Dynapac CS1400 VI Instruction Manual

Dynapac CS1400 VI Instruction Manual

Static three-drum roller
Hide thumbs

Advertisement

Quick Links

Download this manual
Instruction manual
Instruction manual
Operating & Maintenance
Operating & Maintenance
4812164401_A.pdf
4812164401_A.pdf
Static Three-drum Roller
Static Three-drum Roller
CS1400 VI
CS1400 VI
Deutz TD 3.6 L04 (Stage IIIA)
Deutz TD 3.6 L04 (Stage IIIA)
Deutz TD 3.6 L04 (Stage V)
Deutz TD 3.6 L04 (Stage V)
Serial number
Serial number
10000519xxA032198 -
10000519xxA032198 -
10000518xxA026818 -
10000518xxA026818 -
Translation of original instruction
Translation of original instruction
Reservation for changes
Reservation for changes
Printed in Sweden
Printed in Sweden
Engine
Engine

Advertisement

loading
Need help?

Need help?

Do you have a question about the CS1400 VI and is the answer not in the manual?

Questions and answers

Related Manuals for Dynapac CS1400 VI

Summary of Contents for Dynapac CS1400 VI

  • Page 1 Instruction manual Operating & Maintenance Operating & Maintenance 4812164401_A.pdf 4812164401_A.pdf Static Three-drum Roller Static Three-drum Roller CS1400 VI CS1400 VI Engine Engine Deutz TD 3.6 L04 (Stage IIIA) Deutz TD 3.6 L04 (Stage IIIA) Deutz TD 3.6 L04 (Stage V) Deutz TD 3.6 L04 (Stage V)
  • Page 3 Table of Contents Introduction ..........................3 The machine ....................3 Intended use ....................3 Training ....................... 3 Signal symbols and meaning ..............3 Safety information ..................3 General ....................... 4 (Only Stage V)..................... 5 CE marking and Declaration of conformity..........5 Safety - General instructions....................
  • Page 4 Vibrations - Operator station ..............17 Slopes ....................... 17 Dimensions, side view................18 Dimensions, top view ................19 Weights and volumes................20 Working capacity..................21 General ..................... 21 -emission (Stage V only) ..............22 Air Conditioning / Automatic Climate Control (ACC) (Optional) ....22 Tightening torque ..................
  • Page 5 Location - decals ..................30 Location - decals, CALIFORNIA ............... 31 Safety decals..................... 31 Info decals....................34 Instruments/Controls ....................36 Control panel and controls ................ 36 Forward & Reverse lever ................38 Function descriptions ................38 Display, key....................40 "MAIN MENU" ................... 42 "USER SETTINGS"...................
  • Page 6 Fuses in cab....................55 Operation ..........................57 Before starting ......................57 Battery isolation switch - Switching on ............57 Control panel, adjustments ............... 57 Operator's seat - Adjustment..............58 Operator's seat, comfort - Adjustments............. 58 Belt reminder..................... 59 Display - Control..................59 Parking brake ....................
  • Page 7 Miscellaneous ........................87 Lifting ........................87 Locking the articulation ................87 Lifting the roller..................88 Lifting the roller with jack:................89 Unlocking the articulation ................89 Load securing CS1400 VI ................. 90 Towing/Recovering....................93 Brake release pump..............94 2021-11-30 4812164401_A.pdf...
  • Page 8 Short distance towing with the diesel engine switched off/not running ..95 Towing....................... 95 Operating instructions - Summary ..................97 Preventive maintenance ......................99 Acceptance and delivery inspection............99 Warranty....................99 Maintenance - Lubricants and symbols ................101 Maintenance symbols ................102 Maintenance - Maintenance schedule .................
  • Page 9 Scrapers - Check/Cleaning ..............116 Draining the diesel engine's fuel prefilter ..........117 Maintenance - 50h ....................... 119 Air cleaner Checking - Change the main air filter............119 Backup filter - Change................120 Air cleaner - Cleaning....................121 Articulation steering and steering cylinder bushings - Lubrication ..121 Tightening the drum nuts - Check ............
  • Page 10 Seat bearing - Lubrication ............... 134 Diesel engine - Oil change ..............135 Edge cutter (Optional) - Lubrication .................... 136 Hydraulic reservoir cap - Check .............. 137 Replacing the fuel filter / fuel prefilter............138 Hydraulic fluid filter - Replacement ............139 Fuel tank - Draining off water ..............
  • Page 11 Air conditioning (Optional) - Overhaul ....................155 Drying filter - Check................. 156 2021-11-30 4812164401_A.pdf...
