VLF 828- B 3
ADVANCED FULL-MOTION
TV WALL MOUNT
INSTRUCTION MANUAL
MANUEL D'INSTRUCTIONS
Texte français page 18
NOUS POUVONS VOUS AIDER !
Want to watch a video that shows
how easy this DIY project will be?
Souhaitez-vous regarder une vidéo
démontrant la facilité de ce projet
de bricolage ?
Watch it now at:
Regardez-la maintenant sur :
SANUS.com/3218
WE'RE HERE TO HELP
Recommended placement
Get it right the first time!
HeightFinder
Réussissez du premier coup !
HeightFinder
où percer.
Check it out at:
Découvrez-le sur :
SANUS.com/2566
shows you where to drill.
™
vous indique l'endroit
™
Our US-based install experts are
standing by to help.
Nos experts en installation aux
États-Unis sont prêts à vous aider.
Call us at:
Appelez-nous au :
+1 (800) 359-5520
Or, chat at:
Ou, discutez en ligne sur :
SANUS.com/chatSP
Advertisement
Related Manuals for LEGRAND SANUS VLF828-B3
Summary of Contents for LEGRAND SANUS VLF828-B3
- Page 1 VLF 828- B 3 ADVANCED FULL-MOTION TV WALL MOUNT INSTRUCTION MANUAL MANUEL D’INSTRUCTIONS Texte français page 18 WE’RE HERE TO HELP NOUS POUVONS VOUS AIDER ! Recommended placement Want to watch a video that shows Get it right the first time! Our US-based install experts are how easy this DIY project will be? HeightFinder...
- Page 2 IMPORTANT SAFETY INSTRUCTIONS – PLEASE READ MANUAL PRIOR TO USE – SAVE THESE INSTRUCTIONS Please read through these instructions completely to be sure you’re comfortable with this easy install process. Check your TV owner’s manual to see if there are any special requirements for mounting your TV. If you do not understand these instructions or have doubts about the safety of the installation, assembly or use of this product, contact Customer Service: US: +1 (800) 359-5520.
- Page 3 Dimensions TV INTERFACE 7.87in 200mm 3.94in 100mm 20.79in 15.75 528mm 23.62in 17.96in 600mm 456.2 mm WALL PLATE TOP VIEW - EXTENDED SIDE VIEW - EXTENDED 34.8in 883mm 24.0in 711mm 610mm 13.8in 15.7in 11.5in 398mm 291mm 350mm 46deg 46deg 15° DOWN SIMULATED 75"...
- Page 4 Supplied Parts and Hardware WARNING: This product contains small items that could be a choking hazard if swallowed. Before starting assembly, verify all parts are included and undamaged. If any parts are missing or damaged, do not return the damaged item to your dealer; contact Customer Service. Never use damaged parts! NOTE: Not all hardware included will be used.
- Page 5 STEP 1 Attach TV Bracket to TV 1.1 TV Screw Diameter 1 .2 Determine TV Screw Length and Spacers TV Screw Only one screw size Flat Back TV Washer fits your TV. TV Bracket CAUTION [TV brackets lay flat on your TV] NO SPACER NEEDED MINIMUM...
- Page 6 Align with your TV's mounting hole pattern (VESA).
- Page 7 NO SPACER NEEDED SPACER(S) NEEDED 2.5 mm 5.0mm 7.5mm IMPORTANT: Handle is oriented to the BOTTOM of your TV. CAUTION: Avoid potential personal injuries and property damage! DO NOT use power tools for this step. Tighten the screws only enough to secure the TV brackets to the TV.
- Page 8 STEP 2A Attach Wall Plate Wood Stud Installation CAUTION: Avoid potential personal injury or property damage! ● Drywall covering the wall must not exceed 5/8 in. (16 mm) ● Minimum wood stud size: nominal 2 x 4 in. (51 x 102 mm) actual 1½ x 3½ in. (38 x 89 mm) ●...
- Page 9 STEP 2B Attach Wall Plate Solid Concrete or Concrete Block Installation CAUTION: Avoid potential personal injury or property damage! (Center) ● Mount wall plate directly onto concrete surface (no wall covering) ● Minimum solid concrete thickness: 8 in. (203 mm) ●...
- Page 10 STEP 3 Hang TV onto Wall Plate 3.1 Attach Arm Assembly to Wall Plate HEAVY! You may need assistance with this step. CAUTION: Avoid potential personal injury or property damage! For CONCRETE APPLICATIONS: The arm assembly MUST remain centered in wall plate NOTE: For WOOD STUD APPLICATIONS, the arm assembly...
- Page 11 CAUTION: Avoid potential personal injury or property damage! Locking screws must be tightened to secure the arm assembly 3.2 Attach TV to Arm Assembly HEAVY! You may need assistance with this step.
- Page 12 CAUTION: Avoid potential personal injury or property damage! Locking screw must be installed to secure the TV to the arm assembly Adjust handle enough to grab Loosen the screw Tighten the screw from the front of your TV. CAUTION: Do not lower handle beyond screw...
- Page 13 Manage Cables IMPORTANT: Fully extend arm assembly to ensure enough slack in cables. 1. Slide to remove the cable covers 2. Route your cables through the arm assembly 3. Reattach the cable covers over the cables.
- Page 14 TV Adjustments MOVING YOUR TV EXTEND / RETRACT TILT SWIVEL LEVEL ADJUSTMENT CAUTION: Screw MUST be loosened before turning screw CAUTION: Avoid potential personal injury or property damage! Always make sure your securement screw is tightened, so the TV is securely fastened to the arm assembly.
- Page 15 TILT ADJUSTMENT Your TV should adjust easily when moved, then stay in place. If your TV is too loose or too tight, adjust the side tension knob by hand or use hex for additional tightening. NOTE: Once your TV is in place, tighten the tension knob to prevent unwanted movement.
- Page 16 LATERAL SHIFT HEAVY! You may need assistance with this step. CAUTION: Avoid potential injuries or property damage! DO NOT adjust the arm position from center for CONCRETE APPLICATIONS. MUST remain centered in wall plate for all concrete applications! For WOOD STUD APPLICATIONS, 1.
- Page 17 EXTEND / RETRACT -- ONLY IF NECESSARY Your TV should adjust easily when moved, then stay in place. ONLY if needed, adjust the extension/retraction arm tension with screw using hex key CAUTION: Avoid potential personal injury or property damage! DO NOT remove bolts , only turn enough for slight adjustment.
- Page 18 CONSIGNES DE SÉCURITÉ IMPORTANTES Français – CONSERVEZ CES INSTRUCTIONS – VEUILLEZ LIRE ENTIÈREMENT LE MANUEL AVANT D’UTILISER CE PRODUIT Avant de commencer, assurons-nous que ce support vous convient parfaitement! Votre téléviseur Non — Parfait! pèse-t-il plus de 56,6 56,6 kg kg (125 lb) avec les Oui —...
- Page 19 1-3 Fixez le support de téléviseur Desserrez les quatre vis Alignez-le avec le modèle de trou de montage de votre téléviseur (VESA). IMPORTANT : La poignée est orientée vers le FOND de votre téléviseur. ATTENTION : Évitez les risques de blessures corporelles ou de dommages matériels ! N’utilisez PAS d’ o utils électriques pour cette étape. Serrez les vis juste assez pour fixer la patte de fixation au téléviseur.
- Page 20 Legrand AV Inc. and its affiliated corporations and subsidiaries (collectively, “Legrand”), intend to make this manual accurate and complete. However, Legrand makes no claim that the information contained herein covers all details, conditions, or variations. Nor does it provide for every possible contingency in connection with the installation or use of this product. The information contained in this document is subject to change without notice or obligation of any kind. Legrand makes no representation of warranty, expressed or implied, regarding the information contained herein.
