DUAL FUEL RANGE
COS-DFRL486GK
SLIDE-IN RANGE
GAS CONVERSION
INSTRUCTIONS
IMPORTANT:
READ AND SAVE THESE INSTRUCTIONS.
FOR RESIDENTIAL USE ONLY.
INSTALLER:
PLEASE LEAVE THESE INSTRUCTIONS WITH THIS UNIT FOR
THE OWNER.
OWNER:
PLEASE RETAIN THESE INSTRUCTIONS FOR FUTURE
REFERENCE.
R R e e v v . . 2 2 5 5 .0 .01 1
Advertisement
Related Manuals for Cosmo COS-DFRL486GK
Summary of Contents for Cosmo COS-DFRL486GK
- Page 1 DUAL FUEL RANGE COS-DFRL486GK SLIDE-IN RANGE GAS CONVERSION INSTRUCTIONS IMPORTANT: READ AND SAVE THESE INSTRUCTIONS. FOR RESIDENTIAL USE ONLY. INSTALLER: PLEASE LEAVE THESE INSTRUCTIONS WITH THIS UNIT FOR THE OWNER. OWNER: PLEASE RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE. R R e e v v . . 2 2 5 5 .0 .01 1...
- Page 2 COSMO Appliances are designed according to the strictest safety and performance standard for the North American market. We follow the most advanced manufacturing philosophy.
- Page 3 TABLE OF CONTENTS RANGE SAFETY....................4 Anti-tip Device ......................7 INSTALLATION REQUIREMENTS ................ 8 Tools and Parts ......................8 GAS CONVERSION ....................9 Convert Gas Pressure Regulator ................10 Convert Surface Burners ..................13 Convert Griddle ......................16 Complete Gas Conversion ..................18 CONTACT US ......................
- Page 4 RANGE SAFETY READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE Your safety and the safety of others are very important. We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety messages. This is the safety alert symbol.
- Page 5 WARNING FIRE AND EXPLOSION HAZARD If the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal injury or death. • Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.
- Page 6 WARNING • Gas leaks cannot always be detected by smell. Gas suppliers recommend that you use a gas detector approved by UL or CSA. For more information, contact your gas supplier. • Do not install a ventilation system that blows air downward toward this cooking appliance.
- Page 7 ANTI-TIP DEVICE WARNING TIP OVER HAZARD • A child or adult can tip the range and be killed. • Install anti-tip bracket to floor or wall per installation instructions. • Slide range back so rear range foot is engaged in the slot of the floor- mounting anti-tip bracket or rear range pin is engaged under the wall- mounting anti-tip bracket.
- Page 8 INSTALLATION REQUIREMENTS TOOLS AND PARTS Gather the required tools and parts before starting installation. Read and follow the instructions provided with any tools listed here. TOOLS NEEDED • Phillips screwdriver • Gloves • Combination wrench • Safety glasses • Nut driver PARTS NEEDED To purchase these or any other accessories or replacement parts, please visit www.cosmoappliances.com or reference the contact information at the end...
- Page 9 GAS CONVERSION WARNING FIRE AND EXPLOSION HAZARD • Use a new CSA International approved gas supply line and install a shut-off valve for new installations. • Securely tighten all gas connections. • If connected to LP, have a qualified person make sure gas pressure does not exceed the maximum pressure listed in the "Gas Supply Requirement"...
- Page 10 This range is factory-set for use with Natural gas (NG). The Propane gas (LP) conversion kit is sold separately. To order LP or NG conversion kit, see "Parts Needed" in the "Tools and Parts" section. IMPORTANT: Gas conversions must be done by a qualified service technician in accordance with the manufacturer's instructions and all codes and requirements of the authority having jurisdiction.
- Page 11 5. Locate gas pressure regulator. IMPORTANT: Do not remove the gas pressure regulator. Regulator Gas pressure cover regulator 6. Unscrew the metal cover in the center of gas pressure regulator. IMPORTANT: Do not remove the spring from the gas pressure regulator. Metal cover...
- Page 12 7. Unscrew the regulator cap on the metal cover. Orient the regulator cap for the fuel type being used and screw it back into the metal cover. Metal cover Regulator cap Natural gas Propane gas (NG) (LP) position position 8. Screw the metal cover securely back into the gas pressure regulator. Do not overtighten.
- Page 13 Tool Needed • 9/32" (7 mm) nut driver IMPORTANT: Make sure to save the orifices that have just been replaced in the conversion. NG/LP Orifice Chart for Surface Burners COS-DFRL486GK NG Orifice LP Orifice Rating Burner Placement Size (mm) Size (mm)
- Page 14 Converting Surface Burners 1. If installed, remove the burner grates, burner caps, and burner bases. 2. Remove the existing orifices with a 9/32" (7 mm) nut driver. Orifice 3. Replace the orifices with the correct fuel type orifices. Gas orifices are stamped with a size number.
- Page 15 4. Replace the burner bases, burner caps, and burner grates. NOTE: • Align notches in burner caps with pins in burner base. • Make sure the hole in the burner base is positioned over the igniter. • Burner caps should be level when properly positioned. If bur ner caps are not properly positioned, surface burners will not light.
- Page 16 CONVERT GRIDDLE The griddle cannot be converted to Natural gas (NG) or Propane gas (LP) by adjusting or tightening the orifice. The orifice must be replaced. Tool Needed • Phillips screwdriver • 3/8" (9.5 mm) combination wrench IMPORTANT: Make sure to save the orifices that have just been replaced in the conversion.
- Page 17 2. Remove the screws along edges and across center of rear range panel, and slowly remove rear range panel. Rear range panel 3. Remove the screws of griddle orifice holder below the griddle. The orifice is located behind the orifice holder. Griddle Griddle orifice...
- Page 18 4. Using one wrench to hold griddle orifice holder and a 3/8" (9.5 mm) combination wrench for orifice, replace griddle orifice with the correct fuel type orifice. • Gas orifices are stamped with a size number. Refer to the orifice chart earlier for correct NG and LP gas orifice sizes.
- Page 19 CONTACT US CUSTOMER SUPPORT TO CHAT WITH US LIVE FOR ASSISTANCE, VISIT: WWW.COSMOAPPLIANCES.COM/CHAT SCAN TO CHAT...
- Page 20 IMPORTANT Do Not Return This Product To The Store If you have a problem with this product, please contact COSMO Customer Support at +1 (888) 784-3108 DATED PROOF OF PURCHASE, MODEL #, AND SERIAL # REQUIRED FOR WARRANTY SERVICE. IMPORTANT Ne pas Réexpédier ce Produit au Magasin...
- Page 21 MEMO...
- Page 22 MEMO...
- Page 23 MEMO...
- Page 24 APPLIANCES Cosmo is constantly making efforts to improve the quality and performance of our products, so we may make changes to our appliances without updating this manual. Electronic version of this manual is available at: www.cosmoappliances.com...
