Summary of Contents for Hyundai HYM530SPE
- Page 1 PETROL LAWNMOWER HYM530SPE Instruction Manual...
- Page 2 USING THE MACHINE. Keep for future reference and pass it on if the machine is loaned or sold to another user. This manual has been produced by Hyundai Power Products and should be kept with the product. Please read and understand these instructions before you use your product. Failure to do this may result in personal injury or damage to the product.
-
Page 3: Table Of Contents
Contents Safety Information.....4-19 Maintenance......41-51 Maintenance Safety........41 Understand Your Machine.......4 Checking Your Machine.........41 Personal Safety..........5 Cleaning............42-43 Inspect Your Machine........6 Transportation..........43 Work Area............7 Storage............44-45 During Use............8-9 Blade Maintenance........46 Engine Safety..........10 Air Filter............47 Carbon Monoxide...........11 Spark Plug.............48 Fuel Safety..........12-13 Cleaning / Draining Oil........49 Batteries............14 Fuel And Carburetor........49 Electrical Safety..........15... -
Page 4: Safety Information
Safety Information Safety No list of safety guidelines can be complete. Every environment is different. Always consider safety first, as it applies to your individual working conditions. Use this and other machinery with caution and respect. Failure to do so could result in serious injury, damage to equipment, or poor work results. -
Page 5: Personal Safety
Safety Information Personal Safety • WARNING! Never allow children or people unfamiliar with these instructions to use the product. Local regulations can restrict the minimum age of the operator. • Keep children, pets, and other people not using the unit away from the work area (at least 15m). -
Page 6: Inspect Your Machine
Safety Information Inspect Your Machine • Check your machine before starting it. Keep guards in place and in working order. Make sure all nuts, bolts, etc., are securely tightened. • You must check the general condition of the machine before use. •... -
Page 7: Work Area
Safety Information Work Area • Make sure you thoroughly inspect the entire work area and remove all objects and anything that could be thrown by the machine or could damage the engine or machine (branches, stones, wire, toys, etc). Attempting to clear the work area whilst using the machine will reduce your concentration and creates a trip hazard. -
Page 8: During Use
Safety Information During Use • Always hold the unit with both hands when operating. Keep a firm grip on the handlebars. Be aware that the machine may unexpectedly bounce upward or jump forward if the machine should strike buried obstacles such as large rocks or roots. •... - Page 9 Safety Information • Never attempt to move the machine in any way other than intended for normal use while the engine is running. • Reduce the throttle during engine shutdown and close the fuel valve. • Factory-fitted control devices, such as the handle-mounted clutch cable, must not be removed or exposed.
-
Page 10: Engine Safety
Safety Information Engine Safety • This machine is equipped with an internal combustion engine. Do not use on, or near, forest-covered or brush-covered land unless the exhaust system is equipped with a spark arrester meeting applicable local, state, or federal laws. •... -
Page 11: Carbon Monoxide
Safety Information Carbon Monoxide DANGER! Engine exhaust fumes contain Carbon Monoxide. This is a poisonous gas and can kill in minutes. NEVER use inside a building or in an area with poor ventilation. NEVER use inside a confined space, such as but not limited to a house, garage, vehicle, boat or tent. ONLY use outside and far away from windows, doors and vents. -
Page 12: Fuel Safety
Safety Information Fuel Safety CAUTION! ALL FUELS ARE HIGHLY FLAMMABLE AND PETROL VAPOUR IS EXPLOSIVE. TAKE EXTREME CARE WHEN HANDLING FUEL. KEEP FUEL OUT OF REACH OF CHILDREN. General Safety General Safety • Do not smoke each time fuel is handled. •... - Page 13 Safety Information Fueling / De-Fueling • ALWAYS fuel and de-fuel in a well ventilated area outside of buildings. Use a funnel to add fuel, only outdoors. Do not smoke during this and each time fuel is handled. • Add fuel before igniting the engine, never remove the fuel tank cap or add fuel whilst the engine is running or when it is hot.
-
Page 14: Batteries
Safety Information Batteries (Where Present) Batteries present a risk if they become damaged by the possible leaking of electrolyte. This electrolyte is an acid and can cause serious burn injuries. Care should be taken when working on or near them. NOTE the electrolyte may be in a liquid or gel form. Should you come in to contact with electrolyte you should;... -
Page 15: Electrical Safety
Safety Information Electrical Safety (Where Applicable) DANGER! ELECTRICITY CAN KILL - NEVER WORK ON LIVE/ENERGISED EQUIPMENT. • Prior to carrying out any maintenance work you MUST identify electrical isolation methods and isolate all electrical supplies. • Prior to use and with all electrical supplies isolated, you MUST check all electrical cables, plugs and connectors for the following;... -
Page 16: Vibrations
Safety Information Vibrations (Where Applicable) • Prolonged use of hand held (operated) machines will cause the user to feel the effects of/from vibrations. These vibrations can lead to white finger (Raynaud’s phenomenon) or carpal tunnel syndrome. This condition reduces the ability of the hand to feel and regulate temperature, causing numbness and heat sensations and may cause nerve damage and circulatory tissue death. -
Page 17: Personal Protective Equipment
Safety Information Personal Protective Equipment Appropriate Personal Protective Equipment (PPE), MUST be worn at all times when operating or repairing the machine. No protective equipment can ensure 100% protection. When selecting PPE, make sure it’s CE marked and it suits the user in terms of size, fit, etc. If more than one item of PPE is worn at the same time, make sure they can be used together, e.g. -
Page 18: Intended Use
Intended Use The HYM530SPE is a petrol powered rear wheel drive, self-propelled, electric push button start lawnmower from HYUNDAI. The HYM530SPE has a working width of 530mm and is powered by a 224cc 4-stroke OHV petrol engine. The lawnmower is a garden tool and precisely a pedestrian controlled lawnmower. The machine is essentially composed of an engine which drives a blade enclosed in a casing, equipped with wheels and a handle. -
Page 19: Symbols On The Machine
Safety Information Symbols On The Machine We have provided safety messages in this manual and on the machine. This information alerts you to potential hazards that could hurt you or others. Please read these messages carefully. However, we may not have listed all of the possible hazards, you must also use your own judgment. -
Page 20: Features
Features HYM530SPE Features Self Propelled Lever Upper Handle Operator Presence Control (OPC) Lever Rechargeable Battery Push Button Quick Release Ignition Lever Fuel Filler Cap Cutting Height Adjustment Lever Oil Filler Air Filter Grass Collector Spark Plug Side Discharge Exhaust Chute www.hyundaipowerproducts.co.uk... - Page 21 Features HYM530SPE Features Self Propelled Lever Propels the machine forward. All you have to do is control the path the machine takes. Upper Handle Hold onto with both hands this whilst using the machine. Operator Presence Control (OPC) Lever This is a safety feature. The machine will stop if you let go of this lever.
-
Page 22: Unboxing
Lay the contents out and check them. If any part is damaged or missing, you must not use the machine. Contact HYUNDAI Power Products immediately. You must keep the packaging material in case the machine needs to be returned or repaired. -
Page 23: Assembly
Assembly Assembly Safety CAUTION - This guide is meant to serve as a quick reference for operating your HYUNDAI machine. We always advise reading the manual in full before operation. CAUTION - For OUTDOOR use ONLY. Petrol machines produce carbon monoxide –... -
Page 24: Assemble Handlebars
Assembly Unboxing & Assembly Video: Go to youtube.com and type in Hyundai HYM530SPE assembly. YOU MUST read and understand the instruction manual first. Step 1 : Assemble Handle Bars Attach the lower handle to the deck of the mower and tighten the lower bolts securely (A). - Page 25 Assembly Attach the upper handle to the lower handle and tighten the quick release handle bolts securely. See image 3. Slowly pull the recoil start handle up to the cord loop on the handlebar. See image 4. Image 3 Image 4 www.hyundaipowerproducts.co.uk 01646 687 880 sales@hyundaipowerproducts.co.uk...
-
Page 26: Attach Central Panel
Assembly Step 2 : Attach Central Panel Slide the OPC lever to the right to remove from the hole in the handle. Disconnect the cable from the OPC lever. Feed the cable through the hole in the control panel. Reconnect the cable to the OPC lever. Re-insert the OPC lever into the locating hole in the handlebar. -
Page 27: Cable Attachment
Assembly Step 3 : Cable Attachment NOTE - If stood behind the lawnmower: OPC Cable : Attaches to the lever in front of the main handlebar if traced, will attach to the engine. Drive Cable : Attaches to the lever behind the main handlebar and if traced, will enter the deck of the lawnmower behind the engine. -
Page 28: Cable Clips
Assembly Step 4 : Cable Clips Use the 2 velcro straps to attach the electric wire to the handlebar. Use these on the right-hand handle bar. See image 1. Use the plastic cable clip to attach the cables to the left-hand handlebar. See image 2. Image 1 Image 2 www.hyundaipowerproducts.co.uk... -
Page 29: Preparation
Preparation Before Each Use YOU MUST read and understand the full safety instruction manual before starting the machine. Always ensure that the machine is in a safe working condition. Inspect and check safety devices and guards and check all nuts, bolts and screws are secure. Check the oil level and fill the fuel tank. -
Page 30: Adding Oil
Preparation Adding Oil Oil Type : SAE 30 or 15w40 Engine Oil Oil Capacity : 500ml NOTE - The machine is delivered without oil in the engine. All machines are tested and inspected so there may be some residual oil left in the machine so please fill with caution. Remove the oil filler cap. -
Page 31: Adding Fuel
Preparation Adding Fuel Make sure you read the fuel safety before handling fuel. Fuel Type : Fresh Straight Unleaded Petrol Fuel Capacity : 1.8L NOTE - The machine is delivered without petrol. All machines are tested and inspected so there may be some residual petrol left in the machine so please fill with caution. -
Page 32: Charging The Battery
Preparation Charging The Battery Plug the charger into a domestic plug socket and wait for the green power indicator light to turn on. Slide the battery into the charger and the charging indicator light should turn red. Once the battery has been fully charged, the charging indicator light should turn green to indicate that the battery is fully charged. -
Page 33: Inserting / Removing The Battery
Preparation Inserting / Removing The Battery To insert the battery, lift the battery cover on the centre panel and slot it into place. Close the battery cover. To remove the battery, lift the battery cover on the centre panel and press down on the tab and pull the battery out. -
Page 34: Operation
Operation Grass Collection Lift the rear discharge flap. Remove the mulching plug if installed. Hook the grass collector over the mounting points. Lower the rear discharge flap. www.hyundaipowerproducts.co.uk 01646 687 880 sales@hyundaipowerproducts.co.uk... -
Page 35: Mulching
Operation Mulching Lift the rear discharge flap and remove the grass collector. Install the mulching plug. Lower the rear discharge flap. What Is Mulching? Mulching is the intelligent way to keep your lawn healthy. This is when the grass clippings are cut into fine pieces which then fall back into the soil. -
Page 36: Side Discharge
Operation Side Discharge Lift the rear discharge flap and remove the grass collector. Install the mulching plug and lower the rear discharge flap. Lift the catch on the side discharge flap and lift the flap. Hook the side discharge chute over the mounting points and lower the side discharge flap until it rests on the side discharge chute. -
Page 37: Cutting Height Adjustment
Operation Cutting Height Adjustment Pull the adjustment lever outwards and select the required height. The height is automatically adjusted for all wheels. www.hyundaipowerproducts.co.uk 01646 687 880 sales@hyundaipowerproducts.co.uk... -
Page 38: Starting / Stopping
Starting Procedure YOU MUST read and understand the full safety instruction manual before starting the machine. CAUTION - For OUTDOOR use ONLY. Petrol machines produce carbon monoxide – poisonous, colourless and odourless gas that can cause serious injury or death. Petrol is highly flammable, always handle with extreme care and in a well ventilated area. -
Page 39: Recoil Start
Starting Procedure Recoil Start Make sure the blade is free of long grass and the cutting height is set to the highest setting. Pull the Operator Presence Control (OPC) lever back towards the main handlebar. Gently pull the recoil start handle until you feel resistance, then pull swiftly until the lawnmower starts. -
Page 40: Stopping Procedure
Stopping Procedure CAUTION - The engine and exhaust will remain hot for a while after use. Ensure the engine and exhaust has cooled before carrying out any maintenance, refuelling or storage. Stopping Release the Operator Presence Control (OPC) lever and the engine will stop. www.hyundaipowerproducts.co.uk 01646 687 880 sales@hyundaipowerproducts.co.uk... -
Page 41: Maintenance
Maintenance Maintenance Safety IMPORTANT - Routine and accurate maintenance is essential for maintaining original machine safety and performance levels. WARNING - Before cleaning or doing maintenance work, you need to stop the engine, disconnect the spark plug cable and read the relevant instructions. You need to wear proper clothing and protective gloves whenever your hands are at risk. -
Page 42: Cleaning
Maintenance Cleaning CAUTION - DO NOT use a hose pipe or pressure washer to clean the engine. Water can damage the engine or contaminate the fuel system. NOTE Engine must be switched off and spark plug lead disconnected. After Each Use •... -
Page 43: Transportation
Maintenance Hose Attachment • Connect a garden hose to the quick release hose connector on left side of the cutting deck, lower the cutting deck, start the engine and turn on water supply. Run engine for 2 minutes to clean underside of cutting deck. Transportation Whenever the machine is to be handled, lifted, transported or tilted, you must: Wear sturdy work gloves. -
Page 44: Storage
Maintenance Storage Where To Store Store in a cool, dry place away from sources of ignition and varying changes in temperature. Store on a flat and level surface with all wheels on the ground. DO NOT stack other items on top of the machine when in storage. Store the machine in a safe place, out of the reach of children or anyone who is not familiar with operation. - Page 45 Maintenance Long Term Storage If storing the machine for a period of 30 days or more, you must follow proper storage and winterisation guidelines to avoid any possible issues with the machine. Incorrect storage can lead to possible fueling or engine issues that will not be covered by the warranty. Allow the engine to fully cool down.
-
Page 46: Blade Maintenance
Maintenance The Blade WARNING • Never touch a rotating blade. • Check the blade in order to get a good cut. The blade should always be sharp and well balanced. At regular intervals, check the tightness of all nuts, bolts and screws. •... -
Page 47: Air Filter
Maintenance Air Filter CAUTION - A dirty air filter will restrict the air flow to the carburettor, which will reduce engine efficiency. When using the machine in very dusty areas you must clean or replace the air filter more often. Never operate the machine without the air filter being fitted it can cause damage to the engine which is not covered by warranty. -
Page 48: Spark Plug
Maintenance Spark Plug For good performance, the spark plug must be properly gapped and free of deposits. You MUST allow the engine to cool down before carrying out any maintenance. Always use the correct spark plug- F7RTC or NGK BP7RES. To check the spark plug, remove the spark plug HT lead cap and remove the spark plug with the spark plug wrench. -
Page 49: Cleaning / Draining Oil
Maintenance Changing / Draining Oil To reduce fire hazards, check there is no oil and/or fuel leaks on a regular basis. It is highly recommended to change the engine oil every 100 hours or 12 months. This will ensure the machine will function properly over time. There are different ways you can empty the oil: •... -
Page 50: Opc Cable Adjustment
Maintenance OPC Cable Adjustment NOTE - If there is more than 10mm movement in the OPC lever before the cable begins to move, then the OPC cable will require adjustment. It is necessary as part of routine maintenance to adjust the OPC cable tension to ensure the lawnmower will start correctly. Follow the OPC cable to the adjuster located on the side of the engine. -
Page 51: Troubleshooting
Troubleshooting Possible Cause Problem Possible Solution OPC cable not adjusted correctly. Adjust OPC cable. Fuel tank is empty. Fill fuel tank. Stale petrol. Drain carburetor float bowl. Engine does Air filter element is dirty. Clean or replace air filter. not start Tighten spark plug. -
Page 52: Technical Data
Technical Data Specifications Model HYM530SPE Engine Type Single Cylinder 4-Stroke Engine Size 224cc Rated Power 4.4kW Max. Engine Speed 2800rpm Fuel Tank Capacity & Fuel Type 1.8L Unleaded Petrol Oil Capacity & Oil Type 500ml SAE30 or 15W40 Rated Speed... -
Page 53: Notes
Notes www.hyundaipowerproducts.co.uk 01646 687 880 sales@hyundaipowerproducts.co.uk... -
Page 54: Recycling And Disposal
Recycling And Disposal Recycling And Disposal We do not offer a takeback scheme for the recovery of Waste Electrical Electronic Equipment (WEEE) & Batteries. Instead the responsibility to dispose of WEEE and/or Batteries is passed onto you by us. So when it becomes necessary to dispose of your machine you must take it to your local Civic Amenity Site. -
Page 55: Declaration Of Conformity
96.5dB(A) 98dB(A) 2800 mower Product Details: Brand: Hyundai Model: HYM530SPE Description: Petrol Lawnmower Name and address of technical documentation holder and EU distributor: Genpower Ltd, Isaac Way, Pembroke Dock, Pembrokeshire, SA72 4RW, UK. Signed by: Roland Llewellin, Managing Director Date: 26/10/2020 www.hyundaipowerproducts.co.uk... -
Page 56: Useful Information
Go to www.hyundaisupport.co.uk or search ‘Hyundai Power Products’ in YouTube. Warranty Proof of purchase will be required before you make a warranty claim. Full warranty terms and conditions can be found on the HYUNDAI POWER PRODUCTS website: www.hyundaipowerproducts.co.uk Manual Updates Our manuals are constantly being reviewed and updated. -
Page 57: Our Product Range
Our Product Range Generators Mini Dumpers Leisure Inverter, Petrol, Diesel And Built-In 4-Wheel Drive Mini Dumpers And Tracked Motorhome Generators Dumpers Pressure Washers Yard Sweeper Petrol, Diesel And Electric Pressure Washers Self Propelled Yard Sweeper Power Brush Water Pumps Scarifiers Submersible, Clean And Dirty Water And Petrol Lawn Scarifier And Aerator Professional Chemical Water Pumps... -
Page 58: Product Information
Product Information Information As soon as you have purchased the machine, we recommend that you fill out the following. If you need to contact an authorised dealer or customer service for information on servicing, you may need to provide the following information. The model number and serial number can be found on the grey specification sticker on your machine. -
Page 59: Contact Us
Need Help? Talk To Our Experts Contact Us Our friendly aftersales team will be more than happy to help you. Phone Call our team on 01646 687880, open Monday-Friday 8.30am-5pm. Email aftersales@hyundaipowerproducts.co.uk Online Live Chat Go to www.hyundaipowerproducts.co.uk Live chat is open Monday-Friday from 8.30am-5pm. Post Genpower Limited, Isaac Way, Pembroke Dock, Pembrokeshire, SA72 4RW, UK. - Page 60 Isaac Way, London Road, Pembroke Dock, UNITED KINGDOM, SA72 4RW T: +44 (0) 1646 687 880 F: +44 (0) 1646 686 198 E: info@hyundaipowerproducts.co.uk www.hyundaipowerproducts.co.uk Imported/Distributed by Genpower Ltd for The United Kingdom & Ireland Licensed by Hyundai Corporation, Korea...
