PC, DVI, VIDEO INTERFACE CONTROLLER
CONTENTS
Page: 2. Introduction, How to Proceed, Usage Note, Disclaimer
2. System design - Diagram of a suggested system
4. Assembly notes - Important information about system elements
6. Connection & Operation - How to use the controller
10. Connectors, pinouts & jumpers - Essential connection information
33. Warranty, Caution & Limitation of Liability, Trademarks
It is essential that these instructions are read and understood before connecting or
powering up this controller.
© Digital View Ltd 2010
FOR TFT PANEL
Model: DVS-1600
Part number : 41714002X-3
INSTRUCTIONS
www.digitalview.com
Page 1 of 34
Advertisement
Table of Contents
Related Manuals for Digital View 41714002X-3
Summary of Contents for Digital View 41714002X-3
-
Page 1: Table Of Contents
PC, DVI, VIDEO INTERFACE CONTROLLER FOR TFT PANEL Model: DVS-1600 Part number : 41714002X-3 INSTRUCTIONS CONTENTS Page: 2. Introduction, How to Proceed, Usage Note, Disclaimer 2. System design – Diagram of a suggested system 4. Assembly notes – Important information about system elements 6. -
Page 2: System Design
LCD controller card, DVS-1600 LVDS cable (for connection with LVDS panel) TTL cable (for connection with TTL panel) Inverter for CCFT backlight (if not built into LCD) Inverter cable Function controls © Digital View Ltd 2010 www.digitalview.com Page 2 of 34... - Page 3 14. Analog VGA input / Composite 1 / S-Video 1 input 15. DVI-D input 16. Power input (12VDC / 24VDC) Digital View offers a range of accessories such as listed above, to make up complete display solution. - Support on V1.10.00 or up firmware revision. © Digital View Ltd 2010 www.digitalview.com...
-
Page 4: Assembly Notes
- AV cables: Standard Composite or S-video cables can be used. Reasonable quality cable should be used to avoid image quality degradation. 15. DVI-D input cable : Plug the DVI cable to the connector P2 on the controller board. © Digital View Ltd 2010 www.digitalview.com Page 4 of 34... - Page 5 • Refer to graphics modes table in specifications section for supported modes. • Non-interlaced & interlaced video input is acceptable. IMPORTANT: Please read the Application Notes section for more information. © Digital View Ltd 2010 www.digitalview.com Page 5 of 34...
-
Page 6: Connection And Operation
Once the system has been connected and switched on there are a number of functions available to adjust the display image as summarized in the following sections. The settings chosen will be saved for each mode independently. © Digital View Ltd 2010 www.digitalview.com... - Page 7 Select input source to Composite 2 (No function now) Auto Source Seek ON – Auto source select always enable OFF – Disable auto source select function Video system selection* 4 © Digital View Ltd 2010 www.digitalview.com Page 7 of 34...
- Page 8 Adjust Gamma settings (0.4 / 0.6 / 1.0 / 1.6 / 2.2) Gamma adjustment4 Select Gamma to 0.4 Select Gamma to 0.6 Select Gamma to 1.0 Select Gamma to 1.6 Select Gamma to 2.2 © Digital View Ltd 2010 www.digitalview.com Page 8 of 34...
- Page 9 [Firmware version : V1.10.00 or up] * - Function in Video mode only # - Function in ARGB mode only Items marked 4 have sub menus. Exit the OSD menu to save the setting chosen © Digital View Ltd 2010 www.digitalview.com Page 9 of 34...
-
Page 10: Connectors, Pinouts & Jumpers
(Mating type : Molex 43645-0200 compatible) (Matching power cable : P/N 426013800-3) S-video in Mini din 4-way Composite video in BNC connector - Support in V1.10.00 firmware or up revision. © Digital View Ltd 2010 www.digitalview.com Page 10 of 34... - Page 11 Input voltage via Panel Voltage Jumper on board 3.3V 3V3 closed 1-3 & 2-4 12VDC 5V closed 1-3 & 2-4 OPEN 5-7 & 6-8 CAUTION: Incorrect setting can damage panel & controller © Digital View Ltd 2010 www.digitalview.com Page 11 of 34...
- Page 12 CNB1 pin 2 will output 24VDC if input 24VDC via PP2. JA3 & JA6 location on board : (Please pay attention to the jumper settings on JA3 & JA6 which are red in color) © Digital View Ltd 2010 www.digitalview.com Page 12 of 34...
- Page 13 Support in V1.10.00 or up firmware version or up only. Support in V1.15.00 or up firmware version or up only. Support in V1.18.00 or up firmware version or up only. * Support 640x480 input resolution signal only. © Digital View Ltd 2010 www.digitalview.com Page 13 of 34...
- Page 14 A and B. Reserved Selection of TTL / LVDS panel ON : LVDS connection OFF : TTL The most current list can be found the controller solution generator at http://www.digitalview.com/controllers/csg.php © Digital View Ltd 2010 www.digitalview.com Page 14 of 34...
- Page 15 No connection No connection Data bit G0 Data bit G1 Data bit G2 Data bit G3 Data bit G4 Data bit G5 Data bit G6 Data bit G7 Ground Ground © Digital View Ltd 2010 www.digitalview.com Page 15 of 34...
- Page 16 S-Video : Chroma in S-Video : Luma in Ground Ground Composite video 1 in LED1 – Controller status LED connector: 3-pin header DESCRIPTION Green LED pin (anode) LED pin common (cathode) © Digital View Ltd 2010 www.digitalview.com Page 16 of 34...
- Page 17 No connection PP2 – Alternate 12VDC power supply DESCRIPTION +12VDC 5A max / +24VDC 5A max Ground PP5 - Power supply DESCRIPTION +12VDC 5A max / +24VDC 5A max Ground © Digital View Ltd 2010 www.digitalview.com Page 17 of 34...
-
Page 18: Controller Dimensions
Any of the holes shown above can be used for mounting the PCB, they are 3.2mm in diameter. CAUTION: Ensure adequate insulation is provided for all areas of the PCB with special attention to high voltage parts such as the inverter. © Digital View Ltd 2010 www.digitalview.com Page 18 of 34... -
Page 19: Application Notes
CNB1 pins 4 & 5 are available for connecting to an inverter or circuit where VR control is supported. CNB1 DESCRIPTION VR WIP VR A This can then be matched with function controls (OSD switch mount) pins 3 & 4: see cable design below . © Digital View Ltd 2010 www.digitalview.com Page 19 of 34... - Page 20 To evaluate, plug in different values of Rbc : BVR_WIP 2.5 K 1.2 V 2.4 V 7.5 K 3.6 V 10 K 4.8 V So this circuit could provide Brightness adjust voltage ranging from 0V to 5V. © Digital View Ltd 2010 www.digitalview.com Page 20 of 34...
-
Page 21: Troubleshooting
If unit after unit keeps failing consider and investigate whether you are short circuiting the equipment or doing something else seriously wrong. Generally after common sense issues have been resolved we recommend step by step substitution of known working parts to isolate the problem. © Digital View Ltd 2010 www.digitalview.com Page 21 of 34... -
Page 22: Specifications
For specific panel setup a sample of an LCD may be required (this will be returned) and a copy of the full technical specifications for the panel from the manufacturer. • Relayout and custom development services are available. © Digital View Ltd 2010 www.digitalview.com Page 22 of 34... -
Page 23: Appendix I - Graphic & Video Mode Support Table
The controller has been designed to take a very wide range of input signals however to optimize the PC’s graphics performance we recommend choosing 60Hz vertical refresh rate. To support on higher refresh rate over 60Hz, the LCD panel may not support. © Digital View Ltd 2010 www.digitalview.com Page 23 of 34... - Page 24 COMPOSITE, S-VIDEO INPUT PORT : System Resolution Horizontal freq Vertical freq [KHz] [Hz] NTSC 720x480 15.7 NTSC 4.43 720x480 15.7 720x576 15.6 PAL M 720x576 15.6 SECAM 720x576 15.6 © Digital View Ltd 2010 www.digitalview.com Page 24 of 34...
-
Page 25: Appendix Ii - Rs-232 Control Protocols
(In ARGB mode only) “?” Query Image H position 0x86, Set img_hpos = Image horizontal position. nnnn | “+” | “-” | value/increment/decrement (In ARGB mode only) “?” Query © Digital View Ltd 2010 www.digitalview.com Page 25 of 34... - Page 26 Green level for selected colour selected colour channel for the selected colour temperature. temperature nn | “+” | “-” | temp. = “r” | “R” | value/increment/decrement Range: “8””0”-“F””F” “?” Reset Default: “F””F” © Digital View Ltd 2010 www.digitalview.com Page 26 of 34...
- Page 27 “0” | “1” | ”2” | “3” Reset “1” – 1360x768 “r” | “R” | Query “2” – 1366x768 “?” “3” – 1368x768 # - Function in ARGB mode only © Digital View Ltd 2010 www.digitalview.com Page 27 of 34...
- Page 28 0x4C 0x6C 0x4D 0x6D 0x4E 0x6E 0x4F 0x6F 0x50 0x70 0x51 0x71 0x52 0x72 0x53 0x73 0x54 0x74 0x55 0x75 0x56 0x76 0x57 0x77 0x58 0x78 0x59 0x79 0x5A 0x7A © Digital View Ltd 2010 www.digitalview.com Page 28 of 34...
-
Page 29: Appendix Iii - Mapping Definition
Appendix III – Mapping definition • Definition of Mapping A : © Digital View Ltd 2010 www.digitalview.com Page 29 of 34... - Page 30 • Definition of Mapping B : © Digital View Ltd 2010 www.digitalview.com Page 30 of 34...
-
Page 31: Appendix Iv - Auto Color Gain
Reset Color Gain function can be used. This function will reset the stored RGB values to a set of approximate values. © Digital View Ltd 2010 www.digitalview.com Page 31 of 34... -
Page 32: Appendix V - Dv Remote Control Unit Work For Dvs-1600
In input source selection mode, pressing this button to select S-Video source. TRACK (Comp) BUTTON In input source selection mode, pressing this button to select Composite source. ** Support in V1.18.00 or up firmware version or up only. © Digital View Ltd 2010 www.digitalview.com Page 32 of 34... -
Page 33: Warranty
The manufacturer’s liability for damages to customer or others resulting from the use of any product supplied hereunder shall in no event exceed the purchase price of said product. TRADEMARKS The following are trademarks of Digital View Ltd: • Digital View •... -
Page 34: Contact Details
Sales: hksales@digitalview.com WEBSITE www.digitalview.com Brand names belong to their respective owners. Specifications subject to change without notice. 11th issue: 1 June, 2010 (DVS-1600 –2x manual.doc) © Digital View Ltd 2007-2010 © Digital View Ltd 2010 www.digitalview.com Page 34 of 34...
