PETKIT PUROBOT MAX PRO User Manual

Self-cleaning cat litter box with camera
Hide thumbs

Advertisement

Quick Links

Download this manual
USER MANUAL
PETKIT PUROBOT MAX PRO WITH CAMERA
SELF-CLEANING CAT LITTER BOX
Please read the user manual carefully
before use and keep it properly.

Advertisement

loading
Need help?

Need help?

Do you have a question about the PUROBOT MAX PRO and is the answer not in the manual?

Questions and answers

Related Manuals for PETKIT PUROBOT MAX PRO

Summary of Contents for PETKIT PUROBOT MAX PRO

  • Page 1 USER MANUAL PETKIT PUROBOT MAX PRO WITH CAMERA SELF-CLEANING CAT LITTER BOX Please read the user manual carefully before use and keep it properly.
  • Page 2 TABLE OF CONTENTS PACKAGE LIST PRODUCT DESCRIPTION PRODUCT INSTALLATION PRODUCT USAGE APP FUNCTIONS DESCRIPTION OF CONTROL PANEL CLEANING AND MAINTENANCE VIDEO GUIDE BASIC SPECIFICATIONS A MESSAGE TO OUR VALUED CUSTOMERS SAFETY INSTRUCTIONS...
  • Page 3 RETURN TO CONTENTS PACKAGE LIST * Before installation and use, please check if all the accessories are complete according to the following list : Main Unit User Manual Power Adapter Honeycomb Fine Magnetic Cat Litter Remover Litter Si er P99023 (Exclusive for mineral cat litter) Pet Odor Eliminator Trash Bag...
  • Page 4 RETURN TO CONTENTS PRODUCT DESCRIPTION Cylinder Menu Button Fisheye Camera Non-detachable OLED Display Screen Standard Litter Si er P99022 OK Button (Exclusive for tofu cat litter and mixed cat litter) Wheel Handle (To move the device, li the front side by the handle.) Note: The actual product may di er from the image shown due to continuous product improvements;...
  • Page 5 RETURN TO CONTENTS Magnetic Side Cover High Performance Cat Litter Pad MAX P9220 Air Inlet Camera Indicator Light Microphone Breezy Smart Odor Eliminator Fill Light Power Port Proximity Sensor Waste Bin Lid Position for Placing Y-shaped Slot N50 2.0 Waste Bin Handle of Waste Bin (Press the back latch to pull out the waste bin)
  • Page 6 RETURN TO CONTENTS Introduction to Component Functions Component Name Functional Description Fisheye Camera Real-time monitoring of pet toileting Litter Si er E ectively filter clumps without jamming or missing High Performance Anti-stick, waterproof, scratch-resistant, and easy to clean Cat Litter Pad MAX P9220* Decompose the odor in the waste bin to prevent the Pet Odor Eliminator N50 2.0*...
  • Page 7 RETURN TO CONTENTS PRODUCT INSTALLATION 3.1 Install Trash Bag ❶ Press the latch to the right to open the door. ❷ Press the back latch to pull out the waste bin. ❸ Remove the lid and place the trash bag in the waste bin, ensuring that the trash bag lies flat at the bottom.
  • Page 8 RETURN TO CONTENTS ❹ Pull the drawstring through the Y-shaped slot to secure it. ❺ Install the lid. Note: The buckles should not press against the drawstring, and check if the dashed line is on the edge of the waste bin. Buckle...
  • Page 9 RETURN TO CONTENTS 3.2 Install N50 and N60 ❶ Put the N50 in and press firmly to secure it. ❷ Install the waste bin back. ❸ Close the door. ❹ Remove the magnetic side cover.
  • Page 10 RETURN TO CONTENTS ❺ Put the N60 in the smart odor eliminator. ❻ Install the magnetic side cover back. ❼ Insert the power adapter into the device and connect it to the power source. -10-...
  • Page 11 Download the PETKIT App from the App Store or Google Play. Or scan the QR code to download and install. ❷ Open the PETKIT App, click “+” and select PETKIT PUROBOT MAX PRO WITH CAMERA SELF-CLEANING CAT LITTER BOX. 9:41...
  • Page 12 RETURN TO CONTENTS ❸ Start connection Press the menu button on the device to switch to “Connect to the network”, then press the OK button, and the screen will display “Connecting”. Please wait until the connection is successful. * Note: The interface may be di erent due to so ware version update;...
  • Page 13 RETURN TO CONTENTS ❹ Read instructions For the safety of your pets and proper product usage, please read the instructions carefully and adhere to the usage guide. * Note: The interface may be di erent due to so ware version update;...
  • Page 14 RETURN TO CONTENTS 4.2 Pour in Cat Litter Note: The size of cat litter should not exceed 12 mm(0.47 in) in length and 3 mm(0.12 in) in diameter. ❶ Press to switch to “Maintenance Mode”, then press to execute this function, and the cylinder begins to rotate.
  • Page 15 ❶ Open the waste bin door and pull the ❷ Pull out the waste bin and take out the drawstring to pack the trash bag. packed trash bag. ❸ Install a new trash bag. Note: Please use the PETKIT specialized trash bag. -15-...
  • Page 16 Quickly find and replay saved videos by the event category. *For features such as full video playback, please subscribe to the PETKIT Care+ cloud service. Please refer to PETKIT Care+ Service Agreement for details. ❹ Main Functions * Note: The interface may be di erent due to so ware version update;...
  • Page 17 RETURN TO CONTENTS 5.2 Status Indicator Swipe le on the homepage to enter the label page, which displays the status of the N50, N60, and the waste bin. ❶ When the N60 label turns red and displays “N60 has expired”, please replace it promptly.
  • Page 18 RETURN TO CONTENTS 5.3 Description of Functions ❶ Scoop ❷ Maintenance Mode Click it to clean out the clumps from the A er clicking it, the Cylinder begins to rotate. Cylinder. It will stop with the opening facing upward, making it convenient to pour in cat litter. ❸...
  • Page 19 RETURN TO CONTENTS ❹ Deodorize Click it to remove odors. Set the deodorization mode in the "Scooping Setup". There are three options: automatic deodorization, scheduled deodorization, and deep deodorization. * Note: The interface may be di erent due to so ware version update; the actual interface shall prevail.
  • Page 20 RETURN TO CONTENTS 5.4 Play Videos A er subscribing to the PETKIT Care+ service, you can view the highlights and full video playback. ❶ Highlight playback Click on the video in the timeline to view a sped-up 4-second preview version.
  • Page 21 RETURN TO CONTENTS ❷ Full clips playback Click Playback to view the complete video footage. ❸ Speedup playback ··· In the Playback page, click “ ” on the top right corner to choose the speed, or hold the center of the screen to play in 2x speed. * Note: The interface may be di erent due to so ware version update;...
  • Page 22 RETURN TO CONTENTS 5.5 Delete video clips You can delete recorded video clips as you need. Method 1: Swipe le in the timeline and Method 2: Click on the video you want to delete the video. ··· delete, switch to Playback, click “ ”...
  • Page 23 RETURN TO CONTENTS 5.6 Privacy Protection ❶ Activate or deactivate the camera You can turn on or turn o the camera as you need. Note: A er turning o the camera, it will no longer record any videos. ❷ Customize the camera working time period You can customize time slots to turn on the camera.
  • Page 24 RETURN TO CONTENTS ❸ Smart detection When Pet Visit Detection is turned o , the camera won't record videos of the pet outside the litter box, and events of the pet appearing outside the litter box won't be logged on the timeline. When Pet Toileting Video is turned o , the camera won't record toileting videos inside the litter box, but toileting logs will still be displayed on the timeline.
  • Page 25 RETURN TO CONTENTS 5.7 Other Settings ❶ Make fecal pictures clearer Go to Settings > Scooping Setup and turn on Light Assist. A er activating this function, the light will automatically turn on during every scooping and turn o when the scooping is complete.
  • Page 26 The details are subject to the page description. PETKIT Care+ service can be transferred to another PETKIT PUROBOT MAX PRO, which is only once per year. PETKIT Care+ service is a virtual commodity and is non-refundable once purchased.
  • Page 27 RETURN TO CONTENTS DESCRIPTION OF CONTROL PANEL ❶ Press on the control panel to switch functions, and press to execute the selected function. Press and hold Turn on / Turn o Press Switch functions The screen will display the selected function. Press Execute the selected function Double press...
  • Page 28 RETURN TO CONTENTS ❷ Description of displayed status Network connected Camera on Child lock on Toilet times today Total toilet ❸ Description of other prompts There will be scrolling text at the bottom of the screen to describe the current status. Prompts Description The cat enters while the device is in operation...
  • Page 29 RETURN TO CONTENTS CLEANING AND MAINTENANCE For the cat's health, it is recommended to regularly clean or replace these parts. Caution: Please disconnect the power or turn o the device. Cylinder Fisheye Camera Do not rinse or soak (Please replace it regularly) Litter Si er Smart Odor Eliminator Litter Pad...
  • Page 30 RETURN TO CONTENTS 7.1 Empty Cat Litter Before Cleaning Note: To avoid overflowing, please replace a new trash bag first. ❶ Align the magnetic cat litter remover with ❷ Click “Empty” in the App, and empty the litter si er. Once there is a "Click" sound, the remaining cat litter in the cylinder according the installation is successful.
  • Page 31 RETURN TO CONTENTS ❸ Remove the cylinder. ❹ Place the cylinder against the wall. ❺ Grasp one side of the litter si er. ❻ Press the litter si er until it is bent and separates from two buckles (points A and B as shown), and take out the litter si er.
  • Page 32 RETURN TO CONTENTS ❼ Pinch the handle of the litter pad to pull out the litter pad. 7.3 Clean Main Unit and Parts Caution: Do not rinse or soak the main unit; otherwise, the device will be damaged. Only wipe it. ❶...
  • Page 33 RETURN TO CONTENTS ❸ Wipe the main unit with a wet tissue. Wipe the fisheye camera, smart odor eliminator, and proximity sensor with a so cloth. Smart odor eliminator * Please regularly wipe the air inlet Fisheye camera with a so dry cloth to ensure it is unobstructed.
  • Page 34 RETURN TO CONTENTS ❷ Press gently and release the litter pad; its two sides will be automatically inserted into the groove. Note: Please ensure that the green edge of the litter pad is fully stuck into the groove, and that the arrows on both ends align with the indicated direction. ❸...
  • Page 35 RETURN TO CONTENTS ❺ Insert it into point B. ❻ Please check: If the litter si er can be shaken back and forth, the installation is successful. Point B ❼ Put the cylinder on the base and lock the ❽ Install the magnetic side cover. buckle, ensuring it is fastened.
  • Page 36 RETURN TO CONTENTS How to When to How to Parts When to Clean Caution Clean Replace Detach Clean it Clean it with Refer to 5.2 - ① Cylinder when the inner a brush. surface is dirty. Avoid direct Clean it in time Replace it Clean it with exposure to...
  • Page 37 8.2 Video of Cleaning and Maintenance Please copy the video URL and open it in your browser to watch the video. https://youtu.be/o9GJbg5aUU4 BASIC SPECIFICATIONS PETKIT PUROBOT MAX PRO WITH CAMERA SELF-CLEANING CAT LITTER BOX Product Name P9904 Product Model Materials...
  • Page 38 · Please read the user manual carefully before installing and using the product. Any installation or usage indicates that you have read and accepted the safety guide below. · PETKIT is not responsible for or legally liable for any accidents or injuries resulting from the improper use of the product.
  • Page 39 RETURN TO CONTENTS Disposal The European directive 2012 / 19 / CE on Waste Electrical and Electronic Equipment(WEEE), requires that old household electrical appliances must not be disposed in the normal unsorted municipal waste stream. Old appliances must be collected separately in order to optimize the recovery and recycling of the materials theycontain and reduce the impact on human health and the environment.
  • Page 40 RETURN TO CONTENTS PETKIT Network Technology(Shanghai)Co.,Ltd. www.petkit.com support@petkit.com...
