- Page 1 WLRD00THL User Manual Indoor temperature, relative humidity, and light intensity wireless recorder.
- Page 2 WLRD00THL User Manual General warnings. • The following information must be read and understood before proceeding with the installation, commissioning and maintenance of the devices described in this document. • ATTENTION! Any omission or failure to follow these instructions scrupulously can cause danger.
- Page 3 WLRD00THL User Manual 1. Description WLRD00THL is a datalogger designed to measure 3 input channels to acquire indoor temperature [ °C ], relative humidity [ %rel ], and light intensity [ ], with storage functionality of samples acquired. Equipped with a self-calibration photodiode that simulates the human eye answer, with an excellent...
- Page 4 WLRD00THL User Manual 4. Wireless device user interface. WineCapKey The user interface consists of a “virtual” button that can be activated using the and of a two-colours led. WineCapKey To give a command, user must approach the to the device’s sensible area and keep it in that position.; the following picture Picture 3 - WineCapKey positioning ) shows device’s sensible points.
- Page 5 WLRD00THL User Manual The following COMMAND table describes the available commands: WIRELESS MODE COMMAND table Flash count Command Description Shows the device STATUS. As answer the led perform a flash sequence as 1 flash refer to STATUS reported in the STATUS table. If the device is performing the TEST ( TEST command ) this command stops it.
- Page 6 WLRD00THL User Manual WineCapKey For each flash, a different command is associated; to confirm the command the must be removed from the sensible area immediately after the number of flashes corresponding at the desired command. The TEST corresponds to the second pulse and activate the "Field Measurer"...
- Page 7 WLRD00THL User Manual 8. Shutting off/Reactivating the device. (refer to Picture 4 - Command table) If the device is shut off and left unused for a long time, you can issue the STANDBY command . It corresponds to the command number 4 and must be issued twice to confirm the operation.
- Page 8 Picture 7 - Mechanical dimensions 11. Disclaimer. • Specifications are subject to change without notice and should not be interpreted as a commitment on the part of Capetti Elettronica S.r.l. • Capetti Elettronica S.r.l. assumes no responsibility for possibly errors that may appear in this document. In no case Capetti Elettronica S.r.l.
- Page 9 WLRD00THL User Manual 12. Reference standards. EN 61010 -1 For electromagnetic compatibility EN 61000 - 3 - 2 EN 61000 - 3 - 3 EN 300 220 -2 EN 301 489 - 03 EN 61000 - 6 -1 This symbol indicates that this product is compliant with the European Directive 2011/65/CE that restricts the use of substances in the manufacturing of electronic devices.
