PETKIT EverSweet Max P4115 - Smart Water Fountain Manual

PRODUCT LIST

* Please ensure that all accessories are present before installation and use.

Note:
① The water pump works continuously in normal mode. The service life of the water pump may vary depending on different usage and maintenance. Replace the water pump with a new one if necessary.
* Note: In order to enhance the user experience, periodic product improvements may be implemented. The product images shown are for illustrative purposes only. The actual product may vary from the image displayed on the packaging. For any inconsistencies, please refer to the actual product.

PRODUCT DESCRIPTION

PRODUCT DESCRIPTION - Part 1
PRODUCT DESCRIPTION - Part 2

PRODUCT INSTALLATION

Take out the control module vertically upwards.
Unlock the latch and take out the stainless steel water tray.
Take out the lid and filter holder.
Put the water pump into the groove in the water tank, and then insert the outlet pipe into the water outlet above the wireless water pump.
Put the lid, place filter holder as shown in the picture, and put the filter in its holder.
(* Before using the filter, please read the instructions on the filter package carefully.)
Add water to the water tank up to the position of the MAX line.
Insert point A of the water tray under the outlet, and pull the latch outward to secure the other side of the water tray.
Insert the control module vertically into the base, and the installation is complete.

HOW TO USE

Usage Modes

* This product offers two power supply options, and you can choose according to your needs.

Plug it in

Remove the control module, open the silicone plug, and insert the power cord into the power input at the bottom of the control module.
Vertically insert the control module back to its base and plug in.
Press the button to switch water dispensing modes.

Unplug (powered by built-in battery)

Remove the control module, and plug the power cord into its connector to charge the control module.
The solid blue or green light indicates full charging. Unplug it, cover the silicone plug, and insert the control module into the base vertically.
Switching water dispensing mode is not available in battery mode. (To preserve the battery's service life, the water is pumped for 25 seconds per hour by default.)
* Water dispense frequency can be set by clicking "Energy management" in the PETKIT App. Please note that high frequency of pumping water will shorten the battery life. To provide you with the best possible user experience, unscheduled optimization will be performed on software and its functions. Please refer to the real features in the App.
The case that the status indicator light flashes in red shows low battery power. Please plug in to charge the control module.

Indicator Description

Flashing red means that the filter needs to be replaced. Please reset in the App after replacement, then the indicator will go off. (Water fountain in normal operation)
Flashing red means water shortage. The indicator will go off after refilling water. (Water fountain in normal operation)

* When the control module is removed, indicator lights of filter and water shortage are solid red. When the control module is reassembled, the two lights will go off.

Device Binding

Download and Install PETKIT App:
Download the PETKIT App in the App Store or Google Play
Add the device
Open the PETKIT App and click "+" in the top right corner to add "PETKIT EVERSWEET MAX (CORDLESS)".
Connection
The App will start to connect to the device. Please wait until the connection is successful.

FUNCTION DESCRIPTION

Power Supply Options

This device has two power supply options.
Plug it in: Continuous flow and intermittent flow are optional.
Unplug (battery-powered): Switching water outlet modes is not available.

Plug it in
After connecting the device via Bluetooth, you can switch between the two modes according to your needs. You can also pause water dispensing on the App.
Note: The device will automatically resume work after a 10-minute pause to ensure water is always available for your pets.
Standard Mode

The device dispenses water continuously. (This mode is only supported when plugging in)

Intermittent Mode

The device dispenses water intermittently. The water dispensing frequency can be modified through energy management. (This mode is only supported when plugging in)
Unplug (battery-powered)
Once unplugged, the device will be powered by the built-in battery. The default setting is to dispense water for 25s and stop for one hour, and you can modify the frequency in energy management as needed. The battery life will be affected by the frequency of water dispensing.

* Note: To enhance user experience, product firmware will be upgraded periodically. Please update the firmware timely in the App. The actual App interface prevails.

Homepage of Device

On the homepage, you can view the number of times and average duration of drinking that day, as well as online status of device, filter life, energy management, etc.
Homepage of Device
* Note: To enhance user experience, product firmware will be upgraded periodically. Please update the firmware timely in the App. The actual App interface prevails.

Interconnection

Through the interconnection, you can remotely control the device, receive water shortage notification, etc, so that you can know the working status of the device at any time.

How to interconnect
This device can be connected to a master device via Bluetooth. When connecting, make sure that the distance between the device and the master device is within 8 meters and no obstacles are blocking the signal. Additionally, the master device must be updated to the latest version. The master device that supports interconnection: PETKIT self-cleaning cat litter box series and PETKIT smart feeder series. The master device that doesn't support interconnection: PETKIT FRESH ELEMENT smart pet feeder (model is P512 ), PETKIT FRESH ELEMENT Mini smart pet feeder (model is P530).
How to interconnect
* Note: To enhance user experience, product firmware will be upgraded periodically. Please update the firmware timely in the App. The actual App interface prevails.

CLEANING AND MAINTENANCE

The cleaning frequency is based on pet's habits and water quality. To ensure healthy drinking water for pets, it is recommended to clean the water tank at least once a week and clean thoroughly once a month.

Remove the control module and the wireless base, and wipe them with a dry cloth or slightly damp cloth. Please do not immerse them in water.

There are components inside the wireless base and control module. Do not rinse or soak them.
Clean the lid, water tray, filter holder, water tank, outlet pipe, and wireless water pump.

VIDEO GUIDE

Installation & Usage Video

Please copy the video URL and open it in your browser to watch the video.
https://youtu.be/hV9a_9ug4eE

Maintenance & Cleaning Video

Please copy the video URL and open it in your browser to watch the video.
https://youtu.be/lGwNxjT1qQg

BASIC SPECIFICATIONS

Name	PETKIT EVERSWEET MAX (CORDLESS)
Model	P4115
Material	ABS, 304 Stainless Steel
Dimensions Capacity	265171191mm (10.46.77.5in) 3L (101oz)
Weight	About 1.2kg (2.6lb)
Rated Input	5V 1A
Connection	Bluetooth
Scope of Application	Cats and small-breed dogs

A MESSAGE TO OUR VALUED CUSTOMERS

It is important to read and follow the User Manual before using the product.
Once installed or used, it means that you have carefully read and accepted the following safety instructions.
PETKIT is not liable for any accidents or injuries resulting from improper use of the product.
PETKIT reserves the rights of interpretation and revision.

USER SAFETY GUIDE

* Failure to follow the safety guides outlined below can result in product malfunction or other unforeseen mishaps.

Please install and use the product as instructed in the User Manual.
Pets under three months of age are not recommended to use this product.
The product is for indoor use only. Avoid direct sunlight exposure and keep it away from open flames.
Use only the original adapter to avoid device damage or safety hazards.
Place the device on a level surface. Do not knock over the device, otherwise it will not work properly or spill water.
Do not rinse or soak the base and the control module.
Avoid damage to the pump during daily cleaning and maintenance. The case that you drop it accidentally may cause the internal ceramic shaft to break, resulting in product damage.
Please note that this product operates on safe low voltage, but pets chewing on the wires may still pose a risk of electrical leakage. We recommend taking measures to prevent this, such as securing and hiding the power cord when using the product. If you find your pets chewing the cord, please stop them promptly.
Please handle it with care, otherwise it may cause damage to the product.
If you are not using or moving the product for an extended period, it is recommended to unplug the power cord.
Children should use this product under the supervision and guidance of adults.
Repairs should only be performed by professionals to avoid safety hazards.
Before leaving for an extended period, ensure that there is sufficient water in the water tank.
If you encounter any issues with the product, please contact our customer service for assistance.
