Summary of Contents for Dynapac CS 141

  • Page 1 DYNAPAC CS 141 OPERATION O141EN4 Box 504, SE-371 23 Karlskrona, Sweden Phone: +46 455 30 60 00, Fax: +46 455 30 60 30 www.dynapac.com...
  • Page 2 ILF015WO1...
  • Page 3 PIN (S/N) *21720211* (New instrument panel) Dynapac CS 141 is a static 10–13 tonne articulated 3-drum roller. The drums have the same dia- meter and the line load is equal over the entire width. Propulsion and brakes on all three drums.
  • Page 4: Table Of Contents

    This manual contains instructions for operation and use of the roller. For care and maintenance information, see the Proposition 65 Warning MAINTENANCE, CS 141 manual. WARNING Diesel engine exhaust and some of its Remember that when you start and drive a...
  • Page 5: Safety Instructions (Also Read The Safety Manual)

    17. Make no changes or modifications on the roller that could affect safety. Changes may only be made following written consent by Dynapac. 18. Do not use the roller until the hydraulic fluid has reached its normal working temperature.
  • Page 6: Safety When Driving

    Remember that the machine’s center of gravity is displaced outwards when stee- ring to one side. For example, it moves to the right when steering to the left. At least Fig. 1 Position of drum when driving near an edge CS 141 O141EN4...
  • Page 7 ON, driving speed and raising the center of gravity (for example, with accessories) may cause the machine to topple even on a smaller slope than that Max. 30° stated here. or 58% Fig. 2 Tipping angle on side slopes CS 141 O141EN4...
  • Page 8: Safety Decals, Location And Description

    SAFETY DECALS, LOCATION AND DESCRIPTION CS 141 O141EN4...
  • Page 9 Do not touch. tion manual. 908229 The articulation joint must be locked while lifting. Read the instruction manual. Alt. 1 Alt. 2 272372 904601 903425 904835 382751 Hydraulic Biological Handbook Battery Securing fluid hydraulic compartment disconnecter point fluid CS 141 O141EN4...
  • Page 10: Machine And Engine Plates

    Int. Exh. Fuel rate at rated HP 1. Engine plate Date of MFG. Firing Order Made in Great Britain. 2. EPA sign (USA) 3284907 Rated HP/KW CS 141 O141EN4...
  • Page 11: Instruments And Controls

    27. Warning lamp for hydraulic filter 12. Reserve/parking brake knob 13. Direction indicators 28. Warning lamp for oil pressure 29. Warning lamp for brake 14. Light switch for working lights 15. Light switch for parking/dipped lights 30. Handbook compartment = Optional equipment CS 141 O141EN4...
  • Page 12: Instruments And Controls, Functional Description

    Light switch for working lights Turn right to switch on the forward working lights. Light switch for Turn right to switch on the parking lights and parking/dipped lights further right to switch on the dipped headlights. CS 141 O141EN4...
  • Page 13 Stop the engine immediately and locate the fault. Brake warning lamp The lamp lights when the parking or reserve brake knob is pushed in and the brakes are applied. Handbook compartment Storage space for the roller’s operator and safety manuals. CS 141 O141EN4...
  • Page 14: Instruments And Controls, Cab (Optional)

    INSTRUMENTS AND CONTROLS, CAB (OPTIONAL) Fig. 7a Cab roof, left side Fig. 7b Cab roof, right side Fig. 7d Seat, left side Fig. 7c Cab roof, back CS 141 O141EN4...
  • Page 15: Instruments And Controls In Cab, Functional Description

    Left position = maximum heating. Right position = heating is OFF. Air fan switch Push to activate. Two positions for different amounts of air. Washer fluid container Fill with pure water and a small amount of environmentally safe washer fluid. CS 141 O141EN4...
  • Page 16: Before Starting

    The hourmeter (25) records the number of hours so long as the engine is running. Fig. 10 Starting controls 12. Reserve/parking brake knob 17. Start/stop knob 21. Warning lamp for charging 25. Hourmeter 28. Warning lamp for oil pressure 29. Warning lamp for brake CS 141 O141EN4...
  • Page 17 3. Rubber element 4. Anti-slip View Before starting, make sure that the field of view is unobstructed, both in front and behind. All cab windows must be clean and rear view mirrors properly adjusted. Fig. 13 View CS 141 O141EN4...
  • Page 18: Starting

    28. Warning lamp for oil pressure until the machine reaches normal working 29. Warning lamp for brake temperature. WARNING Make sure that ventilation (extraction) is adequate if the engine is run indoors. Risk of carbon monoxide poisoning. CS 141 O141EN4...
  • Page 19: Operation

    Also see Maintenance manual for filling/pumps/filter etc., and the following page regarding different settings for the sprinklerpumps. Fig. 18 Sprinkler control Make sure the scrapers are correctly adjusted on the 18. Sprinkler switch drums. 19. Sprinkler timer CS 141 O141EN4...
  • Page 20: Driving

    Fig. 19d Sprinkler system Allow water from the upper tank to fill the lower Allow water from the upper tank to fill the lower one, then close the tap before the filter. one, then close the tap before the filter. CS 141 O141EN4...
  • Page 21: Braking

    Turn the starter switch (17) to mode O. Lower the instrument cover (on rollers without cab) and lock it. 21-29 Fig. 22 Control panel 17. Starter switch 21-29. Panel for warning lamps CS 141 O141EN4...
  • Page 22: Parking

    This will prevent battery discharge and will also make it difficult for any unauthorized person to start and drive the machine. Also lock the doors to the engine compartment. Fig. 24 Engine compartment 1. Battery disconnector CS 141 O141EN4...
  • Page 23: Lifting

    (4) with the locking stud (2). The locking lug is located on the front frame of the machine. 3 2 4 Fig. 27 Articulation in open mode 2. Locking pin 3. Locking arm 4. Locking lug, rear CS 141 O141EN4...
  • Page 24: Towing

    CAUTION Remember to restore the articulation interlock to its open mode before starting the roller again. WARNING The roller must be unoccupied during Fig. 30 Transportation transportation. 1. Chock 2. Lashing wire CS 141 O141EN4...
  • Page 25: Operating Instructions - Summary

    Push in the reserve/parking brake knob. Stop the engine and chock the drums. 13. Lifting: - See the operation manual. 14. Towing: - See the operation manual. 15. Transport: - See the operation manual. 16. Retrieval: - See the operation manual. CS 141 O141EN4...
