- Page 1 USER MANUAL PETKIT EVERSWEET MAX (CORDLESS) Please read the User Manual carefully before using the product and keep it properly. V1.0-2024.01...
-
Page 2: Table Of Contents
TABLE OF CONTENTS PRODUCT LIST PRODUCT DESCRIPTION PRODUCT INSTALLATION HOW TO USE FUNCTION DESCRIPTION CLEANING AND MAINTENANCE VIDEO GUIDE BASIC SPECIFICATIONS A MESSAGE TO OUR VALUED CUSTOMERS USER SAFETY GUIDE... -
Page 3: Product List
RETURN TO CONTENTS PRODUCT LIST * Please ensure that all accessories are present before installation and use. Wireless ① Main Unit Outlet Pipe Filter Water Pump 2 in 1 Power Cord User Manual Cleaning Brush Note: ① The water pump works continuously in normal mode. The service life of the water pump may vary depending on different usage and maintenance. -
Page 4: Product Description
RETURN TO CONTENTS PRODUCT DESCRIPTION 304 Stainless Steel Water Control Tray Module Filter Filter Holder Water Outlet Latch Outlet Pipe Wireless Water Pump Wireless Base Water Tank Caution: There are components inside the wireless base and control module. Do not rinse or soak them. - Page 5 RETURN TO CONTENTS Status Indicator Light Button Turn on/off: Long press it for 3 seconds until the light flashes in blue, green and red in sequence, indicating a successful setup. Power Cord Connector (Open the dust plug before Control Module using) Bottom of Control Module...
-
Page 6: Product Installation
RETURN TO CONTENTS PRODUCT INSTALLATION ① Take out the control module vertically ② Unlock the latch and take out the upwards. stainless steel water tray. ③ Take out the lid and filter holder. ④ Put the water pump into the groove in the water tank, and then insert the outlet pipe into the water outlet above the wireless water pump. - Page 7 RETURN TO CONTENTS ⑤ Put the lid, place filter holder as ⑥ Add water to the water tank up to the shown in the picture, and put the filter position of the MAX line. in its holder. (* Before using the filter, please read the instructions on the filter package carefully.) MAX line...
-
Page 8: How To Use
RETURN TO CONTENTS HOW TO USE 4.1 Usage Modes * This product offers two power supply options, and you can choose according to your needs. 4.1.1 Plug it in ① Remove the control module, open ② Vertically insert the control module the silicone plug, and insert the power back to its base and plug in. - Page 9 * Water dispense frequency can be set by clicking “Energy management” in the PETKIT App. Please note that high frequency of pumping water will shorten Low battery the battery life. To provide you with the best possible...
- Page 10 RETURN TO CONTENTS 4.2 Indicator Description ① ② Filter Indicator Water Shortage Indicator Plug in Fully charged: Solid blue or green Charging: Flashing blue or green * The light color depends on the water dispensing mode. Unplug The green light is on for 15 seconds and then goes off.
- Page 11 Google Play Download the PETKIT App in the App Store or Google Play ② Add the device Open the PETKIT App and click “+” in the top right corner to add “PETKIT EVERSWEET MAX (CORDLESS)”. 9:41 Hello, PETKIT Device 智能双子星喂食...
- Page 12 RETURN TO CONTENTS ③ Connection The App will start to connect to the device. Please wait until the connection is successful. * Note: To enhance user experience, product firmware will be upgraded periodically. Please update the firmware timely in the App. The actual App interface prevails. -12-...
-
Page 13: Function Description
RETURN TO CONTENTS FUNCTION DESCRIPTION 5.1 Power Supply Options This device has two power supply options. Plug it in: Continuous flow and intermittent flow are optional. Unplug (battery-powered): Switching water outlet modes is not available. ① Plug it in After connecting the device via Bluetooth, you can switch between the two modes according to your needs. - Page 14 RETURN TO CONTENTS ② Unplug (battery-powered) Once unplugged, the device will be powered by the built-in battery. The default setting is to dispense water for 25s and stop for one hour, and you can modify the frequency in energy management as needed. The battery life will be affected by the frequency of water dispensing.
- Page 15 RETURN TO CONTENTS 5.2 Homepage of Device On the homepage, you can view the number of times and average duration of drinking that day, as well as online status of device, filter life, energy management, etc. ① Data Synchronization Refresh it to obtain real-time data. Note: Please ensure that the App and the device are connected via Bluetooth, and stay close to the device during...
- Page 16 PETKIT smart feeder series. The master device that doesn’t support interconnection: PETKIT FRESH ELEMENT smart pet feeder (model is P512 ), PETKIT FRESH ELEMENT Mini smart pet feeder (model is P530). * Note: To enhance user experience, product firmware will be upgraded periodically. Please update the firmware timely in the App.
-
Page 17: Cleaning And Maintenance
RETURN TO CONTENTS CLEANING AND MAINTENANCE The cleaning frequency is based on pet's habits and water quality. To ensure healthy drinking water for pets, it is recommended to clean the water tank at least once a week and clean thoroughly once a month. (View 06 for the video about cleaning and maintenance) ①... -
Page 18: Video Guide
RETURN TO CONTENTS VIDEO GUIDE 7.1 Installation & Usage Video Please copy the video URL and open it in your browser to watch the video. https://youtu.be/hV9a_9ug4eE 7.2 Maintenance & Cleaning Video Please copy the video URL and open it in your browser to watch the video. https://youtu.be/lGwNxjT1qQg -18-... -
Page 19: Basic Specifications
RETURN TO CONTENTS BASIC SPECIFICATIONS Name PETKIT EVERSWEET MAX (CORDLESS) Model P4115 Material ABS, 304 Stainless Steel Dimensions 265*171*191mm (10.4*6.7*7.5in) Capacity 3L (101oz) Weight About 1.2kg (2.6lb) Rated Input 5V 1A Connection Bluetooth Scope of Application Cats and small-breed dogs... -
Page 20: A Message To Our Valued Customers
Once installed or used, it means that you have carefully read and accepted the following safety instructions. · PETKIT is not liable for any accidents or injuries resulting from improper use of the product. · PETKIT reserves the rights of interpretation and revision. - Page 21 RETURN TO CONTENTS This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and ；(2) this device must accept any interference received, including interference that may cause undesired operation. FCC warning: Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
