4. When prompted, specify the following addresses for the
appliance: IP address, IP subnet mask, IP gateway,
and DNS server.
5. When prompted, specify the console password and
CLI enable password.
6 — Configure Date/Time, Local
Users, and Management Network
To configure settings for the Date/Time, Local Users, and
Management Network:
1. Open a browser and enter the IP address and port num-
ber for the appliance. For example, an IP address of
192.168.2.42 with a port number of 8082 would be:
https://192.168.2.42:8082
2. When prompted, enter the default Username (admin)
and Password (admin). The WebUI window opens.
3. Configure the Date/Time:
Select Platform Management > Date/Time.

On the Date/Time panel, click the Edit (pencil icon) button.

In the Edit Date/Time dialog, enter the Date, Time,

and Timezone for the appliance.
NOTE: When the Timezone is set to NTP, the Date and
Time fields are unavailable. To use NTP, select the de-
fault primary and second servers, or define your own.
Click OK to save the date and time settings. When

prompted to confirm the changes, click Apply.
4. Add a Local User:
Select Platform Management > Authentication.

On the Authentication panel, click Local Users.

On the User Management panel, click Add (plus icon)

button to add a new user.
In the Add Users dialog, enter the User ID, Roles, and

Password for the new user.
Click OK to save the new user. When prompted to con-

firm the changes, click Apply.
5. Configure the Management Network:
Select Platform Management > Management Network.

On the Management Network panel, click the Edit

(pencil icon) button.
In the Edit Management Network dialog, enter the set-

tings for MTU, Hostname, and Nameservers (Primary,
Secondary, and Tertiary).
Click OK to save the network settings. When prompted

to confirm the changes, click Apply.
NOTE: For more information on configuring appliance set-
tings, refer to the SSL Visibility Admin Guide, available at
techdocs.broadcom.com.
7 — License the Appliance
SSL Visibility appliances must be licensed for full functional-
ity. To license the appliance, you need:
The appliance serial number

A user account for the Broadcom Support portal

To license the appliance:
1. Download the license:
Go to support.broadcom.com, click Login, and when

prompted, enter your Username and Password.
Click My Entitlements.

Search for the appliance you want to license by enter-

ing its Serial Number, Site ID, or Email.
When the appliance appears, click the Download icon

in the License column.
Save the license file on a system that you can access

from the SSL Visibility appliance.
2. Open a browser and enter the IP address and port num-
ber for the appliance. For example, an IP address of
192.168.2.42 with a port number of 8082 would be:
https://192.168.2.42:8082
3. When prompted, enter the default Username (admin)
and Password (admin). The WebUI window opens.
4. Select (Platform Management) > License.
5. On the License tab, click the Add (plus icon) button.
6. In the Install License dialog, use one of the following
options to install the license:
On the Upload License tab, click Browse to locate and

select the license file.
On the Paste License tab, paste in text that has been

copied from an exported license.
On the License from URL tab, enter the URL to down-

load the license file from a web server.
On the BTO Install tab, install the license file directly

from the portal.
7. Click Add. A confirmation message indicates that all
standard SSL Visibility features are now operational.
Reboot the appliance when prompted.
