Summary of Contents for Capetti Elettronica WSD12-VW

  • Page 1 WSD12-VW User Manual...

  • Page 2: General Warnings

    WSD12-VW User Manual General warnings. • The following information must be read and understood before proceeding with the installation, commissioning and maintenance of the devices described in this document. • ATTENTION! Any omission or failure to follow these instructions scrupulously can cause danger.
  • Page 3 WSD12-VW User Manual refer to Sampling operations start may be selected disconnecting the USB cable or giving the proper command with the magnetic key ( Stand-alone USB datalogger installation. ). More details on device 's connection/disconnection through the USB cable are available on the WineCap System - User Manual R30 manual.

  • Page 4: Device Enrolment

    WSD12-VW User Manual The following COMMAND table describes the available commands: WIRELESS DEVICES USER INTERFACE Flash count Command Description Shows the device STATUS. As answer the led perform a flash sequence as 1 flash refer to STATUS reported in the STATUS table. If the device is performing the TEST ( TEST command ) this command stops it.
  • Page 5 WSD12-VW User Manual WineCapKey For each flash, a different command is associated; to confirm the command the must be removed from the sensible area immediately after the number of flashes corresponding at the desired command. The TEST corresponds to the second pulse and activate the "Field Measurer"...

  • Page 6: Data Logger

    WSD12-VW User Manual STAND-ALONE DEVICE - STATUS TABLE Table FLASH COUNT –STAND ALONE MODE STATUS 1 green flash 2 seconds long ACTIVE 2 red flashes 2 seconds long STANDBY FACTORY RESET Sequence of red flashes: short, INVALID datalogger clock! 2 seconds long, short PC connection required.

  • Page 7: Technical Information

    WSD12-VW User Manual 9. Technical Information. Power supply 8.5Ah - 3.6V type “C” lithium internal battery ( BAT2 Up to 4years (samples every 60 minutes and radio signal quality at least Battery life (*) sufficient) • Frequency (4 input channels) Measures acquired •...
  • Page 8 Picture 7 - Mechanical dimensions 11. Disclaimer. • Specifications are subject to change without notice and should not be interpreted as a commitment on the part of Capetti Elettronica S.r.l. • Capetti Elettronica S.r.l. assumes no responsibility for possibly errors that may appear in this document. In no case Capetti Elettronica S.r.l.
  • Page 9 WSD12-VW User Manual 12. Reference standards. EN 61010 -1 For electromagnetic compatibility EN 61000 - 3 - 2 EN 61000 - 3 - 3 EN 300 220 -2 EN 301 489 - 03 EN 61000 - 6 -1 This symbol indicates that this product is compliant with the European Directive 2011/65/CE that restricts the use of substances in the manufacturing of electronic devices.
