PETROL LAWN MOWER
HYM40SPE
Instruction Manual
WARNING: Read the instructions carefully before use.

Advertisement

loading
Need help?

Need help?

Do you have a question about the HYM40SPE and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Hyundai HYM40SPE

Summary of Contents for Hyundai HYM40SPE

  • Page 1 PETROL LAWN MOWER HYM40SPE Instruction Manual WARNING: Read the instructions carefully before use.
  • Page 2 USING THE MACHINE. Keep for future reference and pass it on if the machine is loaned or sold to another user. This manual has been produced by Hyundai Power Products and should be kept with the product. Please read and understand these instructions before you use your product. Failure to do this may result in personal injury or damage to the product.
  • Page 3 Contents Safety Information.....4-19 Maintenance......38-47 Maintenance Safety........38 Understand Your Machine.......4 Checking Your Machine.........38 Personal Safety..........5 Cleaning............39 Inspect Your Machine........6 Transportation..........39 Work Area............7 Storage............40-41 During Use............8-9 Blade Maintenance........42 Engine Safety..........10 Air Filter............43 Carbon Monoxide...........11 Spark Plug.............44 Fuel Safety..........12-13 Changing / Draining Oil........45 Batteries............14 Fuel And Carburetor........45 Electrical Safety..........15...
  • Page 4 Safety Information Safety No list of safety guidelines can be complete. Every environment is different. Always consider safety first, as it applies to your individual working conditions. Use this and other machinery with caution and respect. Failure to do so could result in serious injury, damage to equipment, or poor work results.
  • Page 5 Safety Information Personal Safety • WARNING! Never allow children or people unfamiliar with these instructions to use the product. Local regulations can restrict the minimum age of the operator. • Keep children, pets, and other people not using the unit away from the work area (at least 15m).
  • Page 6 Safety Information Inspect Your Machine • Check your machine before starting it. Keep guards in place and in working order. Make sure all nuts, bolts, etc., are securely tightened. • You must check the general condition of the machine before use. •...
  • Page 7 Safety Information Work Area • Make sure you thoroughly inspect the entire work area and remove all objects and anything that could be thrown by the machine or could damage the engine or machine (branches, stones, wire, toys, etc). Attempting to clear the work area whilst using the machine will reduce your concentration and creates a trip hazard.
  • Page 8 Safety Information During Use • Always hold the unit with both hands when operating. Keep a firm grip on the handlebars. Be aware that the machine may unexpectedly bounce upward or jump forward if the machine should strike buried obstacles such as large rocks or roots. •...
  • Page 9 Safety Information During Use (Continued) • You must disengage the blade, switch off the engine and unplug the spark plug cable (making sure that all moving parts are stationary): - Before refuelling. - Before adjusting the cutting height. - After striking a foreign object, you must inspect the machine for damage and make repairs before using it again.
  • Page 10 Safety Information Engine Safety • This machine is equipped with an internal combustion engine. Do not use on, or near, forest-covered or brush-covered land unless the exhaust system is equipped with a spark arrester meeting applicable local, state, or federal laws. •...
  • Page 11 Safety Information Carbon Monoxide DANGER! Engine exhaust fumes contain Carbon Monoxide. This is a poisonous gas and can kill in minutes. NEVER use inside a building or in an area with poor ventilation. NEVER use inside a confined space, such as but not limited to a house, garage, vehicle, boat or tent. ONLY use outside and far away from windows, doors and vents.
  • Page 12 Safety Information Fuel Safety CAUTION! ALL FUELS ARE HIGHLY FLAMMABLE AND PETROL VAPOUR IS EXPLOSIVE. TAKE EXTREME CARE WHEN HANDLING FUEL. KEEP FUEL OUT OF REACH OF CHILDREN. General Safety General Safety • Do not smoke each time fuel is handled. •...
  • Page 13 Safety Information Fueling / De-Fueling • ALWAYS fuel and de-fuel in a well ventilated area outside of buildings. Use a funnel to add fuel, only outdoors. Do not smoke during this and each time fuel is handled. • Add fuel before igniting the engine, never remove the fuel tank cap or add fuel whilst the engine is running or when it is hot.
  • Page 14 Safety Information Batteries (Where Present) Batteries present a risk if they become damaged by the possible leaking of electrolyte. This electrolyte is an acid and can cause serious burn injuries. Care should be taken when working on or near them. NOTE the electrolyte may be in a liquid or gel form. Should you come in to contact with electrolyte you should;...
  • Page 15 Safety Information Electrical Safety (Where Applicable) DANGER! ELECTRICITY CAN KILL - NEVER WORK ON LIVE/ENERGISED EQUIPMENT. • Prior to carrying out any maintenance work you MUST identify electrical isolation methods and isolate all electrical supplies. • Prior to use and with all electrical supplies isolated, you MUST check all electrical cables, plugs and connectors for the following;...
  • Page 16 Safety Information Vibrations (Where Applicable) • Prolonged use of hand held (operated) machines will cause the user to feel the effects of/from vibrations. These vibrations can lead to white finger (Raynaud’s phenomenon) or carpal tunnel syndrome. This condition reduces the ability of the hand to feel and regulate temperature, causing numbness and heat sensations and may cause nerve damage and circulatory tissue death.
  • Page 17 Safety Information Personal Protective Equipment Appropriate Personal Protective Equipment (PPE), MUST be worn at all times when operating or repairing the machine. No protective equipment can ensure 100% protection. When selecting PPE, make sure it’s CE marked and it suits the user in terms of size, fit, etc. If more than one item of PPE is worn at the same time, make sure they can be used together, e.g.
  • Page 18 The HYM430SPE is a petrol powered rear wheel drive, self-propelled, electric push button start lawnmower from HYUNDAI, ideally suited for small to medium sized lawns. The HYM430SPE has a cutting width of 420mm and is powered by a 139cc 4-stroke OHV petrol engine.
  • Page 19 Safety Information Symbols On The Machine We have provided safety messages in this manual and on the machine. This information alerts you to potential hazards that could hurt you or others. Please read these messages carefully. However, we may not have listed all of the possible hazards, you must also use your own judgment.
  • Page 20 Features HYM430SPE Features www.hyundaipowerproducts.co.uk 01646 687 880 aftersales@hyundaipowerproducts.co.uk...
  • Page 21 Features HYM430SPE Features Upper Handle Hold onto with both hands this whilst using the machine. Operator Presence Control (OPC) Lever This is a safety feature. The machine will stop if you let go of this lever. Self Propelled Lever Propels the machine forward. All you have to do is control the path the machine takes. Primer Bulb Air Filter Prevents dust, dirt and other contaminants from getting into the engine.
  • Page 22 Lay the contents out and check them. If any part is damaged or missing, you must not use the machine. Contact HYUNDAI Power Products immediately. You must keep the packaging material in case the machine needs to be returned or repaired.
  • Page 23 Assembly Assembly Safety CAUTION - This guide is meant to serve as a quick reference for operating your HYUNDAI machine. We always advise reading the manual in full before operation. CAUTION - For OUTDOOR use ONLY. Petrol machines produce carbon monoxide –...
  • Page 24 Assembly Unboxing & Assembly Video: Go to youtube.com and type in Hyundai HYM430SPE assembly. YOU MUST read and understand the instruction manual first. Step 1 : Assemble Handle Bars You will need a 13mm spanner or an adjustable spanner for assembly.
  • Page 25 Assembly Attach the upper handle to the lower handle and tighten the quick release handle bolts securely. See image 5 & 6. Slowly pull the recoil start handle up to the cord loop on the handlebar. See image 7 & 8. Image 5 Image 6 Image 7...
  • Page 26 Assembly Step 2 : Cable Attachment NOTE - If stood behind the lawnmower: OPC Cable : Attaches to the lever in front of the main handlebar if traced, will attach to the engine. Drive Cable : Attaches to the lever behind the main handlebar and if traced, will enter the deck of the lawnmower behind the engine.
  • Page 27 Assembly Step 3 : Grass Collector Assembly Slot the metal pole into the plastic parts around the grass collector. Step 4 : Cable Clips Use the plastic cable clips to attach the cables to the handlebars. www.hyundaipowerproducts.co.uk 01646 687 880 aftersales@hyundaipowerproducts.co.uk...
  • Page 28 Preparation Adding Oil Oil Type : SAE 30 or 15w40 Engine Oil Oil Capacity : 600ml NOTE - The machine is delivered without oil in the engine. All machines are tested and inspected so there may be some residual oil left in the machine so please fill with caution. Remove the oil filler cap.
  • Page 29 Preparation Adding Fuel Make sure you read the fuel safety before handling fuel. Fuel Type : Fresh Straight Unleaded Petrol Fuel Capacity : 1L NOTE - The machine is delivered without petrol. All machines are tested and inspected so there may be some residual petrol left in the machine so please fill with caution.
  • Page 30 Operation Grass Collection Lift the rear discharge flap. Remove the mulching plug if installed. Lift the back end of the grass collector up high to get the front hooks over the bars. Lower the rear discharge flap so it rests on the grass collector. These are the 2 hooks that will secure the grass collector into place.
  • Page 31 Operation Mulching Lift the rear discharge flap and remove the grass collector. Install the mulching plug. Lower the rear discharge flap. What Is Mulching? Mulching is the intelligent way to keep your lawn healthy. This is when the grass clippings are cut into fine pieces which then fall back into the soil.
  • Page 32 Operation Cutting Height Adjustment Make sure the engine is off. Pull the adjustment lever outwards and select the required height. The height is automatically adjusted for all wheels. This is the lowest height setting. This is the highest height setting. www.hyundaipowerproducts.co.uk 01646 687 880 aftersales@hyundaipowerproducts.co.uk...
  • Page 33 Operation General Mowing Tips Maintain a constant cutting height of 3-5cm. Do not shorten the grass to less than half its original height. Under certain conditions, such as very tall grass, it may be necessary to raise the height of cut to reduce pushing effort, prevent overloading of the motor and leaving clumps of grass clippings.
  • Page 34 Starting Procedure YOU MUST read and understand the full safety instruction manual before starting the machine. CAUTION - For OUTDOOR use ONLY. Petrol machines produce carbon monoxide – poisonous, colourless and odourless gas that can cause serious injury or death. Petrol is highly flammable, always handle with extreme care and in a well ventilated area.
  • Page 35 Starting Procedure Electric Start Make sure the blade is free of long grass and the cutting height is set to the highest setting. From cold, pump the primer bulb 5 times. You do not need to do this for warm start. (Warm start is when the machine has been turned off for less than 15-20 minutes).
  • Page 36 Starting Procedure Recoil Start Make sure the blade is free of long grass and the cutting height is set to the highest setting. From cold, pump the primer bulb 5 times. You do not need to do this for warm start. (Warm start is when the machine has been turned off for less than 15-20 minutes).
  • Page 37 Stopping Procedure Stopping CAUTION - The engine and exhaust will remain hot for a while after use. Ensure the engine and exhaust has cooled before carrying out any maintenance, refuelling or storage. Before stopping the machine, you must allow the engine to idle for 30 seconds. You do not need to do this if you need to emergency stop the engine.
  • Page 38 Maintenance Maintenance Safety IMPORTANT - Routine and accurate maintenance is essential for maintaining original machine safety and performance levels. WARNING - Before cleaning or doing maintenance work, you need to stop the engine, disconnect the spark plug cable and read the relevant instructions. You need to wear proper clothing and protective gloves whenever your hands are at risk.
  • Page 39 Maintenance Cleaning CAUTION - DO NOT use a hose pipe or pressure washer to clean the engine. Water can damage the engine or contaminate the fuel system. NOTE Engine must be switched off and spark plug lead disconnected. After Each Use •...
  • Page 40 Maintenance Storage Where To Store Store in a cool, dry place away from sources of ignition and varying changes in temperature. Store on a flat and level surface with all wheels on the ground. DO NOT stack other items on top of the machine when in storage. Store the machine in a safe place, out of the reach of children or anyone who is not familiar with operation.
  • Page 41 Maintenance Long Term Storage If storing the machine for a period of 30 days or more, you must follow proper storage and winterisation guidelines to avoid any possible issues with the machine. Incorrect storage can lead to possible fueling or engine issues that will not be covered by the warranty. Allow the engine to fully cool down.
  • Page 42 Maintenance The Blade WARNING • Never touch a rotating blade. • Check the blade in order to get a good cut. The blade should always be sharp and well balanced. At regular intervals, check the tightness of all nuts, bolts and screws. •...
  • Page 43 Maintenance Air Filter CAUTION - A dirty air filter will restrict the air flow to the carburettor, which will reduce engine efficiency. When using the machine in very dusty areas you must clean or replace the air filter more often. Never operate the machine without the air filter being fitted it can cause damage to the engine which is not covered by warranty.
  • Page 44 Maintenance Spark Plug For good performance, the spark plug must be properly gapped and free of deposits. You MUST allow the engine to cool down before carrying out any maintenance. Always use the correct spark plug. To check the spark plug, remove the spark plug HT lead cap and remove the spark plug with the spark plug wrench.
  • Page 45 Maintenance Changing / Draining Oil To reduce fire hazards, check there is no oil and/or fuel leaks on a regular basis. It is highly recommended to change the engine oil every 100 hours or 12 months. This will ensure the machine will function properly over time. There are different ways you can empty the oil: •...
  • Page 46 Maintenance OPC Cable Adjustment NOTE - If there is more than 10mm movement in the OPC lever before the cable begins to move, then the OPC cable will require adjustment. It is necessary as part of routine maintenance to adjust the OPC cable tension to ensure the lawnmower will start correctly. Follow the OPC cable to the adjuster located on the side of the engine.
  • Page 47 Maintenance Drive Cable Adjustment NOTE - If there is more than 10mm movement in the drive lever before the cable begins to move, then the drive cable will require adjustment. It is necessary as part of routine maintenance to adjust the drive cable tension to ensure the lawnmower will self-propel correctly.
  • Page 48 Troubleshooting Possible Cause Problem Possible Solution OPC cable not adjusted correctly. Adjust OPC cable. Fuel tank is empty. Fill fuel tank. Stale petrol. Drain carburetor float bowl. Engine does Clean or replace air filter. Air filter element is dirty. not start Spark plug is loose.
  • Page 49 Technical Data Specifications Model HYM430SPE Engine Type HYUNDAI IC140VE, 4-Stroke OHV Single Cylinder Engine Size 139cc Rated Power 2.6kW Max. Engine Speed 2800rpm Fuel Tank Capacity & Fuel Type 1L Straight Unleaded Petrol Oil Capacity & Oil Type 600ml SAE30 or 15W40 Start Method Recoil Start &...
  • Page 50 Spare Parts Ordering Spare Parts Only use original spare parts: The use of non-original and/or incorrectly fitted parts will jeopardise the safety of the machine, may cause accidents or injuries for which the manufacturer is under no circumstance liable or responsible. Find the part you are looking for in the drawings.
  • Page 51 Spare Parts Drawing B Drawing C aftersales@hyundaipowerproducts.co.uk www.hyundaipowerproducts.co.uk 01646 687 880...
  • Page 52 Spare Parts Drawing D aftersales@hyundaipowerproducts.co.uk www.hyundaipowerproducts.co.uk 01646 687 880...
  • Page 53 Spare Parts Drawing E Drawing F aftersales@hyundaipowerproducts.co.uk www.hyundaipowerproducts.co.uk 01646 687 880...
  • Page 54 Spare Parts Drawing A Drawing Number Spare Part Name Part Number HYM430SPE-A1 Foam Pipe 1288003 HYM430SPE-A2 Clutch Lever 1290032 HYM430SPE-A3 Brake Lever 1001001 HYM430SPE-A4 Limiting Stopper 1290002 HYM430SPE-A5 Upper Handle 1137005 HYM430SPE-A6 Bolt 1290006 HYM430SPE-A7 Flat Washer 1290007 HYM430SPE-A8 Knob 1290008 HYM430SPE-A9 Rope Guide...
  • Page 55 Spare Parts Drawing C Drawing Number Spare Part Name Part Number HYM430SPE-C1 Y139E Engine 1137030 HYM430SPE-C2 Screw Cap 1290042 HYM430SPE-C3 Belt Cover 1288036 HYM430SPE-C4 Bolt 1149046 HYM430SPE-C5 Screw 1290044 HYM430SPE-C6 Flat Washer 1288086 HYM430SPE-C7 Flat Key 1149047 HYM430SPE-C8 Blade Adapter 1149048 HYM430SPE-C9 17”...
  • Page 56 Spare Parts Drawing D Drawing Number Spare Part Name Part Number HYM430SPE-D1 Bolt 1143107 HYM430SPE-D2 Height Adjustment Plate 1288048 HYM430SPE-D3 1290064 HYM430SPE-D4 Right Bracket 1288050 HYM430SPE-D5 Bolt 1137049 HYM430SPE-D6 1290039 HYM430SPE-D7 Deck 1137051 HYM430SPE-D8 Mulching Plug 1288054 HYM430SPE-D9 Cable Sleeve 1290058 HYM430SPE-D10 Left Bracket...
  • Page 57 Spare Parts Drawing E Drawing Number Spare Part Name Part Number HYM430SPE-E1 Height Adjustment Handle 1288062 HYM430SPE-E2 Rear Wheel Shaft Assy 1288063 HYM430SPE-E3 Inner Wheel Cover 1288064 HYM430SPE-E4 Spring Washer 1290089 HYM430SPE-E5 Ball Bearing 1290113 HYM430SPE-E6 7” Wheel 1288067 HYM430SPE-E7 1290094 HYM430SPE-E8 7”...
  • Page 58 Recycling And Disposal Recycling And Disposal We do not offer a takeback scheme for the recovery of Waste Electrical Electronic Equipment (WEEE) & Batteries. Instead the responsibility to dispose of WEEE and/or Batteries is passed onto you by us. So when it becomes necessary to dispose of your machine you must take it to your local Civic Amenity Site.
  • Page 59 HYM510SP(E) 508mm 97dB(A) 98dB(A) 2800 Product Details: Brand: Hyundai Model: HYM430SP(E), HYM460SP(E), HYM510SP(E) Description: Petrol lawnmower Name and address of technical documentation holder and EU distributor: Genpower Ltd, Isaac Way, Pembroke Dock, Pembrokeshire, SA72 4RW, UK. Signed by: Roland Llewellin, Managing Director Date: 09/12/2019 aftersales@hyundaipowerproducts.co.uk...
  • Page 60 Go to www.hyundaisupport.co.uk or search ‘Hyundai Power Products’ in YouTube. Warranty Proof of purchase will be required before you make a warranty claim. Full warranty terms and conditions can be found on the HYUNDAI POWER PRODUCTS website: www.hyundaipowerproducts.co.uk Manual Updates Our manuals are constantly being reviewed and updated.
  • Page 61 Our Product Range Generators Mini Dumpers Leisure Inverter, Petrol, Diesel And Built-In 4-Wheel Drive Mini Dumpers And Tracked Motorhome Generators Dumpers Pressure Washers Yard Sweeper Petrol, Diesel And Electric Pressure Washers Self Propelled Yard Sweeper Power Brush Water Pumps Scarifiers Submersible, Clean And Dirty Water And Petrol Lawn Scarifier And Aerator Professional Chemical Water Pumps...
  • Page 62 Product Information Information As soon as you have purchased the machine, we recommend that you fill out the following. If you need to contact an authorised dealer or customer service for information on servicing, you may need to provide the following information. The model number and serial number can be found on the grey specification sticker on your machine.
  • Page 63 Need Help? Talk To Our Experts Contact Us Our friendly aftersales team will be more than happy to help you. Phone Call our team on 01646 687880, open Monday-Friday 8.30am-5pm. Email aftersales@hyundaipowerproducts.co.uk Online Live Chat Go to www.hyundaipowerproducts.co.uk Live chat is open Monday-Friday from 8.30am-5pm. Post Genpower Limited, Isaac Way, Pembroke Dock, Pembrokeshire, SA72 4RW, UK.
  • Page 64 For Inquiries, Please Contact: GENPOWER LTD Isaac Way, London Road, Pembroke Dock, UK, SA72 4RW. T: +44 (0) 1646 687 880 E: info@hyundaipowerproducts.co.uk www.hyundaipowerproducts.co.uk Imported / Distributed by Genpower Ltd for Licensed by Hyundai Corporation Holdings, Korea the United Kingdom & Ireland...
