Alarms
Stop
Message
Priority
Infusion
The administration set is not
Install set
High
Yes
loaded or the door is open.
The administration set is
Check set installation
High
Yes
incorrectly positioned.
Door opened
High
Yes
The door is open.
The administration set is
Set / air installation
High
Yes
incorrectly positioned in front of
the air sensor.
An air bubble has been detected:
Air bubble
High
Yes
At start-up, during the infusion, or
while the infusion is stopped.
An air bubble has been detected
Air alarm
High
Yes
during infusion.
The OCS control system has
OCS failure
High
No
detected a failure.
Open and close door
Open and close the door to
Signal
No
for OCS test
perform the OCS test.
End of infusion
High
Yes
The VTBI is completed.
(KVO not activated)
One of the near end of infusion
Near end of infusion Medium
No
alert criteria is reached.
The flow rate (or dose) has not
Check settings
Medium
No
been confirmed.
Waiting settings
Medium
No
A value must be entered.
The infusion settings have not
Waiting start
Medium
No
been confirmed with start.
End of infusion / Stop
The VTBI is completed and the
Low
No
for new infusion
KVO is activated.
The upper or lower hard limit is
Reached hard limit
Signal
No
reached and cannot be exceeded.
Downstream
The pressure has reached the
High
Yes
occlusion
threshold level.
The pressure in the upstream line
Upstream occlusion
High
Yes
is too low.
Wait during pressure
A downstream occlusion has been
measurement
High
Yes
detected by the device.
checking !!!
In-line pressure has reached 50
Occlusion pre alarm
Medium
No
mmHg below the programmed
threshold.
Pressure increase
Low
No
The pressure is increasing.
Drop in pressure
Low
No
The pressure is decreasing.
Very low battery
Connect to power
High
Yes
The battery is discharged.
and wait
Very low battery
Very low battery. Battery should be
Too low to use
High
Yes
charged before starting infusion.
Wait for charge
Low battery
Connect to power
Medium
No
Low battery.
and wait
Connect the pump to a power
Low
No
supply.
AC power failure
Low
No
The power supply is inconsistent.
Power disconnection
Signal
No
Power supply disconnection.
Keypad lock status
Signal
No
The keypad is locked.
Keypad locked /
The keypad is locked and the door
Unlock keypad to
Signal
No
was opened and closed.
continue
Technical alarm. Disconnect the
Erxx(yyyy)
High
Yes
pump from the power supply.
High internal
Low
No
Temperature increase.
temperature
The pump is mounted on a Link+
Alarm reporting not
Low
No
Agilia rack that has not been
available on the Link+
upgraded.
This document may contain inaccuracies or typographical errors. Modifications
may thus be made, and included in later editions. Due to the evolution of standards,
and of legal texts and materials, the characteristics indicated in the text and images
of this document are applicable only to the device with which it is included.
KEYPAD DESCRIPTION
Problem
On / Off
Increment
(fast/low)
Decrement
(fast/low)
Confirm Value
/ Move to
Next Field
Stop / Pause
Bolus / Prime
/ Advance air
bubble
Cancel Value
/ Move Back
to Previous
Field
Alarm Silence
LIGHT INDICATORS
Power Supply
Indicator
Battery
Charge Status
Indicator
Infusion in Progress:
flashing green
Low-Priority Alarm:
constant yellow /
Medium-Priority Alarm:
flashing yellow
High-Priority Alarm:
flashing red
Fresenius Kabi AG
Else-Kröner-Str. 1
61352 Bad Homburg
GERMANY
Tel.: +49 (0) 6172 / 686-0
www.fresenius-kabi.com
Revision date: March 2021
Agilia VP
Quick Reference Guide
Note: This Quick Reference Guide is not intended to be comprehensive
instructions for the set-up and operation of the Agilia VP Volumetric
Infusion Pumps.
We recommend reading the Instructions For Use before using this device.
Description
Indicators
Battery charge status
Power supply
Volume Infused
Low-Priority Alarm
High-Priority Alarm
Infusion in Progress
Installation
Secure the pump stability
(e.g IV pole fixing)
Plug power cord
The Power Supply Indicator lights up
Installing the administration set
Lift door lever to open the pump door and install the set.
IMPORTANT: Ensure that the patient is not connected.
NOTE: The pump automatically powers on when the door is opened.
If not, press the <ON> key.
Insert the Green Connector
Insert the Blue SafeClip
Check that the tube is inserted into the left tube guide
CC12040-1
Infusion parameters adjusted
Remaining infusion time
VP
20 to 80 cm
Silence Alarm
Infusion in
Progress
