20 CNB1 pins 4 & 5 are available for connecting to an inverter or circuit where VR control is supported. CNB1 DESCRIPTION VR WIP VR A This can then be matched with function controls (OSD switch mount) pins 3 & 4: see cable design below . © Digital View Ltd 2010 www.digitalview.com Page 19 of 34...
  • Page 21 To evaluate, plug in different values of Rbc : BVR_WIP 2.5 K 1.2 V 2.4 V 7.5 K 3.6 V 10 K 4.8 V So this circuit could provide Brightness adjust voltage ranging from 0V to 5V. © Digital View Ltd 2010 www.digitalview.com Page 20 of 34...
  • Page 22 If unit after unit keeps failing consider and investigate whether you are short circuiting the equipment or doing something else seriously wrong. Generally after common sense issues have been resolved we recommend step by step substitution of known working parts to isolate the problem. © Digital View Ltd 2010 www.digitalview.com Page 21 of 34...
  • Page 23 For specific panel setup a sample of an LCD may be required (this will be returned) and a copy of the full technical specifications for the panel from the manufacturer. • Relayout and custom development services are available. © Digital View Ltd 2010 www.digitalview.com Page 22 of 34...
  • Page 24 The controller has been designed to take a very wide range of input signals however to optimize the PC’s graphics performance we recommend choosing 60Hz vertical refresh rate. To support on higher refresh rate over 60Hz, the LCD panel may not support. © Digital View Ltd 2010 www.digitalview.com Page 23 of 34...
  • Page 25 COMPOSITE, S-VIDEO INPUT PORT : System Resolution Horizontal freq Vertical freq [KHz] [Hz] NTSC 720x480 15.7 NTSC 4.43 720x480 15.7 720x576 15.6 PAL M 720x576 15.6 SECAM 720x576 15.6 © Digital View Ltd 2010 www.digitalview.com Page 24 of 34...
  • Page 26 (In ARGB mode only) “?” Query Image H position 0x86, Set img_hpos = Image horizontal position. nnnn | “+” | “-” | value/increment/decrement (In ARGB mode only) “?” Query © Digital View Ltd 2010 www.digitalview.com Page 25 of 34...
  • Page 27 Green level for selected colour selected colour channel for the selected colour temperature. temperature nn | “+” | “-” | temp. = “r” | “R” | value/increment/decrement Range: “8””0”-“F””F” “?” Reset Default: “F””F” © Digital View Ltd 2010 www.digitalview.com Page 26 of 34...
  • Page 28 “0” | “1” | ”2” | “3” Reset “1” – 1360x768 “r” | “R” | Query “2” – 1366x768 “?” “3” – 1368x768 # - Function in ARGB mode only © Digital View Ltd 2010 www.digitalview.com Page 27 of 34...
  • Page 29 0x4C 0x6C 0x4D 0x6D 0x4E 0x6E 0x4F 0x6F 0x50 0x70 0x51 0x71 0x52 0x72 0x53 0x73 0x54 0x74 0x55 0x75 0x56 0x76 0x57 0x77 0x58 0x78 0x59 0x79 0x5A 0x7A © Digital View Ltd 2010 www.digitalview.com Page 28 of 34...
  • Page 30 Appendix III – Mapping definition • Definition of Mapping A : © Digital View Ltd 2010 www.digitalview.com Page 29 of 34...
  • Page 31 • Definition of Mapping B : © Digital View Ltd 2010 www.digitalview.com Page 30 of 34...
  • Page 32 Reset Color Gain function can be used. This function will reset the stored RGB values to a set of approximate values. © Digital View Ltd 2010 www.digitalview.com Page 31 of 34...
  • Page 33 Appendix V – DV remote control unit work for DVS-1600 P/N 559000104-3 : DigitalView remote control unit (without DV logo silk screen printing) P/N 559000103-3 : DigitalView remote control unit (with DigitalView logo silk screen printing) BUTTON FUNCTION POWER BUTTON Soft power ON/OFF button.
  • Page 34 The manufacturer’s liability for damages to customer or others resulting from the use of any product supplied hereunder shall in no event exceed the purchase price of said product. TRADEMARKS The following are trademarks of Digital View Ltd: • Digital View •...
  • Page 35 Sales: hksales@digitalview.com WEBSITE www.digitalview.com Brand names belong to their respective owners. Specifications subject to change without notice. 11th issue: 1 June, 2010 (DVS-1600 –2x manual.doc) © Digital View Ltd 2007-2010 © Digital View Ltd 2010 www.digitalview.com Page 34 of 34...
