3 — Connect Cables
If you would rather mount the appliance before performing
configuration tasks, skip to
and then return to this section. The following procedure doc-
uments a basic Fail to Appliance deployment with a ProxySG
(see Figure 1). For other deployments, refer to the SSL Visi-
bility Admin Guide, available at techdocs.broadcom.com.
NOTE: Network cables are not included with the appliance.
Make sure to use only straight-through Ethernet cables.
Category 6A cables are required for 10GBase-T operation.
To deploy the appliance and connect cables:
1. Connect an Ethernet cable to the rear-panel MGMT 0:0
port of the appliance, and connect the other end to a
management workstation, either directly or through a
management network switch.
2. For a Fail to Appliance deployment (see
nect Ethernet cables from the rear-panel network ports
of the appliance to the following devices:
Upstream switch

ProxySG (2:0 port)

ProxySG (2 1 port)

Client side switch

3. Connect the RJ45 end of the included null-modem serial
cable to the rear-panel RJ45 Serial port of the appli-
ance, and connect the other DB9 end to a serial terminal
or to a workstation with terminal emulation software.
4. Connect the included AC power cords to the rear-panel
Power inlets of the appliance and connect the other
ends to a 120V or 200V power source.
4 — Power On the Appliance and
Verify the LEDs
To power on the appliance and verify it is operational:
1. Confirm the appliance power cords are securely con-
nected to a power source.
2. If the appliance does not automatically power on, press
the rear-panel soft Power switch.
NOTE: The state of the Power switch (on/off) is retained
when power is removed. This may necessitate pressing
the switch when reapplying power to the appliance.
Section 8, Mount the Appliance,
Figure
3. As the appliance boots, verify the following:
The Power LED turns amber during the boot cycle.

Near the end of the boot cycle, the Power LED alter-

nates between green and amber, indicating an uncon-
figured state.
After the boot cycle has completed, the OLED panel dis-

plays the appliance model, serial number, and IP address.
The front-panel Power Status and System Status LEDs of
the appliance indicate the following states:
LED Color
Power Green solid
Status
Amber solid
Green/amber
blinking
None
1), con-
System Green solid
Status
Amber solid
Amber
blinking
None
5 — Perform the Initial
Configuration and Setup
To perform the initial configuration for the appliance:
1. Establish a serial connection to the appliance:
Verify the rear-panel RJ45 Serial port of the appliance

is connected to a serial terminal or to a workstation with
terminal emulation software.
Open a terminal emulation program, such as Microsoft

HyperTerminal®, PuTTY, Tera Term, or ProComm™
and configure it to use the following settings:
Baud rate:

Parity: none

Flow control: none

2. Power on the appliance (if it is not already powered on)
and, when prompted, press Enter three times.
3. Press 2 to launch the Configuration Wizard, and then
press Enter to access ICW commands.
Description
Powered on, booted, configured
In the process of booting.
Powered on but not yet initialized.
No power is present or the
appliance has been powered off.
Operating normally.
Warning fault encountered.
Critical fault encountered.
Operational state undetermined.
115200
Data bits: 8
bps

Stop bits: 1

SSL Visibility
Quick Start Guide
SV-S550
2
