- Page 2 SAFETY 3 - 7 PART LOCATIONS QUICK START GUIDE 9 - 14 STARTING PROCEDURE STOPPING PROCEDURE USING THE MACHINE 16 - 17 MAINTENANCE 18 - 22 TROUBLESHOOTING SPECIFICATION...
- Page 3 The operator of the machine is responsible for, and has a duty of care in making sure that the machine is operated safely and in accordance with the instructions in this user manual. Keep the manual safe and pass it on if the machine is loaned or sold to another user.
- Page 4 1.11 Carbon monoxide is a colourless and odourless gas. Inhaling this gas can cause death as well as serious long term health problems such as brain damage. 1.12 The symptoms of carbon monoxide poisoning can include but are not limited to the following;...
- Page 5 1.31 fuel and defuel in a well ventilated area outside of buildings. 1.32 wear correct, suitable and fit for purpose Personal Protective Equipment (PPE), suggested items are but not limited to safety gloves, overalls. 1.33 When fueling/de-fueling avoid inhaling fumes. 1.34 When de-fueling use a proper fuel retriever.
- Page 6 1.51 Batteries present a risk if they become damaged by the possible leaking of electrolyte. This electrolyte is an acid and can cause serious burn injuries. Care should be taken when working on or near them. the electrolyte may be in a liquid or gel form.
- Page 7 1.71 The operating noise of the machine can damage your hearing. Wear hearing protection such as earplugs or ear defenders to protect your hearing. Long-term and regular users are advised to have hearing checked regularly. Be especially vigilant and cautious when hearing ear protection because your ability to hear alarm warnings will be reduced.
- Page 8 Handle Primer Bulb Operator Presence Control Lever Spark Plug Recoil Starter Handle Exhaust Central Wheel Height Adjuster* Air Filter Oil Filler Cap Grass Catcher Bag *HYM400P Only...
- Page 9 This guide is meant to serve as a quick reference for operating your Hyundai Lawn Mower. We always advise reading the manual in full before operation. Petrol lawnmowers produce carbon monoxide – a poisonous, colourless and odourless gas that can cause serious injury or death.
- Page 10 Attach the handle onto the base unit using the supplied bolts (1). If the upper handles are attached, unfold and the lock into place using the fixed clamps (2). If the upper handle is not attached, fix in place using the supplied bolts. Take care to ensure the cables are not snagged or stretched (3).
- Page 11 2.10 Slowly pull the recoil handle until it reaches the recoil retaining loop on the right hand handle and thread it through the loop (1). Recoil Handle Recoil Cord Recoil Retaining Loop 2.11 Remove the oil filler cap (1). 2.12 Fill with fresh SAE 15W-40 oil to the upper mark on the dipstick (2).
- Page 12 If you are stood behind the lawn mower: : This attaches to the lever in front of the main handlebar and if followed, will attach to the engine. : This attaches to the lever behind the main handlebar and if followed, will enter the deck of the lawn mower behind the engine.
- Page 13 Refit the lever back into its location hole on the main handlebar (5). Check the cable lies flat and has not snagged on any other part of the lawnmower (6). It is necessary as part of routine maintenance to adjust the OPC cable tension to ensure the lawnmower will start correctly.
- Page 14 Move the adjustment nut towards the lock nut and continually check the cable tension at the lever (3). Once the movement has been removed, hold the adjustment nut in place and tighten the lock nut back towards the adjustment lever to lock the cable in place (4). Check the cable adjustment has worked by starting the mower.
- Page 15 ensure the mower has the correct oil and fuel level before operation. From cold, pump the primer bulb (1) 5 times. Make sure the blade is free of long grass and the cutting height is set to maximum (2). Pull back the Operator Presence Control (OPC) lever (3) towards the main handle. Gently pull the recoil starter handle until you feel resistance, then pull swiftly until the engine starts.
- Page 16 The engine and exhaust will remain hot for a while after use. Ensure the engine and exhaust have cooled before carrying out any maintenance or storage. Before stopping the machine, you must allow the engine to idle for 30 seconds. Release the OPC Lever (1) and the engine will stop.
- Page 17 Do not operate the engine in a confined space where dangerous carbon monoxide fumes can collect. Mow only in daylight. Avoid operating the equipment in wet grass. 5.10 Always be sure of your footing on slopes , never run. 5.11 For wheeled rotary machines, mow across the face of slopes, never up and down.
- Page 18 touch a rotating blade. Always stop the engine and unplug the spark plug before doing any repairs or maintenance. Check regularly the oil level and keep it to the recommended level as required. Frequently check the lawnmower and ensure that all grass deposits are removed from beneath the deck.
- Page 19 allow the engine to cool down before carrying out any maintenance. Always replace with the same model spark plug as fitted. To check spark plug, remove spark plug cap (1) and remove spark plug (2) using the supplied spark plug wrench. Clean the spark plug electrode, making sure that there is no damage to the insulator or electrode.
- Page 20 A dirty air filter will restrict the air flow to the carburetor, which will reduce engine efficiency. When using the lawnmower in very dusty areas you must clean or replace the air filter more often. Never operate the machine without the air filter being fitted it can cause damage to the engine which is not covered by warranty.
- Page 21 fuel and defuel in a well ventilated area outside of buildings. wear correct, suitable and fit for purpose Personal Protective Equipment (PPE), suggested items are but not limited to safety gloves, overalls. 6.17 The use of old or stale fuel will impair starting and running of the machine. 6.18 Make sure that the machine has fresh unleaded fuel and always remove fuel before storing for long periods.
- Page 22 use a hose pipe or pressure washer to clean the engine. Water can damage the engine or contaminate the fuel system. 6.22 Wipe the deck with a dry cloth. 6.23 You can hose under deck by tilting the mower. Make sure you tilt the machine so that the air filter is facing up.
- Page 23 Where necessary, all corrective actions should be carried out by suitably qualified persons. If the starter rope becomes disconnected from the rope guide on handle, disconnect the spark plug cap. Pull the starter rope out from engine slowly and re-engage in guide. Re connect spark plug cap.
- Page 24 Engine Type Hyundai OHV 4-Stroke Hyundai OHV 4-Stroke Engine Size – cc Fuel Tank Capacity - L 0.8L 0.8L Fuel Type Straight Unleaded Petrol Straight Unleaded Petrol Oil Capacity – ml Rated Speed – rpm Rated Power – kw Drive Type...
-
Page 25: Postal Address
POSTAL ADDRESS TELEPHONE TECHNICAL EMAIL WEBSITE please visit 10.0 Our manuals are constantly being reviewed and updated. However if you find and error, omission or something you find unclear, please contact your dealer for assistance. 10.1 Our latest manuals are also placed online. 10.2 We reserve the right to make any modifications without prior notice whenever necessary. - Page 26 For Inquires, Please Contact: Trade Tested Limited PO Box 9117, Newmarket, Auckland 1149, New Zealand 0800 800 880 support@tradetested.co.nz www.tradetested.co.nz Imported/Distributed by Trade Tested Limited Licensed by Hyundai Corporation, Korea 28 28...
