Bi-Spectral PTZ Network Camera
User Manual
Issue
V 1.1
Date
2019-09-04

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SN-TPT4231LZ/M and is the answer not in the manual?

Questions and answers

Related Manuals for Sunell SN-TPT4231LZ/M

Summary of Contents for Sunell SN-TPT4231LZ/M

  • Page 1 Bi-Spectral PTZ Network Camera User Manual Issue V 1.1 Date 2019-09-04...

  • Page 3: Precautions

    Bi-Spectral PTZ Network Camera User Manual Precautions Precautions Precautions Fully understand this document before using this device, and strictly observe rules in this document when using this device. If you install this device in public places, provide the tip "You have entered the area of electronic surveillance" in an eye- catching place.
  • Page 4 Bi-Spectral PTZ Network Camera Overview User Manual  Strictly conform to local electrical safety standards and use power adapters that are marked with the LPS standard when installing and using this device. Otherwise, this device may be damaged.  Use accessories delivered with this device. The voltage must meet input voltage requirements for this device.
  • Page 5 Bi-Spectral PTZ Network Camera User Manual Precautions  Do not jam the ventilation opening. Follow the installation instructions provided in this document when installing the device.  Keep the device away from heat sources such as radiators, electric heaters, or other heat equipment.

  • Page 7: Table Of Contents

    Bi-Spectral PTZ Network Camera User Manual Overview Contents Precautions ........................i 1 Overview ........................4 1.1 Principle of Thermal Imaging and Advantages .............. 4 1.2 Product Introduction ....................... 4 1.2.1 Function ......................5 1.2.2 Product Features ....................5 1.3 Description of PTZ cable ....................6 1.3.1 Multi-cable ......................
  • Page 8 Bi-Spectral PTZ Network Camera Overview User Manual 4.2 Visible-light Web ......................32 4.2.1 Login and Logout ..................... 32 4.2.2 Main Page Layout .................... 33 4.2.3 Change the Password ..................35 4.2.4 Browse Video ....................36 4.2.5 Set Local Network Parameters ................. 38 5 Thermal Parameter Configuration ..............
  • Page 9 Bi-Spectral PTZ Network Camera User Manual Overview 7.2.7 Configure North ....................72 7.2.8 Configure Timer ....................73 7.2.9 Configure Extension..................74 A Troubleshooting....................75 B Common Emission Rate ..................78 Issue V1.1 (2019-09-04)

  • Page 10: Overview

    Bi-Spectral PTZ Network Camera Overview User Manual Overview 1.1 Principle of Thermal Imaging and Advantages Any object with temperature higher than the absolute zero (-273.15°F) will emit infrared (IR) ray, even though it does not emit light. The IR ray is also called thermal radiation.

  • Page 11: Function

    Bi-Spectral PTZ Network Camera User Manual Overview automatic scanning, automatic cruise and other functions, suitable for large areas of monitoring, can be widely used in airports, stations, urban roads, traffic survey and monitoring, forest fire prevention, the high and heavy equipment rotary control and other important area.

  • Page 12: Description Of Ptz Cable

    Bi-Spectral PTZ Network Camera Overview User Manual 1.3 Description of PTZ cable 1.3.1 Multi-cable Aviation power supply and network cable of twenty-six cores is shown as Figure 1-1 &Figure 1-2, and the description is shown in Table 1-1. Figure 1-1 Aviation power supply and network cable of twenty-six cores Figure 1-2 Definition of twenty-six cores Issue V1.1 (2019-09-04)

  • Page 13: Aviation Alarm Cable

    Bi-Spectral PTZ Network Camera User Manual Overview Table 1-1 Description of twenty-six cores Name Description DC36V - Black (Thick) Red (Thick) DC36V + Black (Thick) DC36V - DC36V - Black (Thick) Alarm_OUT1 Red (Thin) DC36V + Red (Thick) DC36V + Red (Thick) Audio_IN(G) Audio masking...
  • Page 14 Bi-Spectral PTZ Network Camera Overview User Manual Figure 1-3 Aviation power supply cable of twenty-six cores Figure 1-4 Definition of twenty-six cores Table 1-2 Description of twelve cores Name Description Reserved core Blank Issue V1.1 (2019-09-04)
  • Page 15 Bi-Spectral PTZ Network Camera User Manual Overview Name Description Reserved core Blank Reserved core Blank Reserved core Blank Reserved core Ground Reserved core Blank Reserved core Blank Reserved core Ground Reserved core Ground Reserved core Blank Alarm_IN1 White Alarm_IN2 White and Orange Alarm_IN3 Blue Audio IN(G)

  • Page 16: Device Dimensions

    Bi-Spectral PTZ NetworkCamera Device Dimensions User Manual Device Dimensions Figure 2-1 shows the dimensions of the Bi-Spectral PTZ Network Camera. Figure 2-1 Dimensions (unit: mm) Issue V1.1 (2019-09-04)

  • Page 17: Device Installation

    Bi-Spectral PTZ Network Camera User Manual Device Installation Device Installation 3.1 Installation Method Bi-Spectral PTZ Network Camera can be installed on camera base. Figure 3-1 shows the base dimensions of PTZ camera. Figure 3-1 Base dimensions of PTZ camera (unit: mm) 3.2 Device Installation 3.2.1 Installation of Basic Requirements Installation site and environment to meet the technical parameters mentioned in the...

  • Page 18: Installation Space And Installation Strength

    Bi-Spectral PTZ NetworkCamera Device Installation User Manual Table 3-1 Installation tools Name Quantity Remarks 13mm wrench For mounting fixtures and mounting brackets 14mm sleeve Cross For common construction screwdriver(big) Used to disassemble the DIP cover to Cross adjust the device communication screwdriver(small) parameters Used for disassembly of pan / tilt pallet...
  • Page 19 Bi-Spectral PTZ Network Camera User Manual Device Installation COLOR Function define Remark Yellow RS422 TX- RS422 RX+ Blue RS422 RX- Yellow & Green In order to prevent lightning strikes, the grounding wire (yellow-green wire) in the cable outlet base must be grounded reliably and the grounding resistance should be <4Ω. ----End Issue V1.1 (2019-09-04)

  • Page 20: Quick Configuration

    Bi-Spectral PTZ Network Camera User Manual Quick Configuration Quick Configuration 4.1 Thermal Web 4.1.1 Login and Logout You must use Internet Explorer 8 or a later version to access the web management system; otherwise, some functions may be unavailable. Login system Step 1 Open the Internet Explorer, enter the IP address of IP camera (default value: 192.168.0.121) in the address box, and press Enter.

  • Page 21: Main

    Bi-Spectral PTZ Network Camera User Manual Quick Configuration Logout To logout of system, click in the upper right corner of the main page, the login page is display after you log out of the system. 4.1.2 Main Page Layout On the main page, you can view real-time video, set parameter, Video parameter, Video control, PTZ control, PTZ Configure and log out of the system.

  • Page 22: Change The Password

    Bi-Spectral PTZ Network Camera User Manual Quick Configuration Element Description the playback videos. Device You can choose a menu to set device parameters, configuration including the device information, audio and video streams, alarm setting, and privacy mask function. Change password You can click to change the password.

  • Page 23: Browse Video

    Bi-Spectral PTZ Network Camera User Manual Quick Configuration The Change Password dialog box is displayed, as shown in Figure 4-3. Figure 4-3 Modify Password dialog box The change password page will be displayed if you don’t change the default password when you login the system for the first time.
  • Page 24 Bi-Spectral PTZ Network Camera User Manual Quick Configuration Figure 4-4 Adding the a trusted site Step 2 In the Internet Explorer, choose Tool > Internet Options > Security > Customer level, and set Download unsigned ActiveX control and initialize and script ActiveX controls not marked as safe for scripting under ActiveX controls and plug-ins to Enable, as shown in Figure 4-5.

  • Page 25: Install Plugins

    Bi-Spectral PTZ Network Camera User Manual Quick Configuration The login page is display when the control is loaded. 4.1.5 Install Plugins You will be prompted with a message “Download and install the new plugin” as shown in Figure 4-6 when you login to the web management system for the first time. Figure 4-6 Download the plugin page Procedure Step 1...
  • Page 26 Bi-Spectral PTZ Network Camera User Manual Quick Configuration Figure 4-7 Local Network page Step 2 Set the parameters according to Table 4-2. Table 4-2 Local network parameters Parameter Description Setting IP Protocol IPv 4 is the IP protocol that uses [Setting method] an address length of 32 bits.
  • Page 27 Bi-Spectral PTZ Network Camera User Manual Quick Configuration Parameter Description Setting Subnet Mask Subnet mask of the network [Setting method] adapter. Enter a value manually. [Default value] 255.255.255.0 Default Gateway This parameter must be set if [Setting method] the client accesses the device Enter a value manually.

  • Page 28: Thermal Settings

    Bi-Spectral PTZ Network Camera User Manual Quick Configuration 4.1.7 Thermal Settings 4.1.7.1 Temperature Parameters Temperature parameters include: temperature unit, ambient type, ambient temperature, cavity temperature, correctional coefficient and area temperature display mode. Operation Procedure Step 1 Choose Configuration >Thermal >Temperature Parameters. The Temperature Parameters page is displayed, as shown in Figure 4-8.
  • Page 29 Bi-Spectral PTZ Network Camera User Manual Quick Configuration Parameter Description Setting Ambient The ambient temperature of [Setting method] Temperature camera. It is set when ambient Enter a value manually. is outside. Cavity The cavity temperature of Temperature camera. Correction Correction coefficient is refer to [Setting method] Coefficient the deviation of measured...
  • Page 30 Bi-Spectral PTZ Network Camera User Manual Quick Configuration Parameter Description Setting Measure Mode There are two types measure [Setting method] modes. Select a value from the drop-down list box. [Default value] General Display Alarm [Setting method] Area Enable or disable [Default value] Disable Area Alarm...

  • Page 31: Temperature Area

    Bi-Spectral PTZ Network Camera User Manual Quick Configuration Parameter Description Setting Greater Prominent Enable that, the image will [Setting method] show the setting color if the Enter a value manually. temperature is higher than set Choose one color to value. show.
  • Page 32 Bi-Spectral PTZ Network Camera User Manual Quick Configuration Figure 4-10 Temperature area and alarm configuration Step 2 Set the parameters according to Table 4-5 Table 4-5 Temperature area and alarm configuration Parameter Description Setting Channel [Setting method] Select a value from the drop-down list box.
  • Page 33 Bi-Spectral PTZ Network Camera User Manual Quick Configuration Parameter Description Setting Alarm Type Threshold alarm, Section Alarm [Setting method] and Temperature difference Select a value from the alarm are available for alarm drop-down list box. type. [Default value] Threshold alarm Warning Value Camera will warn when the [Setting method]...

  • Page 34: Shield Area

    Bi-Spectral PTZ Network Camera User Manual Quick Configuration Parameter Description Setting Alarm Open or close the alarm output [Setting method] and linkage of area. Tick the alarm areas area. Step 3 temperature 1. Tick an area ID. 2. Select type from drop-list. 3.

  • Page 35: Schedule Linkage

    Bi-Spectral PTZ Network Camera User Manual Quick Configuration Operation Procedure Step 1 Choose Configuration >Thermal > Shield Area. Figure 4-12 Shield Area Step 2 Enable the shield area. Step 3 Enable Show Shield Area, then the setting shield will show on live video. Step 4 Click left mouse button to set area, click right mouse button to end the setting.
  • Page 36 Bi-Spectral PTZ Network Camera User Manual Quick Configuration Figure 4-13 Schedule Linkage Step 2 Tick the output channel. Enable “Alarm Record”, “SMTP”,”FTP” button. Step 3 Step 4 Set schedule linkage. Method 1：Click left mouse button to select any time point within 0:00-24:00 from Monday to Sunday as shown in Figure 4-13.

  • Page 37: Bad Point Check

    Bi-Spectral PTZ Network Camera User Manual Quick Configuration 4.1.7.5 Bad Point Check Description The points that can’t move when the environment or scenario change is bad point. You can delete the bad point by bad point check function. Procedure Step 1 Choose Configuration >Thermal >...

  • Page 38: Visible-Light Web

    Bi-Spectral PTZ Network Camera User Manual Quick Configuration Figure 4-15 Recover bad point Step 3 Click Reset to return the previous settings. Step 4 Click Apply. The message "Apply success" is displayed, the system saves the settings. ----End 4.2 Visible-light Web 4.2.1 Login and Logout You must use Internet Explorer 8 or a later version to access the web management system;...

  • Page 39: Main

    Bi-Spectral PTZ Network Camera User Manual Quick Configuration Login system Step 1 Open Internet Explorer, enter the IP address of the IP camera (default value: 192.168.0.120) in the address box, and press Enter. The login page is displayed, as shown in Figure 4-16. Figure 4-16 Login page Step 2 Enter the user name, and password.
  • Page 40 Bi-Spectral PTZ Network Camera User Manual Quick Configuration Figure 4-17 Main page layout Table 4-6 Elements on the main page Element Description Real-time video area Real-time videos are played in this area. You can also set sensor parameters. Playback You can query the playback videos in this area. NOTE Only when the SD card or NAS have videos that you can query the playback videos.

  • Page 41: Change The Password

    Bi-Spectral PTZ Network Camera User Manual Quick Configuration Element Description Fault icon When the device encounters an exception, the fault icon is displayed. You can click to view the fault information. Change password You can click to change the password. Sign Out You can click to return to the login page.

  • Page 42: Browse Video

    Bi-Spectral PTZ Network Camera User Manual Quick Configuration Figure 4-18 Modify Password dialog box The change password page will be displayed if you don’t change the default password when you login the system for the first time. User need to wait at least three minutes after changing password, and then restart the device.
  • Page 43 Bi-Spectral PTZ Network Camera User Manual Quick Configuration In the displayed dialog box, click Add, as shown in Figure 4-19. Figure 4-19 Add a trusted site Step 2 In Internet Explorer, choose Tools > Internet Options > Security > Customer level, and set Download unsigned ActiveX controls and Initialize and script ActiveX controls not marked as safe for scripting under ActiveX controls and plug-ins to Enable, as shown in Figure 4-20.

  • Page 44: Set Local Network Parameters

    Bi-Spectral PTZ Network Camera User Manual Quick Configuration Step 3 Download and install the player control as prompted. If the repair tips displayed when installing the control, please ignore the prompt, and continue the installation, the login page is displayed when the control is loaded. Download the right control in the Internet Explorer Real-time video page pop-ups the message clicks to play live video with ActiveX control to reduce latency.
  • Page 45 Bi-Spectral PTZ Network Camera User Manual Quick Configuration  Procedure Step 1 Choose Configuration > Device > Local Network.. The Local Network page is displayed, as shown in Figure 4-21 Figure 4-21 Local Network page Step 2 Set the parameters according to Table 4-7. Table 4-7 Local network parameters Parameter Description...
  • Page 46 Bi-Spectral PTZ Network Camera User Manual Quick Configuration Parameter Description Setting Obtain IP address The device automatically obtains [Setting method] automatically the IP address from the DHCP Click the button on server. to enable DHCP. NOTE To query the current IP address of the device, you must query it on the...
  • Page 47 Bi-Spectral PTZ Network Camera User Manual Quick Configuration Parameter Description Setting MTU(800-1500) Set the maximum value of network [Setting method] transmission data packets. Enter a value manually. NOTE The MTU value is range from 800 to 1500, the default value is 1500, Please do not change it arbitrarily.

  • Page 48: Thermal Parameter Configuration

    Bi-Spectral PTZ Network Camera User Manual Thermal Parameter Configuration Thermal Parameter Configuration 5.1 Access the Sensor Setting Interface Operation procedure: Step 1 On the web interface or client interface, move the cursor to the real-time video page and right-click on the page. A shortcut menu is displayed, as shown in Figure 5-1,and Table 5-1 describes the sensor setting interface.

  • Page 49: Sensor Setting Parameter Description

    Bi-Spectral PTZ Network Camera User Manual Thermal Parameter Configuration Step 2 Choose Sensor Configure and the Sensor Setting dialog box appears. ----End 5.2 Sensor Setting Parameter description 5.2.1 Time Segment Operation procedure: Step 1 Click Time Segment tag on sensor setting interface, the time segment page is displayed, as shown in Figure 5-2.
  • Page 50 Bi-Spectral PTZ Network Camera User Manual Thermal Parameter Configuration Figure 5-3 Image setting interface Table 5-2 describes the image setting parameters. Table 5-2 Image setting parameter description Parameter Description Setting Brightness It indicates the total brightness of an image. As [Setting the value increases, the image becomes brighter.

  • Page 51: Scene

    Bi-Spectral PTZ Network Camera User Manual Thermal Parameter Configuration 5.2.3 Scene Figure 5-4 shows the scene interface. Figure 5-4 Scene interface Provide the selection of image pixel locations. Normal: the image is not flipped. Horizontal: the image is flipped left and right. Vertical: the image is flipped up and down.

  • Page 52: Ffc Control

    Bi-Spectral PTZ Network Camera User Manual Thermal Parameter Configuration Figure 5-5 set pseudocolor interface Polarity/LUT: the temperatures of the temperature fields detected by the thermal imaging camera are separately mapped to values ranging from 0 to 255 by the algorithm. In the black/white display mode, this range is converted to the grayscale tones.
  • Page 53 Bi-Spectral PTZ Network Camera User Manual Thermal Parameter Configuration Figure 5-6 FFC mode interface Table 5-3 describes the FFC mode parameters. Table 5-3 FFC control parameter description Parameter Description Setting The internal of the thermal imaging camera may comprise the mechanical action correction mechanism that can periodically improve the image quality.

  • Page 54: Noise Reduction

    Bi-Spectral PTZ Network Camera User Manual Thermal Parameter Configuration Parameter Description Setting change of the camera is based on the temperatures collected by the internal temperature probe. The temperature of the camera sharply changes when the camera is powered on. The FFC is relatively frequent, which is normal.

  • Page 55: Enhance Image

    Bi-Spectral PTZ Network Camera User Manual Thermal Parameter Configuration Figure 5-7 Noise reduction interface Table 5-4 describes noise reduction parameters. Table 5-4 DNR parameter description Parameter Description Setting [How to set] Select from the drop-down list box. Drag the slider to adjust max Decrease the image 2 DNR strength.
  • Page 56 Bi-Spectral PTZ Network Camera User Manual Thermal Parameter Configuration Figure 5-8 Enhance image interface Table 5-5 Screen adjustment parameter description Parameter Meaning Configurati on Method Compared with images generated based on visible light, IR images boast the features of high background and low contrast.
  • Page 57 Bi-Spectral PTZ Network Camera User Manual Thermal Parameter Configuration Parameter Meaning Configurati on Method It indicates the contrast between the bright part and the [Configurati dark part of an image. on method] Drag the As the value increases, the contrast increases. slide bar Contrast [Default...

  • Page 58: Visible-Light Parameter Configuration

    Bi-Spectral PTZ Network Camera User Manual Visible-light Parameter Configuration Visible-light Parameter Configuration 6.1 Access the Sensor Interface Operation procedure Step 1 On the web or NVMS interface, move the cursor to the real-time video page and right-click on the page. A shortcut menu is displayed, as shown in Figure 6-1. Figure 6-1 Sensor Setting interface Step 2 Choose Sensor Configure and the Sensor Setting dialog box appears.

  • Page 59: Image Adjust

    Bi-Spectral PTZ Network Camera User Manual Visible-light Parameter Configuration Figure 6-2 Time Segment page Step 2 Choose Debug Model in the lower left corner to activate the sensor setting page. Step 3 Set the time segment parameters. Step 4 Click save to save the setting. ----End 6.2.2 Image Adjust Figure 6-3 shows the Image Adjust tab page.

  • Page 60: Scene Mode

    Bi-Spectral PTZ Network Camera User Manual Visible-light Parameter Configuration Table 6-1 Parameters on the Image Adjust tab page Parameter Description Configuration Method Contrast It indicates the contrast between the bright part [Setting method] and the dark part of an image. Drag the slider.
  • Page 61 Bi-Spectral PTZ Network Camera User Manual Visible-light Parameter Configuration Figure 6-4 Scene mode interface Table 6-2 describes the FFC mode parameters. Table 6-2 FFC mode parameters description Parameter Description Configuration Method It indicates the working mode of a camera.. [Configuration method] Select from the drop- ...

  • Page 62: Exposure

    Bi-Spectral PTZ Network Camera User Manual Visible-light Parameter Configuration 6.2.4 Exposure Figure 6-5 shows the Exposure interface. Figure 6-5 Exposure interface for high speed dome Table 6-3 describes Exposure parameters. Table 6-3 Exposure parameters description Parameter Meaning Configuration Method The exposure modes include: [Setting method] ...

  • Page 63: Wb Setting

    Bi-Spectral PTZ Network Camera User Manual Visible-light Parameter Configuration Parameter Meaning Configuration Method The device automatically adjusts the shutter time [Setting method] based on the ambient brightness. The shutter time is less than or equal to the value of this parameter. Select a value from the drop- Shutter...

  • Page 64: Daynight

    Bi-Spectral PTZ Network Camera User Manual Visible-light Parameter Configuration Table 6-4 WB Setting parameters description Parameter Meaning Configuration Method Mode It is adjusted based on application scenarios [Setting method] to improve the fidelity of the image color. Select a value from The WB modes include: the drop-down list.
  • Page 65 Bi-Spectral PTZ Network Camera User Manual Visible-light Parameter Configuration Figure 6-7 DayNight Mode interface Table 6-5 describes DayNight Mode parameters. Issue V1.1 (2019-09-04)
  • Page 66 Bi-Spectral PTZ Network Camera User Manual Visible-light Parameter Configuration Table 6-5 DNR parameters description Parameter Meaning Configuration Method D/N Setting It can be set to Auto, Day, Night or [Setting method] Timing. Mode Select a value from the drop-down list. ...

  • Page 67: Noise Reduction

    Bi-Spectral PTZ Network Camera User Manual Visible-light Parameter Configuration Parameter Meaning Configuration Method It determines the night-to-day switching [Setting method] TRANSI.(N ->D)(dB) in auto mode. When the system gain is Drag the slider. smaller than the value of this parameter, [Default value] the system enters the day mode.

  • Page 68: Enhance Image

    Bi-Spectral PTZ Network Camera User Manual Visible-light Parameter Configuration Figure 6-8 Noise Reduction interface Table 6-6 describes DNR parameters. Table 6-6 DNR parameters description Parameter Meaning Configuration Method [Configuration method] Select from the drop- down list 3D NR Reduce noise of image. [Default value] Auto It is valid in auto noise filter mode.
  • Page 69 Bi-Spectral PTZ Network Camera User Manual Visible-light Parameter Configuration Figure 6-9 Enhance image interface Table 6-7 Enhance image parameters description Parameter Meaning Configuration Method [Setting method] It is used to display the foreground and Tick the WDR background at the same time in the mode and drag the environment with a large brightness slider.

  • Page 70: Zoom Focus

    Bi-Spectral PTZ Network Camera User Manual Visible-light Parameter Configuration Parameter Meaning Configuration Method It provides a clearer view of an image in the [Setting method] fogged environment when Defog is Tick the Defog enabled. mode and drag the As the value increases, the image becomes DeFog slider.
  • Page 71 Bi-Spectral PTZ Network Camera User Manual Visible-light Parameter Configuration Parameter Meaning Configuration Method It can be set to the auto, manual or semi-automatic mode. Auto focus mode: The system automatically triggers focus based on [Configuration application scenarios. method] Select from the Manual focus mode: You can trigger Focus Mode drop-down list...

  • Page 72: Ptz Function Application

    Bi-Spectral PTZ Network Camera User Manual PTZ Function Application PTZ Function Application 7.1 PTZ Control function Operation Description PTZ Control function is only available to a camera with an external PTZ and High Speed Dome with PTZ function. PTZ Control When browsing real-time videos shot by a dome camera or a camera connected to an external PTZ, you can control the PTZ to view Video shot in different directions.

  • Page 73: Ptz Configuration

    Bi-Spectral PTZ Network Camera User Manual PTZ Function Application Table 7-1 Descriptions of PTZ buttons Button Description Auto Zoom Click to adjust the surveillance range of the front-end lens. Auto Iris Click to adjust the size of the front-end iris. Auto Focus Click to adjust the focus of the front-end lens.

  • Page 74: Configure And Apply Preset

    Bi-Spectral PTZ Network Camera User Manual PTZ Function Application 7.2.2 Configure and Apply Preset You can configure preset positions and quickly rotate the camera to preset position by applying the preset. Operation procedure Step 1 Click Preset tab page in the PTZ configuration interface, the add preset page is displayed, as shown in Figure 7-3.

  • Page 75: Configure And Apply Scan

    Bi-Spectral PTZ Network Camera User Manual PTZ Function Application Figure 7-4 Add Track Step 2 Select a track ID (such as 1) from the track drop-down list box and enter the name of track. Step 3 Click , then use eight arrow keys in the PTZ control area to configure a track, then click to complete adding a track.

  • Page 76: Configure And Apply Tour

    Bi-Spectral PTZ Network Camera User Manual PTZ Function Application Figure 7-5 Add Scan Step 2 Select Scan ID (such as 1) from the track drop-down list box and enter the name of scan. Step 3 Click , then use eight arrow keys in the PTZ control area to configure two positions, then click to complete adding a scan.

  • Page 77: Configure And Apply Idle

    Bi-Spectral PTZ Network Camera User Manual PTZ Function Application Figure 7-6 Add Tour Step 2 Select Tour ID (such as 2) from the drop-down list box, enter the tour name. Step 3 Select first required position preset from the preset drop-down list box. Step 4 Input the values from Wait Time area box to set the time to stay in this position preset.(0 sec~ 255 sec).

  • Page 78: Configure North

    Bi-Spectral PTZ Network Camera User Manual PTZ Function Application Figure 7-7 Idle Step 2 Select a monitor type from the Type drop-down list box. Monitor type can choose preset, Scan, track, tour and Cir Scan. Step 3 Select a name form the Name drop-down list box. Step 4 Input a value from the Wait Time area box.

  • Page 79: Configure Timer

    Bi-Spectral PTZ Network Camera User Manual PTZ Function Application Step 2 Click to set the current position of true north. ----End 7.2.8 Configure Timer Operation procedure Step 1 Click Timer tab page in the PTZ configuration interface, the set timer page is displayed, as shown in Figure 7-9.

  • Page 80: Configure Extension

    Bi-Spectral PTZ Network Camera User Manual PTZ Function Application Step 6 Select the required monitor type at the PTZ type drop-down list box, you can select preset, Scan, Track, Tour in the box, and then select a specific from the Name drop- down list box.(for example preset, 1).

  • Page 81: A Troubleshooting

    Bi-Spectral PTZ Network Camera User Manual PTZ Function Application Troubleshooting Common Possible Cause Solution Trouble  Unable to Network is not Connect the network cable of the camera to access the connected. the PC to check whether the network cable is in good contact.
  • Page 82 Bi-Spectral PTZ Network Camera User Manual PTZ Function Application Common Possible Cause Solution Trouble An error The data in the Delete the cache of the Internet Explorer. The occurs in cache of browser is steps are as follows (taking IE9 as an example): not updated in time.
  • Page 83 Bi-Spectral PTZ Network Camera User Manual PTZ Function Application Common Possible Cause Solution Trouble normal, Access to computer Lower stream and resolution image performance is instability insufficient, take up CPU usage (Web video) Lack of network Replacement of industrial Gigabit switches bandwidth Access decoder Replacement of high-performance...

  • Page 84: B Common Emission Rate

    Bi-Spectral PTZ Network Camera User Manual PTZ Function Application Common Emission Rate Emission Rate The emission rate is the capability of an object to emit or absorb energy. An ideal transmitter provides an emission rate of emitting 100% of intake energy. An object with an emission rate of 0.8 can absorb 80% of intake energy, and reflect the remaining 20%.
  • Page 85 Bi-Spectral PTZ Network Camera User Manual PTZ Function Application Nickel wire 187/368 Lead (99.9% purity, No 127/260 0.06 oxidized) Copper 199/390 0.18 Cobalt 599/1110 0.19 199/390 Steel 599/1110 0.57 Tinned iron sheet (Light) 28/82 0.23 Brass(High-polish) 247/476 0.03 Brass (Tough rolled, polished 21/70 0.04 metal wire)
  • Page 86 Bi-Spectral PTZ Network Camera User Manual PTZ Function Application Frozen soil 0.93 Brick (Red, rough) 21/70 0.93 Brick (Unglazed, rough) 1000/1832 Carbon (T - carbon 0.9% ash) 127/260 0.81 Concrete 0.94 Glass (Glossy) 22/72 0.94 Granite (Surfaced) 21/70 0.85 0/32 0.97 Marble (I Polished, grey) 22/72...
