PTZ
Network Camera
Quick Setup Guide
NO:170-18-20-0206-02
Issue:1.1
1 Packing List
1
Packing List
Accessories are different from countries and regions. Please refer
to the actual product.
or
or
*1
*1
*4
T10
*3
*1
*1
Power adapter *1
Power cable *1
Wall Mount *1
2
Device Port
NOTE
Different devices may have different multi-core cables; The figure is only for your reference, please refer to the actual application scene.
1
Power
2
3
Alarm in
Alarm out
4
POE port
NOTE
All external devices should be powered separately. There is no power voltage from the camera.
S5
AC 24~/DC36V+
Red
AC 24~/DC36V-
Black
GND EARTH
Yellow Green
Audio in
Audio out
Alarm button
Alert light
NVR /Switch
3
Device Dimension
NOTE
Different devices may have different dimensions; Please refer to the
actual product.
Unit: mm
Micrphone
Speaker
4 Reset and Install SD Card
4
Reset and Install SD Card
T10
